Power stability, linewidth, beam quality
MDL-380 is a 380 nm CW laser. Used for medical imaging, flow cytometry, dna sequencing. Central Wavelength 378-382nm MDL-380/ 1~300mW Central Wavelength 378-382nm. Key specifications: output / average power 1~300 mW, operating mode CW, power stability (rms, 4 hours ± 3°c) <2%, <1%, <0.5%. View specifications, datasheet and enquiry options from Precisometer.
Specifications
16 specification rows
| Output / average power | 1~300 mW |
|---|---|
| Beam / notes | Central Wavelength 378-382 nm MDL-380/ 1~300 mW Central Wavelength 378-382 nm |
| Operating mode | CW |
| Power stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Transverse mode | Multimode |
| Beam divergence, full angle (mrad) | ~4.0×1.0 |
| Warm-up time (minutes) | <5 |
| Cooled method | Air cooled |
| Operating temperature (°C) | 10-35 |
| Power supply (100-240VAC) | PSU-H-FDA/PSU-H-LED |
| Expected lifetime (hours) | >10000 |
| Central wavelength (nm) | 380±5 |
| Output power (mW) | 150-400 |
| Beam diameter at the aperture (1/e2, mm) | ~2.0×4.0 |
| Beam height from base plate (mm) | 29 |
| Modulation option | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional |
Application context
Applications named on this model’s datasheet, expanded with the model’s optical specifications.
MDL-380: 380 nm emission can be matched to the absorption or excitation band used in Medical imaging. The stated stability or noise figure (<2%, <1%, <0.5%) helps keep measured intensity changes attributable to the sample rather than source drift.
MDL-380: 380 nm emission can be matched to the absorption or excitation band used in Flow cytometry. The stated stability or noise figure (<2%, <1%, <0.5%) helps keep measured intensity changes attributable to the sample rather than source drift.
MDL-380: 380 nm emission can be matched to the absorption or excitation band used in DNA sequencing. The stated stability or noise figure (<2%, <1%, <0.5%) helps keep measured intensity changes attributable to the sample rather than source drift.
System integration
Use these checks to connect MDL-380 to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
Technical FAQ
Cooled method: Air cooled · Operating temperature (°C): 10-35. Provide the stated cooling method and keep the laser-head base thermally coupled; temperature drift moves wavelength, output power and beam pointing.
Transverse mode: Multimode · Beam divergence, full angle (mrad): ~4.0×1.0. Size the downstream optics from the stated beam diameter and divergence rather than from the aperture of the housing, and confirm the polarisation state before specifying isolators or polarising optics.
Share wavelength, operating mode, output power or pulse energy, linewidth or pulse width, delivery, control, and safety requirements and we will qualify the matching configuration and lead time.
Model selection
Compare MDL-380 with the closest available models in the CW Lasers family. Confirm option-dependent values on the final configuration before ordering.
| Selection parameter | MDL-380 (current) | MLL-III-380 | MLL-H-380 |
|---|---|---|---|
| Wavelength | 380 nm | 380 nm | 380 nm |
| Optical power / pulse energy | 1~300 mW | 1~150 mW | 150~400 mW |
| Operating mode / pulse width | CW | CW | CW |
| Beam quality | Multimode | Multimode | Multimode |
Compare the MDL-380 with nearby cw lasers across the wavelength range.
