Diode Lasers — 2174 models | Laser Selector

Browse 255 product families

Choose a series to compare its wavelength models and open their specifications.

2174 models · 211 series

405nm CW Pulse Violet Blue Laser

40 models

Model	Wavelength	Output / average power	Repetition rate	Pulse width	Spectral linewidth	Power stability	Optical noise	Longitudinal mode	Power stability (rms, 4 hours±3℃)	Beam divergence, full angle (mrad)	Beam diameter at the aperture (1/e2,mm)	M2	Polarization ratio	Cooled method	Operating temperature (℃)	Power supply (220/110VAC)	Expected lifetime (hours)	Transverse mode	Warm-up time (minutes)	Operating temperature (°C)	Power supply (100-240VAC)	Parameters of customed power supply	Polarization direction	Power stability(rms, over 4 hours)	Warm-up time	Warranty (years)	Operating voltage(PSU-V-OEM)	Operating voltage(PSU-I-OEM)	Connection	Operating temperature	Storage temperature	Humidity	Dimensions of laser head	Operating voltage(external PCB1)	stability	Operating voltage(internal PCB)	Modulation optional	Storage temperature (°C)	Humidity (%)	Dimensions of laser head (mm)	Operating voltage(PSU-II-OEM)	Dimensions of internal PCB	Fiber core diameter	Fiber Connector	Fiber length	Fiber jacket	Power stability (rms, 4 hours ± 3°C)	Ave power stability (rms, 4 hours±3℃)	Beam size (<250mm)	Beam divergence (mrad)	Laser operation mode	Weight (g)
MSL-T-405	405 nm	1~80 mW	–	–	<0.000005 nm (<10 MHz) Coherent length >30m	–	<0.5%	Single	<1%, <0.5%	<1	<2	<1.2	>100:1,Vertical(Horizontal optional)	Water cooled	15-35	RAD1PS	>10000	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-C-405	405 nm	1~50 mW	–	–	–	<1%	–	–	–	~2.5×0.2	–	–	–	Air cooled	–	–	>10000	Multimode	<5	10-35	PSU-H-FDA/PSU-H-LED	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-E-405	405 nm	1~50 mW	–	–	< 0.03 nm	<1%	–	–	–	~2.5×0.2	–	–	–	Air cooled	–	–	>10000	Multimode	<5	10-35	PSU-H-FDA/PSU-H-LED	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
TUN-403~406 Wavelength tunable	405 nm	1~30 mW	–	–	<0.1 nm	<1%	–	–	–	<1.0	–	–	–	–	20-30	–	>10000	Near TEM00	<5	–	PSU-TUN	TEC: 7-12kΩ	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
TEM-LN-405	405 nm	1~30 mW	–	–	–	<0.5%	<0.5%	–	–	<1.5	–	<1.1	–	–	–	–	>10000	TEM00	<5	25±3	PSU-III-FDA/PSU-III-LED/PSU-A-D	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MLL-III-405L	405 nm	1~300 mW	–	–	–	<0.5%	<0.5%	–	–	–	–	<1.5 / <1.2	–	Conduction	–	–	>10000	Near TEM00	<5	10-35	PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MLL-III-405	405 nm	1~1000 mW	–	–	–	<0.5%	<0.5%	–	–	<2.5×1.0	–	–	–	Conduction	–	–	>10000	–	<5	10-35	PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MLL-H-405	405 nm	1~3 W	–	–	–	<0.5%	<0.5%	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MLL-III-405-SM	405 nm	1~30 mW	–	–	–	<0.5%	<0.5%	–	–	<2.5×1.0	–	–	–	Conduction	–	–	>10000	–	<5	10-35	PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
TEM-F-405	405 nm	1~30 mW	–	–	–	<0.5%	–	–	–	<1.5	–	<1.1	–	–	–	–	>10000	TEM00	<5	25±3	PSU-III-FDA/PSU-III-LED/PSU-A-D	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-XS-405	405 nm	1~200 mW	–	–	–	<0.5%	–	–	–	~2.5×0.2	–	–	–	Air cooled	–	–	>10000	Multimode	<5	10-35	PSU-H-FDA/PSU-H-LED	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-III-405L	405 nm	1~300 mW	–	–	–	<0.5%	–	–	–	–	–	<1.5 / <1.2	–	Conduction	–	–	>10000	Near TEM00	<5	10-35	PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-III-405	405 nm	1~1000 mW	–	–	–	<0.5%	–	–	–	<2.5×1.0	–	–	–	Conduction	–	–	>10000	Multimode	<5	10-35	PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-H-405	405 nm	1~3 W	–	–	–	<0.5%	–	–	–	~2.5×0.2	–	–	–	Air cooled	–	–	>10000	Multimode	<5	10-35	PSU-H-FDA/PSU-H-LED	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-MD-405	405 nm	1~4000 mW	–	–	–	<0.5%	–	–	–	~2.8×0.5 / ~4.3×0.5	–	–	–	–	25±3	–	>10000	Multimode	<5	–	PSU-H-FDA/PSU-H-LED/PSU-N-LED	–	Horizontal+ Vertical / Horizontal/ Vertical	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-HD-405	405 nm	4~16 W	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
FC-OEM-405	405 nm	1~30 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–
YL-I-405	405 nm	1~24 W	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–
PGL-FP-405	405 nm	1~50 mW	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-V-FC-405	405 nm	1~50 mW	–	–	–	–	–	–	–	<0.5 / <3×0.5	–	–	–	–	–	–	10000	Near TEM00 / Multimode	–	–	–	–	–	<5%, <3%, <1%	minutes / <10	1	100-240VAC	12VDC	9 pin connector	-10°C to 50°C	-20°C to 80°C	< 90%, non-condensing	92(L)×40(W)×40(H)mm3	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-D8-405	405 nm	1~50 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	10000	Near TEM00	–	–	–	–	–	–	–	1	–	–	Cable with flying leads	0°C to 40°C	-20°C to 80°C	<90%, non-condensing	–	6VDC	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-F-405	405 nm	1~50 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-D12-405	405 nm	1~100 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	10000	Near TEM00	–	–	–	–	–	–	–	1	–	–	Cable with flying leads	0°C to 40°C	-20°C to 80°C	<90%, non-condensing	–	6VDC	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-VI-FC-405	405 nm	1~100 mW	–	–	–	<5%	–	–	–	–	–	–	–	–	–	–	–	–	–	10°C to 35°C	–	–	–	–	–	–	–	–	Cable with flying leads	–	–	–	–	–	lifetime	5VDC	TTL or Analog0-3V,0-5V	-10°C to 70°C	<90 %, non-condensing	Φ56×250mm2 / (PGL-FC-375/589)	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-FS-405	405 nm	1~150 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	10000	Near TEM00	–	–	–	–	–	–	minutes / <10	1	–	–	Cable with flying leads	-10°C to 50°C	-20°C to 80°C	< 90%, non-condensing	77(L)×30(W)×30(H)mm3	–	–	–	–	–	–	–	7V / (TTL30kHz or Analog 0-5V,optional)	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-VI-405	405 nm	1~150 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	10000	Near TEM00	–	–	–	–	–	–	–	1	–	–	Cable with flying leads	0°C to 40°C	-20°C to 80°C	<90%, non-condensing	–	–	–	6VDC	–	–	–	–	–	mm2 / Φ12×50	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-H-405	405 nm	1~350 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	10000	Near TEM00	–	–	–	–	–	–	minutes / <10	1	–	–	Cable with flying leads	-10°C to 50°C	-20°C to 80°C	< 90%, non-condensing	77(L)×30(W)×30(H)mm3	–	–	–	–	–	–	–	7V / (TTL30kHz or Analog 0-5V,optional)	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-V-H-FC-405	405 nm	1~500 mW	–	–	–	<1%	–	–	–	<0.5 / <3×0.5	–	–	–	–	–	–	10000	Near TEM00 / Multimode	–	–	–	–	–	–	minutes / <10	–	100-240VAC	12VDC	9 pin connector	-10°C to 50°C	-20°C to 80°C	< 90%, non-condensing	92(L)×40(W)×40(H)mm3	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL-V-H-405	405 nm	1~800 mW	–	–	–	<0.5%	–	–	–	<0.5 / <3×0.5	–	–	–	–	–	–	10000	Near TEM00 / Multimode	–	–	–	–	–	–	minutes / <10	1	100-240VAC	12VDC	9 pin connector	-10°C to 50°C	-20°C to 80°C	< 90%, non-condensing	92(L)×40(W)×40(H)mm3	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
PGL/MDL-L series	405 nm	1~1000 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	–	–	–	10000	Near TEM00	–	–	–	–	–	–	minutes / <10	1	–	–	Cable with flying leads	-10°C to 50°C	-20°C to 80°C	< 90%, non-condensing	77(L)×30(W)×30(H)mm3	–	–	–	–	–	–	–	7V / (TTL30kHz or Analog 0-5V,optional)	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-III-405-SM	405 nm	1~30 mW	–	–	–	<0.5%	–	–	–	<2.5×1.0	–	–	–	Conduction	–	–	>10000	Multimode	<5	10-35	PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
OEM-I-405	405 nm	120 mW	–	–	–	<0.5%	–	–	–	–	–	–	–	Conduction	20-30	–	>10000	–	<5	–	PSU-III-LED	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	3um, 0.12NA	FC/ APC/ PC optional	1m	PVC	–	–	–	–	–	–	Datasheet
PGL-V-H-FP-405	405 nm	1~200 mW	–	–	–	<1%	–	–	–	<0.5 / <3×0.5	–	–	–	–	–	–	10000	Near TEM00 / Multimode	–	–	–	–	–	–	minutes / <10	–	100-240VAC	12VDC	9 pin connector	-10°C to 50°C	-20°C to 80°C	< 90%, non-condensing	92(L)×40(W)×40(H)mm3	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
MDL-NS-405	405 nm	1~300 mW	–	10 ns~10 ms	–	–	–	–	–	~2.5×0.2	–	–	–	Air cooled	–	–	>10000	Multimode	<5	10-35	PSU-H-FDA/PSU-H-LED	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	<2%, <1%, <0.5%	–	–	–	–	–	Datasheet
MDL-PS-405	405 nm	1~100 mW	0.1~80 MHz	100~1000 ps	–	–	–	–	–	~2.5×0.2	–	–	–	Air cooled	–	–	>10000	Multimode	<5	10-35	PSU-H-FDA/PSU-H-LED	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	<2%, <1%, <0.5%	–	–	–	–	–	Datasheet
HPL-405-T	405 nm	200 uJ/ 2 W	1~10 kHz	<15 ns	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet
TUN-TiA-393-408	405 nm	1~1000 mW	10~50 kHz	~35 ns @50 kHz	–	–	–	–	–	<4	–	–	–	Air Cooled	15-35	–	>10000	–	<10	–	PSU-AOM (3U)	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	<5%, <3%	–	–	–	–	Datasheet
FC-D-405	405 nm	1~100 mW	–	–	<0 nm. 06	<1%	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–
PGL-LF-405	405 nm	1~150 mW	–	–	–	–	–	–	–	–	–	–	–	–	–	–	10000	–	–	-10°C to +45°C	–	–	–	–	–	–	–	–	Cable with flying leads	–	–	–	–	–	–	DC 5V	TTL 30kHz or analog (0-3V or 0-5V)	-20°C to +80°C	< 90 %, non-condensing	–	–	–	–	–	–	–	–	–	40-200um	<1.5	CW	45g	Datasheet
TUN-403~406	405 nm	1~30 mW	–	–	<0.1 nm	<1%	–	–	–	<1.0	–	–	–	–	20-30	–	>10000	Near TEM00	<5	–	PSU-TUN	TEC: 7-12kΩ	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	Datasheet

Browse all models by name

Open a model for its complete specifications and technical files. The comparison search above covers the full catalog.

Not sure which model fits?

Send the physics — wavelength, mode, power or energy, linewidth or pulse width, delivery, control and safety — and we qualify the source.
