AO-1064A1064 nm near-infrared Q-switched pulsed laser
1064 nmThe AO-1064A is a precision 1064 nm Actively Q-switched Pulsed laser delivering 1000 mW& 500 output power, with <2%, <1% power stability, <1.2 beam quality. View technical specifications, download the datasheet, and request configuration options from Precisometer.
Specifications
AO-1064A
21 specification rows
| Operating mode | Actively Q-switched |
|---|---|
| Output / average power | 1000 mW& 500 |
| Pulse energy | 1000 uJ & 500 uJ |
| Repetition rate | 1-10 kHz |
| Pulse width | ~12 ns @1 kHz |
| Power stability | <2%, <1% |
| M² | <1.2 |
| Beam / notes | & 532A |
| Transverse mode | TEM00 |
| Beam divergence, full angle (mrad) | <3 |
| Polarization ratio | >100:1 Horizontal |
| Warm-up time (minutes) | <10 |
| Cooled method | Air cooled |
| Operating temperature (℃) | 10-35 |
| Operating voltage (VDC) | 12V/25A |
| Expected lifetime (hours) | >10000 |
| Wavelength (nm) | 1064±1 |
| Rep. rate | 1Hz-10kHz |
| Ave power stability (over 4 hours) | <2%, <1% |
| Beam diameter at the aperture (1/e2, mm) | ~0.8 |
| Beam height from base plate (mm) | 79 |
What do you need?
Tell us the pulse energy, pulse width, repetition rate and beam delivery you need, and we'll reply with the matching configuration and lead time.
Model selection
Nearby series comparison
Compare AO-1064A with the closest available models in the Pulsed Lasers family.
| Selection parameter | AO-1064A (current) | FS-H- 10 64A | FS-H- 10 64B |
|---|---|---|---|
| Wavelength | 1064 nm | 1064 nm | 1064 nm |
| Optical power / pulse energy | 1000 mW& 500 | 1-500 mW | 500-5000 mW |
| Operating mode / pulse width | Actively Q-switched | Pulsed | Pulsed |
| Beam quality | <1.2 | <1.2 | <1.2 |
