1311 models · 241 series
405nm CW Pulse Violet Blue Laser
20 models| Model | Wavelength | Output / average power | Repetition rate | Pulse width | Spectral linewidth | Power stability | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | Polarization direction | Operating temperature (℃) | Warranty (years) | Operating voltage(external PCB1) | Connection | Operating temperature | Storage temperature | Humidity | Warm-up time | Operating voltage(PSU-II-OEM) | Dimensions of laser head | Operating voltage(internal PCB) | Dimensions of internal PCB | Operating voltage(PSU-V-OEM) | Operating voltage(PSU-I-OEM) | Fiber core diameter | Fiber Connector | Fiber length | Fiber jacket | Power stability (rms, 4 hours ± 3°C) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-405 | 405 nm | 1~50 mW | – | – | – | <1% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-E-405 | 405 nm | 1~50 mW | – | – | < 0.03 nm | <1% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XS-405 | 405 nm | 1~200 mW | – | – | – | <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-405L | 405 nm | 1~300 mW | – | – | – | <0.5% | Near TEM00 | – | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 / <1.2 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-405 | 405 nm | 1~1000 mW | – | – | – | <0.5% | Multimode | <2.5×1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-405 | 405 nm | 1~3 W | – | – | – | <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-405 | 405 nm | 1~4000 mW | – | – | – | <0.5% | Multimode | ~2.8×0.5 / ~4.3×0.5 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | – | Horizontal+ Vertical / Horizontal/ Vertical | 25±3 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-HD-405 | 405 nm | 4~16 W | – | – | – | <0.5% | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM -405 | 405 nm | 1~30 mW | – | – | – | <0.5% | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-D8-405 | 405 nm | 1~50 mW | – | – | – | <0.5% | Near TEM00 | – | – | – | – | – | 10000 | – | – | – | 1 | 6VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-D12-405 | 405 nm | 1~100 mW | – | – | – | <0.5% | Near TEM00 | – | – | – | – | – | 10000 | – | – | – | 1 | 6VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-FS-405 | 405 nm | 1~150 mW | – | – | – | <0.5% | Near TEM00 | – | – | – | – | – | 10000 | – | – | – | 1 | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | minutes / <10 | 7V / (TTL30kHz or Analog 0-5V,optional) | 77(L)×30(W)×30(H)mm3 | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-405 | 405 nm | 1~150 mW | – | – | – | <0.5% | Near TEM00 | – | – | – | – | – | 10000 | – | – | – | 1 | – | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | – | – | – | 6VDC | mm2 / Φ12×50 | – | – | – | – | – | – | – | Datasheet |
| PGL-H-405 | 405 nm | 1~350 mW | – | – | – | <0.5% | Near TEM00 | – | – | – | – | – | 10000 | – | – | – | 1 | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | minutes / <10 | 7V / (TTL30kHz or Analog 0-5V,optional) | 77(L)×30(W)×30(H)mm3 | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-V-H-405 | 405 nm | 1~800 mW | – | – | – | <0.5% | Near TEM00 / Multimode | <0.5 / <3×0.5 | – | – | – | – | 10000 | – | – | – | 1 | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | minutes / <10 | – | 92(L)×40(W)×40(H)mm3 | – | – | 100-240VAC | 12VDC | – | – | – | – | – | Datasheet |
| PGL/MDL-L series | 405 nm | 1~1000 mW | – | – | – | <0.5% | Near TEM00 | – | – | – | – | – | 10000 | – | – | – | 1 | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | minutes / <10 | 7V / (TTL30kHz or Analog 0-5V,optional) | 77(L)×30(W)×30(H)mm3 | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-405-SM | 405 nm | 1~30 mW | – | – | – | <0.5% | Multimode | <2.5×1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| OEM-I-405 | 405 nm | 120 mW | – | – | – | <0.5% | – | – | <5 | Conduction | – | PSU-III-LED | >10000 | – | – | 20-30 | – | – | – | – | – | – | – | – | – | – | – | – | – | 3um, 0.12NA | FC/ APC/ PC optional | 1m | PVC | – | Datasheet |
| MDL-NS-405 | 405 nm | 1~300 mW | – | 10 ns~10 ms | – | – | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | <2%, <1%, <0.5% | Datasheet |
| MDL-PS-405 | 405 nm | 1~100 mW | 0.1~80 MHz | 100~1000 ps | – | – | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | <2%, <1%, <0.5% | Datasheet |
410nm CW Pulse Violet Blue Laser
7 models| Model | Wavelength | Output / average power | Repetition rate | Pulse width | Power stability | Transverse mode | M2 | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Beam divergence, full angle (mrad) | Power stability (rms, 4 hours ± 3°C) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-410 | 410 nm | 1~50 mW | – | – | <1% | – | – | – | – | – | – | – | – | – | |
| MDL-III-410L | 410 nm | 1~300 mW | – | – | <0.5% | Near TEM00 | <1.5 / <1.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | Datasheet |
| MDL-III-410 | 410 nm | 1~300 mW | – | – | <0.5% | Multimode | – | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <0.5×2.0 | – | Datasheet |
| FC-OEM -410 | 410 nm | 1~40 mW | – | – | <0.5% | – | – | – | – | – | – | – | – | – | |
| MDL-III-410-SM | 410 nm | 1~40 mW | – | – | <0.5% | Multimode | – | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <0.5×2.0 | – | Datasheet |
| MDL-NS-410 | 410 nm | 1~300 mW | – | 10 ns~10 ms | – | Near TEM00 | <1.5 / <1.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | ~0.5 | <2%, <1%, <0.5% | Datasheet |
| MDL-PS-410 | 410 nm | 1~100 mW | 0.1~80 MHz | 100~1000 ps | – | Near TEM00 | <1.5 / <1.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | ~0.5 | <2%, <1%, <0.5% | Datasheet |
473nm CW Pulse Blue Laser
3 models| Model | Wavelength | Output / average power | Transverse mode | Beam divergence, full angle (mrad) | Expected lifetime (hours) | Warranty (years) | Operating voltage(internal PCB) | Connection | Operating temperature | Storage temperature | Humidity | Dimensions of PGL-VI-473 | Dimensions of PGL-VI-1-473 | Dimensions of external | Beam diameter at the aperture(1/e2) (mm) | Operating voltage(external PCB) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PGL-VI-473 | 473 nm | 1~20 mW | TEM00 | <1.5 | 10000 | 1 | 3VDC | Cable with flying leads | 10°C to 35°C | -20°C to 80°C | <90%, non-condensing | Φ20×100mm2 | Φ15×65mm2 | control 750hz frequency) | – | – | Datasheet |
| PGL-H1-473 | 473 nm | 1~50 mW | Near TEM00 | – | 10000 | 1 | 3VDC | – | 10°C to 35°C | -20°C to 80°C | – | – | – | – | ~1.5 | 5VDC | Datasheet |
| MDL-473(FC) | 473 nm | 1~4500 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
425 NM Blue Violet Laser, Diode Laser, Blue Laser |
7 models| Model | Wavelength | Output / average power | Transverse mode | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Power stability (rms, 4 hours ± 3°C) | M2 | Warm-up time (minutes) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-424 | 425 nm | 1~30 mW | Multimode | <2.5×0.2 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | Datasheet |
| MDL-E-424 | 425 nm | 1~30 mW | Multimode | <2.5×0.2 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | Datasheet |
| MDL-III-425L | 425 nm | 1~100 mW | – | <1.0 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <2%, <1%, <0.5% | <1.5 / <1.2 | <5 | Datasheet |
| MDL-III-425 | 425 nm | 1~500 mW | Multimode | <2.5×0.2 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <2%, <1%, <0.5% | – | <5 | Datasheet |
| MDL-H-425 | 425 nm | 500~1300 mW | Multimode | <2.5×0.2 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | Datasheet |
| MDL-NS-425 | 425 nm | 1~100 mW | Multimode | <2.5×0.2 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | Datasheet |
| MDL-PS-425 | 425 nm | 1~50 mW | Multimode | <2.5×0.2 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | Datasheet |
438 NM Blue Violet Diode Laser.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-438 | 438 nm | 1~500 mW | <2%, <1%, <0.5% | Multimode | <2.1×1.6 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-438(FC) | 438 nm | 1~450 mW | – | – | – | – | – | – | – | – |
440 NM Laser, Violet Blue Laser, DPSS Laser |
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-440 | 440 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-H-440 | 440 nm | 1~3 W | <2%, <1%, <0.5% | Multimode | 1.4×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
444 NM Blue Violet Diode Laser.
7 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Operating temperature (℃) | Polarization direction | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-444 | 444 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | 1.4×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-E-444 | 444 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | 1.4×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-H-444 | 444 nm | 1~3000 mW | <2%, <1%, <0.5% | Multimode | 1.4×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-F-444 | 444 nm | 3~4.5 W | – | Multimode | 1.4×0.2 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | 10-35 | – | Datasheet |
| MDL-MD-444 | 444 nm | 1~8000 mW | <2%, <1%, <0.5% | Multimode | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | 25±3 | Horizontal+ Vertical / Horizontal/ Vertical | Datasheet |
| MDL-HD-444 | 444 nm | 8~16 W | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XD-444 | 444 nm | 16~20 W | – | – | – | – | – | – | – | – | – | – | Datasheet |
470nm Blue Laser, Blue Diode Laser, Diode Laser Module |
8 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Noise of amplitude (rms, 20Hz-20MHz) | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Operating temperature (℃) | Polarization direction | Power stability (rms, over 4 hours) | TTL / Analog modulation | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-III-470 | 470 nm | 1~800 mW | <2%, <1%, <0.5% | <1%, <0.5% | <2.5×0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | Datasheet |
| MLL-F-470 | 470 nm | 800~1500 mW | <2%, <1%, <0.5% | <1%, <0.5% | ~2.5×0.5 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | Multimode | 10-35 | – | – | – | – | Datasheet |
| MDL-III-470 | 470 nm | 1~800 mW | <2%, <1%, <0.5% | – | <2.5×0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | Datasheet |
| MDL-F-470 | 470 nm | 800~1500 mW | – | – | ~2.5×0.5 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | Multimode | 10-35 | – | – | – | – | Datasheet |
| F-470-HS | 470 nm | 800~1500 mW | – | – | ~2.5×0.5 | <5 | – | 25±3 | PSU-III-FDA/PSU-III-LED/PSU-A-D | >10000 | Multimode | – | – | – | – | – | Datasheet |
| MDL-MD-470 | 470 nm | 1~6000 mW | <2%, <1%, <0.5% | – | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Multimode | 25±3 | Horizontal+ Vertical / Horizontal/ Vertical | – | – | – | Datasheet |
| MDL-HD-470 | 470 nm | 4~8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XD-470 | 470 nm | 8~16 W | – | – | <2.4×2.0 | <5 | – | – | PSU-N-LED/ PSU-N-FDA | 10000 | – | 10-35 | Horizontal+Vertical | <1%, <2%, <3% | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 1 year | Datasheet |
483 NM Blue Diode Laser.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-483L | 483 nm | 1~50 mW | <2%, <1%, <0.5% | <2 / <1.5 | ~1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-483(FC) | 483 nm | 1~45 mW | – | – | – | – | – | – | – | – |
495 NM Blue Diode Laser.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-495L | 495 nm | 1~50 mW | <2%, <1%, <0.5% | <2 / <1.5 | ~1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-495(FC) | 495 nm | 1~45 mW | – | – | – | – | – | – | – | – |
505 NM Green Laser, Diode Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XS-505 | 505 nm | 1~50 mW | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-505-SM | 505 nm | 1~30 mW | – | – | – | – | – | – | – | – | |
| MDL-NS-505 | 505 nm | 1~20 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
Infrared Laser AT 2130 NM
1 model| Model | Wavelength | Output / average power | Beam divergence, full angle (mrad) | Power stability (rms, 4 hours±3℃) | Warm-up time (minutes) | during operations, etc. | Operating temperature (℃) | Power supply | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|
| OEM-IR-2130 | 2130 nm | 1~6 W | <3 | <5%, <3% | <10 | Cooled method / Water cooled | 10-30 | PSU-MIR (3U) | >10000 | Datasheet |
10.5 ΜM Infrared Laser, Solid State Laser |
2 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-10500-DFB | 10500 nm | 1~5 mW | |
| MDL-XN-10500 | 10500 nm | 1~200 mW |
Infrared Laser, 1020 NM Infrared Laser Module, Infrared Diode Lasers.
4 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1020 | 1020 nm | 1~500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-XF-1020 | 1020 nm | 500~3000 mW | – | Multimode | <3.0 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | 10-35 | Datasheet |
| FC-1020 | 1020 nm | 1~8 W | – | – | – | – | – | – | – | – | – | |
| MIL-1020(FC) | 1020 nm | 1~4500 mW | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1035 NM Infrared Laser Module, Infrared DPSS Lasers.
7 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-III-1035 | 1035 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <1%, <0.5% | <3.0 | <5 | Conduction | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MLL-H-1035 | 1035 nm | 1~2 W | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1035 | 1035 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | – | <3.0 | <5 | Conduction | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-H-1035 | 1035 nm | 1~2 W | <2%, <1%, <0.5% | Multimode | – | <3.0 | <5 | Air cooled | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-XF-1035 | 1035 nm | 2~3 W | – | – | – | – | – | – | – | – | Datasheet |
| FC-1035 | 1035 nm | 1~8 W | – | – | – | – | – | – | – | – | |
| MIL-1035(FC) | 1035 nm | 1~4500 mW | – | – | – | – | – | – | – | – |
Infrared Diode Laser, 1130 NM Infrared Diode Lasers, High Power Diode Laser System.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1130 | 1130 nm | 1~2000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-XF-1130 | 1130 nm | 2~5 W | – | – | – | – | – | – | – | – | Datasheet |
| MDL-1130(FC) | 1130 nm | 1 mW~4.3 W | – | – | – | – | – | – | – | – |
Infrared Diode Laser, 1140 NM Infrared Diode Lasers, High Power Diode Laser System.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1140 | 1140 nm | 1~2000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-XF-1140 | 1140 nm | 2~5 W | – | – | – | – | – | – | – | – | Datasheet |
| MDL-1140(FC) | 1140 nm | 1 mW~4.3 W | – | – | – | – | – | – | – | – |
Infrared Diode Laser, 1150 NM Infrared Diode Lasers, High Power Diode Laser System.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1150 | 1150 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-1150(FC) | 1150 nm | 1~800 mW | – | – | – | – | – | – | – | – |
Infrared Laser, 1160 NM Infrared Lasers, High Power Diode Laser System
2 models| Model | Wavelength | Output / average power | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XF-1160 | 1160 nm | 1~5000 mW | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-1160(FC) | 1160 nm | 1 mW~4.3 W | – | – | – | – | – | – | – |
Infrared Laser, 1190 NM Infrared Laser Module, Infrared DPSS Lasers.
4 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-F-1190 | 1190 nm | 1~3000 mW | <2%, <1%, <0.5% | Multimode | <1%, <0.5% | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-F-1190 | 1190 nm | 1~3000 mW | – | Multimode | – | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| FC-1190 | 1190 nm | 1~8 W | – | – | – | – | – | – | – | – | – | |
| MIL-1190(FC) | 1190 nm | 1~3600 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser, 1208 NM Infrared Diode Lasers, High Power Diode Laser System.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Polarization direction | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1208 | 1208 nm | 1~1500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-HD-1208 | 1208 nm | 1~3500 mW | <2%, <1%, <0.5% | Multimode | <5 | – | – | – | PSU-N-FDA/PSU-N-LED | >10000 | Horizontal+ Vertical | 25±3 | Datasheet |
| MDL-1208(FC) | 1208 nm | 1 mW~1.4 W | – | – | – | – | – | – | – | – | – | – |
Infrared Laser,1320 NM Infrared Diode Lasers,infrared Diode Laser System.
7 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Power stability(rms, over 4 hours) | Warm-up time | Warranty (years) | Operating voltage(PSU-V-OEM) | Operating voltage(PSU-I-OEM) | Connection | Operating temperature | Storage temperature | Humidity | Dimensions of laser head | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1320-SLD | 1320 nm | 1~34 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1320 | 1320 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-1320 | 1320 nm | 800~3000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1320-SLD-SM | 1320 nm | 1~34 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-V-H-FC-1320 | 1320 nm | 1~500 mW | – | Multimode | <10 | – | – | – | – | 10000 | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | 92(L)×40(W)×40(H)mm3 | Datasheet |
| PGL-V-H-1320 | 1320 nm | 1~1000 mW | – | Multimode | <10 | – | – | – | – | 10000 | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | 92(L)×40(W)×40(H)mm3 | Datasheet |
| MDL-1320(FC) | 1320 nm | 1~2600 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1335 NM Infrared Laser Module, Infrared DPSS Lasers
3 models| Model | Wavelength | Output / average power | Transverse mode | M2 | Beam divergence (mrad) | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Modulation optional | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIL-H-1335 | 1335 nm | 1~500 mW | TEM00 | <1.5 | <2.0 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | Datasheet |
| FC-1335 | 1335 nm | 1~450 mW | – | – | – | – | – | – | – | – | – | |
| MIL-1335(FC) | 1335 nm | 1~450 mW | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1338 NM Infrared Laser Module, Infrared DPSS Lasers
3 models| Model | Wavelength | Output / average power | Transverse mode | M2 | Beam divergence (mrad) | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Modulation optional | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIL-H-1338 | 1338 nm | 1~500 mW | TEM00 | <1.5 | <2.0 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | Datasheet |
| FC-1338 | 1338 nm | 1~450 mW | – | – | – | – | – | – | – | – | – | |
| MIL-1338(FC) | 1338 nm | 1~450 mW | – | – | – | – | – | – | – | – | – |
Infrared Laser,1370 NM Infrared Diode Lasers,infrared Diode Laser System.
5 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1370L | 1370 nm | 1~15 mW | <2%, <1%, <0.5% | Near TEM00 | <2.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-1370-SM | 1370 nm | 1~15 mW | – | – | – | – | – | – | – | – | |
| MDL-III-1370DFB-SM | 1370 nm | 1~15 mW | – | – | – | – | – | – | – | – | |
| FC-OEM-1370 | 1370 nm | 1~15 mW | – | – | – | – | – | – | – | – | |
| MDL-1370(FC) | 1370 nm | 1~10 mW | – | – | – | – | – | – | – | – |
Infrared Laser,1380 NM Infrared Diode Lasers,infrared Diode Laser System.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1380 | 1380 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-1380(FC) | 1380 nm | 1~700 mW | – | – | – | – | – | – | – | – |
Infrared Laser,1420 NM Infrared Diode Lasers,infrared Diode Laser System.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1420 | 1420 nm | 1~500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-H-1420 | 1420 nm | 500~1500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-1420(FC) | 1420 nm | 1~1300 mW | – | – | – | – | – | – | – | – |
1490nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| FC-OEM-1490 | 1490 nm | 1~15 mW | |
| MDL-III-1490-SM | 1490 nm | 1~15 mW | |
| MDL-III-1490DFB-SM | 1490 nm | 1~15 mW |
1540nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| FC-OEM-1540 | 1540 nm | 1~15 mW | |
| MDL-III-1540-SM | 1540 nm | 1~15 mW | |
| MDL-III-1540DFB-SM | 1540 nm | 1~15 mW |
Infrared Laser, 1568 NM Infrared Laser Module, Infrared DPSS Lasers.
5 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MLL-III-1568-SM | 1568 nm | 1~15 mW | |
| TEM-F-1568DFB | 1568 nm | 1~20 mW | |
| MDL-III-1568-SM | 1568 nm | 1~15 mW | |
| MDL-III-1568DFB-SM | 1568 nm | 1~15 mW | |
| FC-OEM-1568 | 1568 nm | 1~15 mW |
Infrared Laser, 1570 NM Infrared Laser Module, Infrared DPSS Lasers.
4 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MLL-III-1570-SM | 1570 nm | 1~15 mW | |
| MDL-III-1570-SM | 1570 nm | 1~15 mW | |
| MDL-III-1570DFB-SM | 1570 nm | 1~15 mW | |
| FC-OEM-1570 | 1570 nm | 1~15 mW |
Infrared Laser, 1580 NM Infrared Laser Module, Infrared DPSS Lasers.
8 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MLL-III-1580-SM | 1580 nm | 1~15 mW | |
| TEM-F-1580DFB | 1580 nm | 1~20 mW | |
| MDL-III-1580DFB-SM | 1580 nm | 1~15 mW | |
| MDL-III-1580-SLD | 1580 nm | 1~17 mW | |
| MDL-III-1580-SM | 1580 nm | 1~15 mW | |
| MDL-III-1580-SLD-SM | 1580 nm | 1~17 mW | |
| FC-OEM-1580 | 1580 nm | 1~15 mW | |
| MIL-1580(FC) | 1580 nm | 1~20 mW |
1590nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1590DFB-SM | 1590 nm | 1~15 mW |
1610nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1610DFB-SM | 1610 nm | 1~15 mW |
1620nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1620DFB-SM | 1620 nm | 1~5 mW |
1625nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1625DFB-SM | 1625 nm | 1~5 mW |
1627nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1627DFB-SM | 1627 nm | 1~5 mW |
1647nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1647DFB-SM | 1647 nm | 1~5 mW |
1649nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1649DFB-SM | 1649 nm | 1~5 mW |
1650nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1650DFB-SM | 1650 nm | 1~5 mW |
1651nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1651DFB-SM | 1651 nm | 1~5 mW |
1653nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1653DFB-SM | 1653 nm | 1~5 mW |
1654nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1654DFB-SM | 1654 nm | 1~5 mW |
1680nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1680DFB-SM | 1680 nm | 1~5 mW |
1683nm DFB Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1683DFB-SM | 1683 nm | 1~5 mW |
1710 NM IR Laser, Infrared Diode Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1710 | 1710 nm | 1~500 mW | <3%, <2%, <1% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | 10000 | 1 year | Datasheet |
Infrared Laser, 1720 NM Infrared Laser Module, Infrared DPSS Lasers.
4 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1720 | 1720 nm | 1~1000 mW | <3%, <2%, <1% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | 10000 | 1 year | Datasheet |
| FC-1720 | 1720 nm | 1~2.5 W | – | – | – | – | – | – | – | – | |
| FC-W-1720B | 1720 nm | 20~80 W | – | – | – | – | – | – | – | – | |
| MIL-1720(FC) | 1720 nm | 1~850 mW | – | – | – | – | – | – | – | – |
Infrared Diode Laser AT 1920 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1920 | 1920 nm | 1~500 mW | <3%, <2%, <1% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
| MDL-1920(FC) | 1920 nm | 1~450 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser AT 2160 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-2160 | 2160 nm | 1~400 mW | <1%, <2%, <3% | Multimode | <5. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
| MDL-2160(FC) | 2160 nm | 1~350 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser AT 2180 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-2180 | 2180 nm | 1~400 mW | <3%, <2%, <1% | Multimode | <5. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
| MDL-2180(FC) | 2180 nm | 1~350 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser AT 2230 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-2230 | 2230 nm | 1~400 mW | <3%, <2%, <1% | Multimode | <5. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
| MDL-2230(FC) | 2230 nm | 1~350 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser AT 2260 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-2260 | 2260 nm | 1~400 mW | <2%, <1%, <0.5% | Multimode | <5.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-2260(FC) | 2260 nm | 1~350 mW | – | – | – | – | – | – | – | – |
Infrared Laser, 2600 NM Infrared Laser Module, Infrared DPSS Lasers.
4 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours±3℃) | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | Rep. rate | Single pulse energy (µJ) | Warm-up time (minutes) | Beam diameter at the aperture (1/e2,mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIL-W-2700 | 2600 nm | 250~1000 mW | <5%, <3% | <11 | Air Cooled | 15-35 | RAD1PS | >10000 | – | – | – | – | Datasheet |
| TUN-W-2600~4410 | 2600 nm | 250~1000 mW | <5%, <3% | <11 | Air Cooled | 15-35 | RAD1PS | >10000 | – | – | – | – | Datasheet |
| EO-XS-2600-4410 | 2600 nm | 1~1000 mW | <5%, <3% | <5 | Air cooled | 10-35 | PSU-AOM (3U) | >10000 | 30-50kHz | 1-33.3 / 1-26.7 / 1-13.3 / 1-6.7 | <10 | – | Datasheet |
| MIL-W-2600 | 2600 nm | 250~1000 mW | <5%, <3% | – | Air Cooled | 15-35 | RAD1PS | >10000 | – | – | – | <11 | Datasheet |
Infrared Laser, 2800 NM Infrared Laser Module, Infrared DPSS Lasers.
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours±3℃) | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|
| MIL-W-2800 | 2800 nm | 250~1000 mW | <5%, <3% | <11 | Air Cooled | 15-35 | RAD1PS | >10000 | Datasheet |
Infrared Laser, 2830 NM Infrared Laser Module, Infrared DPSS Lasers.
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours±3℃) | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|
| MIL-W-2830 | 2830 nm | 250~1000 mW | <5%, <3% | <11 | Air Cooled | 15-35 | RAD1PS | >10000 | Datasheet |
3.6 ΜM Infrared Laser, CW Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XN-3600 | 3600 nm | 1~200 mW | <3%, <2%, <1% | Near TEM00 | <5.0 | <10 | Air cooled | 10-35 | PSU-H-LED | >10000 | Datasheet |
4.33 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-4330-DFB | 4330 nm | 1~15 mW |
4.56 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-4560-DFB | 4560 nm | 1~15 mW |
4.58 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-4580-DFB | 4580 nm | 1~15 mW |
5.24 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-5240-DFB | 5240 nm | 1~15 mW |
5.81 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-5810-DFB | 5810 nm | 1~15 mW |
6.64 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-6640-DFB | 6640 nm | 1~15 mW |
6.79 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-6790-DFB | 6790 nm | 1~15 mW |
7.26 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-7260-DFB | 7260 nm | 1~15 mW |
7.32 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-7320-DFB | 7320 nm | 1~15 mW |
7.4 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-7400-DFB | 7400 nm | 1~15 mW |
7.5 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-7500-DFB | 7500 nm | 1~15 mW |
7.67 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-7670-DFB | 7670 nm | 1~15 mW |
8.2 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-8200 | 8200 nm | 1~1300 mW |
8.6 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-8600 | 8600 nm | 1~1000 mW |
9.26 ΜM Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-9260-DFB | 9260 nm | 1~15 mW |
9.4μm Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-XN-9400 | 9400 nm | 1~400 mW |
Infrared Laser, 937 NM Infrared Diode Lasers, High Power Diode Laser System.
5 models| Model | Wavelength | Output / average power | Spectral linewidth | Power stability | M² | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | Warm-up time (minutes) | monitoring, | Operating temperature (℃) | Operating voltage (VDC) | Modulation option | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-OEM-937 | 937 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-937L | 937 nm | 1~200 mW | – | – | – | <2%, <1%, <0.5% | <1.5 | <1.0 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | Datasheet |
| MDL-III-937-SM | 937 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-937 | 937 nm | – | High Stability Infrared Laser nm | <2%, <1%, <0.5% | 1.5 | – | – | <1.0 | – | – | – | >10000 | Near TEM00 | <1%, <0.5% | <5 | inspection | 10-35 | 12V/4A | AMOD (Analog) DC-100kHz | Datasheet |
| MDL-937(FC) | 937 nm | 1~180 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 968 NM Infrared Diode Lasers, High Power Diode Laser System.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-968 | 968 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-968(FC) | 968 nm | 1~900 mW | – | – | – | – | – | – | – | – |
860 NM IR Laser, Infrared Diode Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-860 | 860 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-H-860 | 860 nm | 1~4 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-XF-860 | 860 nm | 4~6 W | – | – | – | – | – | – | – | – | Datasheet |
870 NM IR Laser, Infrared Diode Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-870L | 870 nm | 1~10 mW | <2%, <1%, <0.5% | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
3.9 ΜM MID Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XN-3900 | 3900 nm | 1~300 mW | <3%, <2%, <1% | Near TEM00 | <5.0 | <10 | Air cooled | 10-35 | PSU-H-LED | >10000 | Datasheet |
4 ΜM MID Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XN-4000 | 4000 nm | 1~600 mW | <3%, <2%, <1% | Near TEM00 | <5.0 | <10 | Air cooled | 10-35 | PSU-H-LED | >10000 | Datasheet |
4.4 ΜM MID Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XN-4400 | 4400 nm | 1~1000 mW | <3%, <2%, <1% | Near TEM00 | <5.0 | <10 | Air cooled | 10-35 | PSU-H-LED | >10000 | Datasheet |
4.6 ΜM MID Infrared Laser, Solid State Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XN-4600 | 4600 nm | 1~1500 mW | <3%, <2%, <1% | Near TEM00 | <5.0 | <10 | Air cooled | 10-35 | PSU-H-LED | >10000 | Datasheet |
637 NM RED Diode Laser |
12 models| Model | Wavelength | Output / average power | Power stability | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | monitoring, | Operating temperature (℃) | Operating voltage (VDC) | Modulation option | Expected lifetime (hours) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Output power | Polarization direction | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Long Coherence Length | 637 nm | 1-50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-637 | 637 nm | Integrated electronics | – | <2%, <1%, <0.5% | Near TEM00 | <1%, <0.5% | <1.2 | <1.0 | <5 | inspection | 10-35 | 12V/4A | AMOD (Analog) DC-100kHz | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-637 | 637 nm | 1-200 mW | <0.5% | – | – | – | <1.5 / <1.2 | <1.0 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-637 | 637 nm | – | – | <2%, <1%, <0.5% | Multimode | – | – | <2.0×2.0 | <5 | – | 25±3 | – | – | >10000 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | 1-2000 | Horizontal/ Vertical | – | – | – | – | – | – | – | Datasheet |
| MDL -HD- 637 | 637 nm | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| OEM Laser Module | 637 nm | 1-100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL Series | 637 nm | Compact laser module | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| Narrow Linewidth | 637 nm | 1-50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-637-SM | 637 nm | SM Fiber output laser | – | <2%, <1%, <0.5% | – | – | <1.5 / <1.2 | <1.0 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | – | – | – | – | – | – | – | – | – | Datasheet |
| Nanosecond Pulsed | 637 nm | 1-200 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| Picosecond Pulsed | 637 nm | 1-50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-637 | 637 nm | 1-130 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | -10°C to +45°C | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | Datasheet |
665nm RED Laser, RED Diode Laser |
6 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Polarization direction | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-665 | 665 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | Datasheet |
| MDL-H-665 | 665 nm | 800~2000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-MD-665 | 665 nm | 1~1500 mW | <2%, <1%, <0.5% | Multimode | ~3.1×2.5 / ~2.5×2.5 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Horizontal+ Vertical / Horizontal/ Vertical | 25±3 | Datasheet |
| MDL-HD-665 | 665 nm | 1.5~3 W | <2%, <1%, <0.5% | Multimode | ~2.5×2.5 | <5 | – | – | PSU-N-FDA/PSU-N-LED | >10000 | Horizontal+ Vertical | 25±3 | Datasheet |
| MDL-XD-665 | 665 nm | 3~4.5 W | <2%, <1%, <0.5% | Multimode | <3.5×4.0 | <5 | – | – | PSU-N-FDA/PSU-N-LED | >10000 | Horizontal/ Vertical | 10-35 | Datasheet |
| MDL-NS-665 | 665 nm | 1~180 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
669nm RED Laser, Solid State Laser, DPSS RED Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-669 | 669 nm | 1~150 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
755 NM RED Laser, RED Diode Laser |
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-755 | 755 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-XF-755 | 755 nm | 1~3 W | – | – | – | – | – | – | – | – | Datasheet |
760 NM RED Laser, RED Diode Laser |
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-760 | 760 nm | 1~3000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-XF-760 | 760 nm | 3~5 W | – | – | – | – | – | – | – | – | Datasheet |
380 NM UV Diode Laser.
5 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Polarization direction | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-380 | 380 nm | 1~150 mW | <2%, <1%, <0.5% | Multimode | ~2.0×0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | Datasheet |
| MDL-H-380 | 380 nm | 150~400 mW | <2%, <1%, <0.5% | Multimode | ~4.0×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-MD-380 | 380 nm | 1~1200 mW | <2%, <1%, <0.5% | Multimode | ~4.0×1.0 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Horizontal | 25±3 | Datasheet |
| MDL-NS-380 | 380 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | ~4.0×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-380(FC) | 380 nm | 1~260 mW | – | – | – | – | – | – | – | – | – | – |
397 NM UV Diode Laser.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-397L | 397 nm | 1~100 mW | <2%, <1%, <0.5% | Near TEM00 | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-397 | 397 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | – | <2.0×0.5 | – | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
420nm Violet Blue Laser, Diode Laser, Violet Laser |
3 models| Model | Wavelength | Output / average power | Transverse mode | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|
| MDL-XS-420 | 420 nm | 1~100 mW | Multimode | <2.5×0.2 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-NS-420 | 420 nm | 1~100 mW | Multimode | <2.5×0.2 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-PS-420 | 420 nm | 1~50 mW | Multimode | <2.5×0.2 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
571 NM Yellow Laser, Solid State Laser, Yellow Laser Module |
1 model| Model | Wavelength | Output / average power | Transverse mode | M2 | Cooled method | Warm-up time (minutes) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|
| MGL-U-571-SF | 571 nm | 1~200 mW | TEM00 | ~3.0 | Air Cooled/ Water Cooled | <10 | PSU-SF | >10000 | Datasheet |
577 NM Yellow Laser, Solid State Laser, Yellow Laser Module |
11 models| Model | Wavelength | Output / average power | Transverse mode | Longitudinal mode | Spectral line width (nm) | Noise of amplitude (rms, 20Hz-20MHz) | Warm-up time (minutes) | Pointing stability over temperature (urad/°C) | Frequency shift (MHz) (over ±2°C and 8hrs) (optional) | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Power stability (rms, 4 hours , ±3°C) | M2 | Beam diameter at the aperture (1/e2, mm) | Beam divergence (mrad) | Polarization ratio | Pointing stability over temperature (μrad/°C) | Power supply (12VDC) | Operating voltage (VDC) | Shock tolerance (6ms) | Modulation optional | Power Stability (rms, 4 hours ± 3°C) | Beam divergence, full angle (mrad) | Modulation option | Storage temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MSL-FN-577 | 577 nm | 1~300 mW | TEM00 | Single | <1MHz | <1%, <0.5% | <5 | <8 | <±200 | 10-35 | PSU-H-FDA | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-U-577 | 577 nm | 1~200 mW | TEM00 | – | <0.1, <0.003 | – | <5 | – | – | 10-35 | PSU-H-FDA | >10000 | <3%, <2%, <1% | <1.2 | <1.0 | <1.5 | >100:1, Horizontal (Vertical optional) | <8 | PSU-SR-OEM (12V/25A) | – | – | – | – | – | – | – | Datasheet |
| MLL-F-577 | 577 nm | 200~300 mW | – | – | <0.1 | – | <5 | – | – | 10-35 | PSU-H-FDA | >10000 | <3%, <2% | – | ~2.0 | – | >100:1, Horizontal (Vertical optional) | – | – | PSU-SR-OEM (12V/25A) | – | – | – | – | – | – | Datasheet |
| MGL-S-577 | 577 nm | 1~30 mW | TEM00 | – | – | – | <5 | – | – | – | – | >10000 | – | – | <1.0 | <1.5 | – | – | – | – | 7g laterally, 15g vertically | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | Datasheet |
| MGL-U-577 | 577 nm | 1~500 mW | TEM00 | – | – | – | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | <3%, <2%, <1% | – | <1.0 | <1.5 | >100:1, Horizontal (Vertical optional) | <8 | PSU-SR-OEM(12V/25A) | – | – | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | Datasheet |
| MGL-F-577 | 577 nm | 500~600 mW | – | – | – | – | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | – | – | – | – | >100:1, Horizontal (Vertical optional) | – | – | – | – | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | Datasheet |
| MGL-FN-577 | 577 nm | 600~1200 mW | – | – | – | – | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | – | – | – | <1.5 | >100:1, Horizontal (Vertical optional) | <8 | – | – | – | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | Datasheet |
| MGL-FN-577-A | 577 nm | 1.2~4 W | TEMn1 | – | – | – | – | – | – | 10-35 | – | >10000 | <5%, <3% | <1.5 | – | <10 | >100:1, Horizontal (Vertical optional) | – | – | 100-240V | – | – | – | – | – | – | Datasheet |
| MGL-W-577A | 577 nm | 1.2~5 W | Near TEM00 | – | – | – | <10 | – | – | 10-35 | PSU-W-LED | >10000 | – | – | ~5.0 | – | >50:1(100:1 optional), Horizontal(Vertical optional) | – | – | – | – | – | <3%, <2%, (<1% optional) | <1.5 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | Datasheet |
| OEM-S-577-MD | 577 nm | 1~1000 mW | TEMn1 | – | – | – | <10 | – | – | – | – | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | 0-60 | Datasheet |
| MGL-N-577-AOM | 577 nm | 1~1500 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
585 NM Yellow Laser, Solid State Laser, Yellow Laser Module |
1 model| Model | Wavelength | Output / average power | Transverse mode | M2 | Cooled method | Warm-up time (minutes) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|
| MGL-U-585-SF | 585 nm | 1~100 mW | TEM00 | ~3.0 | Air Cooled/ Water Cooled | <10 | PSU-SF | >10000 | Datasheet |
435 NM Blue Violet Laser
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Noise of amplitude (rms, 20Hz-20MHz) | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-435 | 435 nm | 1~500 mW | <2%, <1%, <0.5% | <1%, <0.5% | <2.1×1.6 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| MDL-H-435 | 435 nm | 500~4000 mW | – | – | <2.5×0.2 | – | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Multimode | Datasheet |
454 NM Blue Violet Diode Laser.
10 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Polarization direction | Operating temperature (℃) | Power stability (rms, over 4 hours) | TTL / Analog modulation | Warranty | Power stability (rms, 4 hours±3℃) | Power supply (24VDC) | Modulation option | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-454 | 454 nm | 800~2000 mW | <2%, <1%, <0.5% | Multimode | ~2.5×0.5 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-454 | 454 nm | 1~8000 mW | <2%, <1%, <0.5% | Multimode | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Horizontal+ Vertical / Horizontal/ Vertical | 25±3 | – | – | – | – | – | – | Datasheet |
| MDL-HD-454 | 454 nm | 8~16 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XD-454 | 454 nm | 8~16 W | – | – | <2.4×2.0 | <5 | – | – | PSU-N-LED/ PSU-N-FDA | 10000 | Horizontal+Vertical | 10-35 | <1%, <2%, <3% | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 1 year | – | – | – | Datasheet |
| OEM-BD-455 | 454 nm | 40~50 W | – | – | ~1.2 | <5 | Air cooled | – | – | >10000 | – | 0-30 | – | – | – | <2%, <1% | PSU-PNST-OEM (24V/ 14.6A) | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL/ Analog optional | Datasheet |
| OEM-ED-455 | 454 nm | 50~60 W | – | – | ~1.2 | <5 | Air cooled | – | – | >10000 | – | 0-30 | – | – | – | <2%, <1% | PSU-PNST-OEM (24V/ 14.6A) | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL/ Analog optional | Datasheet |
| OEM-AD-455 | 454 nm | 70~90 W | – | – | ~1.2 | <5 | Air cooled | – | – | >10000 | – | 0-30 | – | – | – | <2%, <1% | PSU-PNDT-OEM (24V/ 14.6A) | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL/ Analog optional | Datasheet |
| MDL-454(FC) | 454 nm | 1~650 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-454 | 454 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | – | <5 | – | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-454L | 454 nm | 1~80 mW | <2%, <1%, <0.5% | – | – | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | Datasheet |
457 NM Blue Laser.
1 model| Model | Wavelength | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-457 | 457 nm | <2%, <1%, <0.5% | Multimode | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
462 NM Blue Violet Diode Laser.
6 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Polarization direction | Operating temperature (℃) | Power stability (rms, over 4 hours) | TTL / Analog modulation | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-462 | 462 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | Datasheet |
| MDL-F-462 | 462 nm | 800~1500 mW | – | – | – | – | – | – | PSU-H-LED/ PSU-H-FDA | – | – | – | – | – | – | Datasheet |
| MDL-MD-462 | 462 nm | 1~6000 mW | <2%, <1%, <0.5% | Multimode | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Horizontal+ Vertical / Horizontal/ Vertical | 25±3 | – | – | – | Datasheet |
| MDL-HD-462 | 462 nm | 4~8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XD-462 | 462 nm | 8~16 W | – | – | <2.4×2.0 | <5 | – | – | PSU-N-LED/ PSU-N-FDA | 10000 | Horizontal+Vertical | 10-35 | <1%, <2%, <3% | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 1 year | Datasheet |
| MDL-462(FC) | 462 nm | 1~14 W | – | – | – | – | – | – | – | – | – | – | – | – | – |
465 NM Blue Violet Diode Laser.
6 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Polarization direction | Operating temperature (℃) | Power stability (rms, over 4 hours) | TTL / Analog modulation | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-465 | 465 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | Datasheet |
| MDL-F-465 | 465 nm | 800~1500 mW | – | – | – | – | – | – | PSU-H-LED/ PSU-H-FDA | – | – | – | – | – | – | Datasheet |
| MDL-MD-465 | 465 nm | 1~6000 mW | <2%, <1%, <0.5% | Multimode | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Horizontal+ Vertical / Horizontal/ Vertical | 25±3 | – | – | – | Datasheet |
| MDL-HD-465 | 465 nm | 4~8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XD-465 | 465 nm | 8~16 W | – | – | <2.4×2.0 | <5 | – | – | PSU-N-LED/ PSU-N-FDA | 10000 | Horizontal+Vertical | 10-35 | <1%, <2%, <3% | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 1 year | Datasheet |
| MDL-465(FC) | 465 nm | 1~13500 mW | – | – | – | – | – | – | – | – | – | – | – | – | – |
488 NM Blue Diode Laser.
10 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | monitoring, | Operating temperature (℃) | Operating voltage (VDC) | Modulation option | Expected lifetime (hours) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Long Coherent Length | 488 nm | 1-70 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-488 | 488 nm | Integrated electronics | <2%, <1%, <0.5% | Near TEM00 | <1%, <0.5% | <1.2 | <1.0 | <5 | inspection | 10-35 | 12V/4A | AMOD (Analog) DC-100kHz | >10000 | – | – | – | Datasheet |
| MDL-III-488L | 488 nm | – | <2%, <1%, <0.5% | – | – | <2 / <1.5 | ~1.0 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
| MDL-III-488 | 488 nm | – | <2%, <1%, <0.5% | Multimode | – | – | ~2.5×1.0 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
| MDL-H-488 | 488 nm | – | – | Multimode | – | – | ~2.5×1.0 | – | – | – | – | – | >10000 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | Datasheet |
| MDL-MD-488 | 488 nm | Economic | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-HD-488 | 488 nm | Economic | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| OEM Laser | 488 nm | 1-150 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-488-SM | 488 nm | SM Fiber output laser | <2%, <1%, <0.5% | Multimode | – | – | ~2.5×1.0 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
| MDL-488(FC) | 488 nm | 1~1200 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
510 NM Green Diode Laser.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-510 | 510 nm | 1~50 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-XS-510 | 510 nm | 1~50 mW | – | – | – | – | – | – | – | – | |
| MDL-NS-510 | 510 nm | 1~20 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
Infrared Laser, 1047 NM Infrared Laser Module, Infrared DPSS Lasers.
12 models| Model | Wavelength | Output / average power | Pulse energy | Transverse mode | Longitudinal mode | Spectral line width (MHz) | M2 | Beam diameter at the aperture (1/e2, mm) | Beam divergence (mrad) | Polarization ratio | Warm-up time (minutes) | Pointing stability over temperature (urad/°C) | Frequency shift (MHz) (over ±2°C and 8hrs) (optional) | Operating temperature (°C) | Power supply (100-240VAC) | Operating voltage (VDC) | Expected lifetime (hours) | Noise of amplitude (rms, 20Hz-20MHz) | Power supply (12VDC) | Spectral line width (nm) | Power stability (rms, 4 hours , ±3°C) | Power stability (rms, over 4 hours) | Warm-up time(minutes) | M2 factor | Pointing stability after warm-up(mrad) | Cooled method | Operating temperature (℃) | Power supply (90-264VAC) | Warranty period | Beam diameter at the aperture 1/e2 (mm) | Rep. rate (kHz) | Beam diameter at the aperture (mm) | Pulse duration (ns) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MSL-U-1047-SU | 1047 nm | 1~500 mW | – | TEM00 | Single | <1MHz | <1.2 | <1.0 | <1.5 | >100:1, Horizontal (Vertical optional) | <5 | <8 | <±200 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-U-1047-SU | 1047 nm | 1~1000 mW | – | TEM00 | – | – | <1.5 | – | – | >100:1, Horizontal (Vertical optional) | <5 | – | – | 10-35 | PSU-H-FDA | – | >10000 | <1% | PSU-SR-OEM (12V/25A) | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-H-1047 | 1047 nm | 1~1000 mW | – | TEM00 | – | – | <1.5 | – | <2.0 | – | <5 | – | – | 10-35 | PSU-H-FDA | – | >10000 | <1% | PSU-SR-OEM (12V/25A) | <0.1 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-H-1047 | 1047 nm | 1~1000 mW | – | TEM00 | – | – | <1.5 | ~1.2 | <2.0 | >100:1, Horizontal (Vertical optional) | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-U-1047-SU | 1047 nm | 1~4 W | – | TEM00 | – | – | <1.5 | ~1.0 | – | >100:1, Horizontal (Vertical optional) | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | – | – | <3%, <2%, <1% | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-V-1047 | 1047 nm | 4~8 W | – | Near TEM00 | – | – | – | – | – | >100:1 | – | – | – | – | – | – | 10000 | – | – | – | – | <1%, <2%,<3% | <10 | <2.0 | <0.05 | Air cooled | 10~35 | PSU-AOM (3U) | 1 year | – | – | – | – | Datasheet |
| FC-1047 | 1047 nm | 1~3600 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MIL-1047(FC) | 1047 nm | 1~7200 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| AO-S-1047 | 1047 nm | 1~1300 mW | 1~250 uJ | TEM00 | – | – | – | – | – | >100:1, Horizontal (Vertical optional) | <10 | – | – | – | PSU-AOM-DL | – | >10000 | – | – | – | – | – | – | – | – | – | 10-35 | – | – | ~1.2 | – | – | – | Datasheet |
| AO-V-1047 | 1047 nm | 1~3 W | 1~2000 uJ | – | – | – | – | – | – | – | <10 | – | – | – | PSU-AOM (3U) | – | >10000 | – | – | – | – | – | – | – | – | Air cooled | 10-35 | – | – | – | 1-10 | – | – | Datasheet |
| MPL-H-1047 | 1047 nm | 1~300 mW | 50~150 uJ | TEM00 | – | – | – | – | – | – | <5 | – | – | – | PSU-H-FDA | – | >10000 | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | – | ~0.8 | – | Datasheet |
| MPL-U-1047-SU | 1047 nm | 1~300 mW | 1~150 uJ | TEM00 | – | – | – | – | – | – | <5 | – | – | – | PSU-H-FDA/ PSU-SR | – | >10000 | – | – | – | <5%, <3%, <2% | – | – | – | – | – | 10-35 | – | – | – | – | ~1.2 | ~10 | Datasheet |
Infrared Laser, 1053 NM Infrared Laser Module, Infrared DPSS Lasers.
13 models| Model | Wavelength | Output / average power | Pulse energy | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Power supply (12VDC) | Expected lifetime (hours) | Spectral line width (nm) | Beam divergence (mrad) | Power stability (rms, 4 hours , ±3℃) | Longitudinal mode | Current adjustment range | Spectral linewidth (nm) | Relative intensity noise (rms, 10Hz-3MHz) | Frequency shift (MHz) (over ±2℃and 8 hours) | Fiber connector | Fiber length(m) | Fiber jacket | Beam diameter (mm) | Polarization ratio (dB) | Cooled method | Operating temperature (℃) | Power supply (VAC) | Relative intensity noise (rms,10Hz-3MHz) | Pointing stability (urad) | Beam diameter at the aperture 1/e2 (mm) | Beam diameter at the aperture (mm) | Pulse duration (ns) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-U-1053-SU | 1053 nm | 1~1500 mW | – | TEM00 | <1% | <1.5 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-H-1053 | 1053 nm | 1~1500 mW | – | TEM00 | <1% | <1.5 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | <0.1 | <2.0 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1053-LN-L | 1053 nm | 1~10 W | – | TEM00 | – | <1.1 | – | <30 | – | – | – | >10000 | – | – | <2%, <1%, <0.5% | SLM | 1-100% | <0.004 | <0.1%, <0.05% | <±200 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | Air cooled or Water cooled | 15-30 | 110/220VAC | – | – | – | – | – | Datasheet |
| FL-1053-LN-H | 1053 nm | 10~35 W | – | TEM00 | – | TEM00, <1.1 | – | <30 | – | – | – | >10000 | – | – | <1%, <0.5% | SLM | 1-100% | <0.004 | – | – | Collimator | <3 | Metal | 4±1 (Collimator output) | >15, after PM fiber | Air cooled (≤20W) / Water cooled (≤35W) | 15-30 | 110/220VAC | <0.1%, <0.05% | <5 / <10 | – | – | – | Datasheet |
| FC-1053 | 1053 nm | 1~3600 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MIL-1053(FC) | 1053 nm | 1~7200 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MIL-H-1053 | 1053 nm | 1~1500 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MIL-U-1053-SU | 1053 nm | 1.5~4 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| TEM-F-1053SLD | 1053 nm | 1~8 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| AO-S-1053 | 1053 nm | 1~1000 mW | 1~250 uJ | TEM00 | – | – | >100:1, Horizontal (Vertical optional) | <10 | – | PSU-AOM-DL | – | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | ~1.2 | – | – | Datasheet |
| FL-1053-CW | 1053 nm | 1~200 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MPL-H-1053 | 1053 nm | 300~450 mW | 30~50 uJ | TEM00 | – | – | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | – | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | ~1.5 | – | Datasheet |
| MPL-U-1053-SU | 1053 nm | 1~450 mW | 1~50 uJ | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | ~10 | Datasheet |
Infrared Laser, 1085 NM Infrared Laser Module,infrared Lasers.
4 models| Model | Wavelength | Output / average power | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Power supply (12VDC) | Expected lifetime (hours) | Beam diameter at the aperture (1/e2, mm) | Modulation optional | Power stability (rms, over 4 hours) | Fiber NA | Fiber Connector | Fiber Length (m) | Operating temperature (℃) | Cooling way | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-U-1085-SU | 1085 nm | 1~1000 mW | TEM00 | <1% | <1.5 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-U-1085-SU | 1085 nm | 1~1000 mW | TEM00 | – | <1.5 | – | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | ~1.0 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | – | – | – | Datasheet |
| FC-1085 | 1085 nm | 1~900 mW | – | – | – | – | <5 | – | – | – | 10000 | – | – | <1%, <2%, <3%, <5% | 0.22 | SMA905 | 1 (Other lengths are available on request) | 10~35 | By air | 1 year | Datasheet |
| MIL-1085(FC) | 1085 nm | 1~900 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1112 NM Infrared Laser Module,infrared Lasers.
7 models| Model | Wavelength | Output / average power | Transverse mode | Longitudinal mode | Spectral line width (MHz) | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam diameter at the aperture (1/e2, mm) | Beam divergence (mrad) | Polarization ratio | Warm-up time (minutes) | Pointing stability over temperature (urad /°C) | Frequency shift (MHz) (over ±2°C and 8hrs) (optional) | Operating temperature (°C) | Power supply (100-240VAC) | Operating voltage (VDC) | Expected lifetime (hours) | Power supply (12VDC) | Modulation optional | Power Stability (rms, 4 hours ± 3°C) | Pointing Stability Over Temperature (urad/°C) | Cooled method | Power stability (rms, over 4 hours) | Fiber NA | Fiber Connector | Fiber Length (m) | Operating temperature (℃) | Cooling way | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MSL-U-1112-SU | 1112 nm | 1~200 mW | TEM00 | Single | <1MHz | <1% | <1.2 | <1.0 | <1.5 | >100:1, Horizontal (Vertical optional) | <5 | <8 | <±200 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-U-1112-SU | 1112 nm | 1~100 mW | TEM00 | – | – | <1% | <1.5 | – | – | – | <5 | – | – | 10~35 | PSU-H-FDA | – | >10000 | PSU-SR-OEM (12V/25A) | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-H-1112 | 1112 nm | 1~500 mW | TEM00 | – | – | – | <1.5 | ~1.2 | <2.0 | >100:1, Horizontal (Vertical optional) | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-U-1112-SU | 1112 nm | 500~2000 mW | TEM00 | – | – | – | <1.5 | ~1.0 | – | – | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-T-1112 | 1112 nm | 1200~7000 mW | TEM00 | – | – | – | <1.5 | – | – | >50:1(100:1 optional), Horizontal(Vertical optional) | <10 | – | – | 10-35 | PSU-W-FDA/PSU-W-LED | – | >10000 | – | – | <3%, <2%, (<1% optional) | <20 | Air cooled | – | – | – | – | – | – | – | Datasheet |
| FC-1112 | 1112 nm | 1~1800 mW | – | – | – | – | – | – | – | – | <5 | – | – | – | – | – | 10000 | – | – | – | – | – | <1%, <2%, <3%, <5% | 0.22 | SMA905 | 1 (Other lengths are available on request) | 10~35 | By air | 1 year | Datasheet |
| MIL-1112(FC) | 1112 nm | 1~1800 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1122 NM Infrared Laser Module,infrared Lasers.
6 models| Model | Wavelength | Output / average power | Transverse mode | Longitudinal mode | Spectral line width (MHz) | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam diameter at the aperture (1/e2, mm) | Beam divergence (mrad) | Polarization ratio | Warm-up time (minutes) | Pointing stability over temperature (urad /°C) | Frequency shift (MHz) (over ±2°C and 8hrs) (optional) | Operating temperature (°C) | Power supply (100-240VAC) | Operating voltage (VDC) | Expected lifetime (hours) | Power supply (12VDC) | Modulation optional | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MSL-U-1122-SU | 1122 nm | 1~250 mW | TEM00 | Single | <1MHz | <1% | <1.2 | <1.0 | <1.5 | >100:1, Horizontal (Vertical optional) | <5 | <8 | <±200 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | Datasheet |
| MLL-U-1122-SU | 1122 nm | 1~300 mW | TEM00 | – | – | <1% | <1.5 | – | – | – | <5 | – | – | 10~35 | PSU-H-FDA | – | >10000 | PSU-SR-OEM (12V/25A) | – | Datasheet |
| MIL-H-1122 | 1122 nm | 1~1000 mW | TEM00 | – | – | – | <1.5 | ~1.2 | <2.0 | >100:1, Horizontal (Vertical optional) | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | Datasheet |
| MIL-U-1122-SU | 1122 nm | 1000~1200 mW | TEM00 | – | – | – | <1.5 | ~1.0 | – | – | <5 | – | – | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | Datasheet |
| FC-1122 | 1122 nm | 1~1080 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MIL-1122(FC) | 1122 nm | 1~6300 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1177 NM Infrared Laser Module,infrared Lasers.
3 models| Model | Wavelength | Output / average power | Transverse mode | M2 | Beam diameter at the aperture (1/e2, mm) | Beam divergence (mrad) | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Modulation optional | Power supply (100-240VAC) | Expected lifetime (hours) | Power stability (rms, over 4 hours) | Fiber NA | Fiber Connector | Fiber Length (m) | Operating temperature (℃) | Cooling way | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIL-H-1177 | 1177 nm | 1~400 mW | TEM00 | <1.5 | ~1.2 | <2.0 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | – | – | – | – | – | – | – | Datasheet |
| FC-1177 | 1177 nm | 1~360 mW | – | – | – | – | – | <5 | – | – | – | 10000 | <1%, <2%, <3%, <5% | 0.22 | SMA905 | 1 (Other lengths are available on request) | 10~35 | By air | 1 year | Datasheet |
| MIL-1177(FC) | 1177 nm | 1~360 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1413 NM Infrared Laser Module, DPSS Infrared Lasers.
3 models| Model | Wavelength | Output / average power | Transverse mode | M2 | Beam divergence (mrad) | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Modulation optional | Power supply (100-240VAC) | Expected lifetime (hours) | Power stability (rms, 4 hours ± 3°C) | Fiber connector | Cooled method | Operating temperature (℃) | Operating voltage (VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIL-H-1413 | 1413 nm | 1~300 mW | TEM00 | <1.5 | <2.0 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | – | – | – | – | – | Datasheet |
| FC-1413 | 1413 nm | 1~270 mW | – | – | – | – | – | – | – | – | >10000 | <2%, <1%, <0.5% | SMA905, FC/PC optional | Air cooled | 10-35 | 100-240 | Datasheet |
| MIL-1413(FC) | 1413 nm | 1~270 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1444 NM Infrared Laser Module, DPSS Infrared Lasers.
5 models| Model | Wavelength | Output / average power | Pulse energy | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Power supply (12VDC) | Expected lifetime (hours) | Beam diameter at the aperture (1/e2, mm) | Modulation optional | Power stability (rms, 4 hours ± 3°C) | Fiber connector | Cooled method | Operating temperature (℃) | Operating voltage (VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-U-1444-SU | 1444 nm | 1~400 mW | – | TEM00 | <1% | <1.5 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | – | – | – | – | – | Datasheet |
| MIL-U-1444-SU | 1444 nm | 1~400 mW | – | TEM00 | – | <1.5 | – | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | ~1.0 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | – | Datasheet |
| FC-1444 | 1444 nm | 1~360 mW | – | – | – | – | – | – | – | – | – | >10000 | – | – | <2%, <1%, <0.5% | SMA905, FC/PC optional | Air cooled | 10-35 | 100-240 | Datasheet |
| MIL-1444(FC) | 1444 nm | 1~360 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MPL-U-1444-SU | 1444 nm | 1~10 mW | 1~3 uJ | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
Infrared Laser,1470 NM Infrared Diode Lasers,infrared Diode Laser System.
7 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | Transverse mode | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-OEM-1470 | 1470 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-1470(FC) | 1470 nm | 1~3000 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-H-1470 | 1470 nm | 500~1500 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1470 | 1470 nm | 1~500 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-1470DFB-SM | 1470 nm | 1~15 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-1470R | 1470 nm | 1~200 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1470-SM | 1470 nm | 1~15 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
Infrared Laser,1532 NM Infrared Diode Lasers, Infrared Fiber Coupled Laser System.
6 models| Model | Wavelength | Output / average power | Spectral line width (nm) | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-OEM-1532 | 1532 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | |
| MDL-H-1532 | 1532 nm | 1~800 mW | <0.5 | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-XF-1532 | 1532 nm | 800~2000 mW | – | – | Multimode | <3.0 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | 10-35 | Datasheet |
| MDL-III-1532-SM | 1532 nm | 1~15 mW | <0.5 | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-III-1532DFB-SM | 1532 nm | 1~15 mW | <0.5 | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-1532(FC) | 1532 nm | 1~3000 mW | – | – | – | – | – | – | – | – | – | – |
Infrared Laser,1550 NM Infrared Diode Lasers, Infrared Laser System.
9 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | Transverse mode | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-OEM-1550 | 1550 nm | 1~180 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-H-1550 | 1550 nm | 600~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1550 | 1550 nm | 1~600 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-1550DFB-SM | 1550 nm | 1~180 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-1550L | 1550 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1550R | 1550 nm | 1~200 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1550-SM | 1550 nm | 1~180 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-N-1550 | 1550 nm | 1~3.5 W | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-1550(FC) | 1550 nm | 1~3000 mW | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser AT 1910 NM.
1 model| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1910 | 1910 nm | 1~500 mW | <3%, <2%, <1% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
Infrared Diode Laser AT 2000 NM.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-2000 | 2000 nm | 1~300 mW | <2%, <1%, <0.5% | Multimode | <5.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-XF-2000 | 2000 nm | 300~1000 mW | – | Multimode | <5.0 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | 10-35 | Datasheet |
| MDL-2000(FC) | 2000 nm | 1~350 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser AT 2200 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-2200 | 2200 nm | 1~400 mW | <3%, <2%, <1% | Multimode | <5. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
| MDL-2200(FC) | 2200 nm | 1~350 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser, 793 NM Infrared Diode Lasers, High Power Diode Laser System.
4 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Fiber Core Diameter (um) | Fiber Connector | Fiber lengths | Fiber Jacket | Power stability (rms, 4 hours±3℃) | Operating temperature (℃) | Operating voltage (VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-793 | 793 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | Datasheet |
| MDL-H-793 | 793 nm | 2500~4000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | Datasheet |
| OEM-I-793-BG | 793 nm | 200 W | – | – | – | <5 | Air cooled | – | – | >10000 | 200, 0.22NA | SMA905 | 4m | PVC, Metal optional | <2%, <1%, <0.5% | -30-60 | 100-240 | Datasheet |
| MDL-793(FC) | 793 nm | 1~3600 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser, 825 NM Infrared Diode Lasers.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-825 | 825 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-825(FC) | 825 nm | 1 mW~2 W | – | – | – | – | – | – | – | – | |
| MDL-III-825 | 825 nm | 1~1500 mW | – | – | – | – | – | – | – | – |
Infrared Laser, 885 NM Infrared Diode Lasers.
4 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-885L | 885 nm | 1~5 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| MDL-III-885 | 885 nm | 1~1000 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Datasheet |
| MDL-H-885 | 885 nm | 1~2 W | <2%, <1%, <0.5% | – | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Multimode | Datasheet |
| MDL-885(FC) | 885 nm | 1~1200 mW | – | – | – | – | – | – | – | – | – |
Infrared Laser, 905 NM Infrared Diode Pulse Lasers, High Power Diode Laser System.
6 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-905L | 905 nm | 1~70 mW | <2%, <1%, <0.5% | Near TEM00 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-905 | 905 nm | 1~400 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-905-SM | 905 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-P-905 | 905 nm | >130 W | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-905 | 905 nm | 1~150 mW | <2%, <1%, <0.5% | Near TEM00 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-PS-905 | 905 nm | 1~30 mW | <2%, <1%, <0.5% | Near TEM00 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
Infrared Laser, 946 NM Infrared Laser Module, DPSS Infrared Lasers.
12 models| Model | Wavelength | Output / average power | Pulse energy | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Power supply (12VDC) | Expected lifetime (hours) | Spectral line width (nm) | Beam divergence (mrad) | Beam diameter at the aperture (1/e2, mm) | Polarization ratio | Power stability (rms, 4 hours , ±3°C) | Pulse duration | Power stability (rms, 4 hours ± 3°C) | Operating temperature (℃) | Operating voltage (VDC) | Beam diameter at the aperture 1/e2 (mm) | Beam diameter at the aperture (mm) | Pulse duration (ns) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-U-946-SU | 946 nm | 1~300 mW | – | TEM00 | <1% | <1.5 | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-H-946 | 946 nm | 300~800 mW | – | TEM00 | <1% | <1.5 | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | <0.1 | <2.0 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-H-946 | 946 nm | 1~800 mW | – | TEM00 | – | <1.5 | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | <2.0 | ~1.2 | >100:1, Horizontal (Vertical optional) | – | – | – | – | – | – | – | – | Datasheet |
| MIL-U-946-SU | 946 nm | 800~1500 mW | – | TEM00 | – | <1.5 | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | – | ~1.0 | – | <3%, <2% | – | – | – | – | – | – | – | Datasheet |
| MIL-W-946 | 946 nm | 1.5~5 W | – | TEM00 | – | <1.5 | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | <2.0 | ~1.2 | >100:1, Horizontal (Vertical optional) | – | – | – | – | – | – | – | – | Datasheet |
| FC-946 | 946 nm | 1~1350 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MIL-946(FC) | 946 nm | 1~4500 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-946 | 946 nm | 1~10 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| AO-Mini-946 | 946 nm | 100~500 mW | 100~150 uJ | TEM00 | – | – | <10 | – | – | – | >10000 | – | – | – | – | – | 20-50 | <5%, <3%, <2% | 10-35 | 12V/29A | – | – | – | Datasheet |
| AO-S-946 | 946 nm | 1~150 mW | 1~40 uJ | TEM00 | – | – | <10 | – | PSU-AOM-DL | – | >10000 | – | – | – | >100:1, Vertical (Horizontal optional) | – | – | – | 10-35 | – | ~1.2 | – | – | Datasheet |
| MPL-S-946 | 946 nm | 1~100 mW | 1~50 uJ | TEM00 | – | – | – | – | PSU-SR | – | >10000 | – | – | – | – | <5%, <3%, <2% | – | – | 10-35 | – | – | ~1.0 | – | Datasheet |
| MPL-U-946-SU | 946 nm | 1~150 mW | 1~20 uJ | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | ~5 | Datasheet |
622 NM RED Diode Laser.
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-H-622 | 622 nm | 1~50 mW |
627 NM RED Diode Laser.
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-627 | 627 nm | 1~300 mW | <2%, <1%, <0.5% | Multimode | <3.0×0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
690 NM RED Diode Laser.
5 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-690R | 690 nm | 1~200 mW | <3%, <2%, <1% | Round | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| MDL-III-690L | 690 nm | 1~250 mW | <2%, <1%, <0.5% | – | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 / <1.2 | Datasheet |
| MDL-III-690 | 690 nm | 1~1300 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| FC-690 | 690 nm | 1~3 W | – | – | – | – | – | – | – | – | – | |
| MRL-690(FC) | 690 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – |
705 NM RED Diode Laser.
7 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-705 | 705 nm | 1~10 mW | – | – | – | – | – | – | – | – | |
| MDL-E-705 | 705 nm | 1~10 mW | – | – | – | – | – | – | – | – | |
| MDL-XS-705 | 705 nm | 1~25 mW | – | – | – | – | – | – | – | – | |
| MDL-III-705L | 705 nm | 1~25 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-705-SM | 705 nm | 1~15 mW | – | – | – | – | – | – | – | – | |
| MDL-NS-705 | 705 nm | 1~25 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-705(FC) | 705 nm | 1~20 mW | – | – | – | – | – | – | – | – |
Infrared Laser,750 NM Infrared Diode Lasers,infrared Diode Laser System.
5 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-750-SLD | 750 nm | 1~12 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-750 | 750 nm | 1~2000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-H-750 | 750 nm | 2~5 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-III-750-SLD-SM | 750 nm | 1~12 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-750(FC) | 750 nm | 1~4000 mW | – | – | – | – | – | – | – | – |
545 NM Green Laser.
2 models| Model | Wavelength | Output / average power | Spectral linewidth | Transverse mode | Warm-up time (minutes) | Storage temperature (℃) | Expected lifetime (hours) | Pointing stability over temperature (urad/°C) | Operating temperature (°C) | Power supply (100-240VAC) | Operating voltage (VDC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OEM-S-545-MD | 545 nm | 1~1000 mW | – | TEMn1 | <10 | 0-60 | >10000 | – | – | – | – | Datasheet |
| MLL-FN-543.5 | 543.5 nm | 1~100 mW | <0.003 nm | TEM00 | <5 | – | >10000 | <8 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | Datasheet |
780 NM Infrared Laser.
11 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-780(FC) | 780 nm | 1~2000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | |
| MDL-C-780 | 780 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-XS-780 | 780 nm | 1~80 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-III-780L | 780 nm | 1~80 mW | <2%, <1%, <0.5% | – | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 | Datasheet |
| MDL-III-780 | 780 nm | 1~2000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| MDL-H-780 | 780 nm | 2~4 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-III-780-SM | 780 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| FC-OEM-780 | 780 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | |
| MDL-E-780 | 780 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-NS-780 | 780 nm | 1~80 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-PS-780 | 780 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
Infrared Laser, 1050 NM Infrared Laser Module, Infrared DPSS Lasers.
5 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours , ±3℃) | Transverse mode | Longitudinal mode | Current adjustment range | Relative intensity noise (rms, 10Hz-3MHz) | Frequency shift (MHz) (over ±2℃and 8 hours ) | M2 | Fiber connector | Fiber length(m) | Fiber jacket | Beam diameter (mm) | Polarization ratio (dB) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (VAC) | Expected lifetime (hours) | Spectral linewidth (nm) | Frequency shift (MHz) (over ±2℃and 8 hours) | Line width(nm) | Fiber length (m) | Polarization state | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1050-SLD | 1050 nm | 1~17 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1050-SLD-SM | 1050 nm | 1~17 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| FL-1050-SLM | 1050 nm | 1~10 W | <2%, <1%, <0.5% | TEM00 | SLM | 1-100% | <0.3%, <0.1%, (<0.05% optional) | <±200 | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | – | – | – | – | – | Datasheet |
| FL-1050-LN-L | 1050 nm | 1~10 W | <2%, <1%, <0.5% | TEM00 | SLM | 1-100% | <0.1%, <0.05% | – | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | <0.004 | <±200 | – | – | – | Datasheet |
| FL-1050-CW | 1050 nm | 1~100 W | – | – | – | – | – | – | – | FC/APC, Collimator optional | – | PVC, Metal optional | 4±1 (Collimator output) | – | <15 | Air cooled | 15-35 | 110/220VAC | >10000 | – | – | <2nm | 1 | Random | Datasheet |
1270nm DFB Laser, Infrared Laser, DPSS Laser |
6 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-1270(FC) | 1270 nm | 1~4500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | |
| MDL-H-1270 | 1270 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-F-1270 | 1270 nm | 1~5 W | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1270-SM | 1270 nm | 1~10 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-III-1270DFB-SM | 1270 nm | 1~10 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| FC-OEM-1270 | 1270 nm | 1~10 mW | – | – | – | – | – | – | – | – |
1700 NM IR Laser, Infrared Diode Laser |
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1700 | 1700 nm | 1~100 mW | <1%, <2%, <3% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1KHz 1KHz-10KHz, 10KHz-30KHz optional | 10000 | 1 year | Datasheet |
| MDL-1700(FC) | 1700 nm | 1~80 mW | – | – | – | – | – | – | – | – | – |
1850 NM IR Laser, Infrared Diode Laser |
2 models| Model | Wavelength | Output / average power | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|
| MDL-1850(FC) | 1850 nm | 1~600 mW | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | |
| MDL-F-1850 | 1850 nm | 1~700 mW | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
Infrared Diode Laser AT 1940 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1930 | 1930 nm | 1~600 mW | <3%, <2%, <1% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
| MDL-H-1940 | 1940 nm | 1~600 mW | <3%, <2%, <1% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
976 NM Infrared Laser.
14 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Noise of amplitude (rms, 20Hz-20MHz) | M2 | monitoring, | Operating temperature (℃) | Operating voltage (VDC) | Modulation option | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-976(FC) | 976 nm | 1 mW~2 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-976 | 976 nm | 1~50 mW | <2%, <1%, <0.5% | Near TEM00 | <1.0 | <5 | – | – | – | >10000 | <1%, <0.5% | ~1.5 | inspection | 10-35 | 12V/4A | AMOD (Analog) DC-100kHz | – | – | – | – | – | – | – | Datasheet |
| MDL-III-976L | 976 nm | 1~200 mW | <2%, <1%, <0.5% | – | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | <1.5 | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-976 | 976 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-976 | 976 nm | 2.5~5 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-F-976 | 976 nm | 5~8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XF-976 | 976 nm | 8~12 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-976-SM | 976 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-976-A | 976 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| FC-OEM-976-B | 976 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-976 | 976 nm | 1~10 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | – | – | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | Datasheet |
| MDL-E-976 | 976 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-976 | 976 nm | 1~200 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-976 | 976 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
638 NM RED Diode Laser.
14 models| Model | Wavelength | Output / average power | Fiber Core Diameter (um) | Fiber Connector | Fiber lengths | Fiber Jacket | Power stability (rms, 4 hours±3℃) | customers’ equipment. Cooled method | Storage temperature (℃) | Modulation option | Expected lifetime (hours) | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Operating temperature (°C) | Storage temperature (°C) | Humidity (%) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| YL-I-638 | 638 nm | 1~40 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/525 | 638 nm | 2.9 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/450 | 638 nm | 6 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| YL-I-638/525/450 | 638 nm | 11 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/980/1550 | 638 nm | 13 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| YL-I-638/808/980 | 638 nm | 15 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/980/1064 | 638 nm | 16 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| YL-I-638/525/450/1064/1470 | 638 nm | 55 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| YLI-638/808/980/1470 | 638 nm | 62 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/525/450/808/1550 | 638 nm | 66 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/525/450/980/808 | 638 nm | 71 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/525/450/808/1064 | 638 nm | 74 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/808/980/1064 | 638 nm | 118 W | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | PVC, Metal optional | <2%, <1% | Air cooled | -20-50 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| PGL-LF-638 | 638 nm | 1~130 mW | – | – | – | – | – | – | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -10°C to +45°C | -20°C to +80°C | < 90 %, non-condensing | 45g | Datasheet |
642 NM RED Laser, RED Diode Laser, RED Laser Module |
21 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Cooled method | Power stability (rms, over 4 hours) | M2 factor | Operating temperature (℃) | Power supply (85-264VAC) | TTL / Analog modulation | Warranty | Polarization direction | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | Beam quality (M2) | Pointing stability after warm-up (mrad) | Power supply (90-264VAC) | Warranty period | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-642 | 642 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| TEM-LN-642 | 642 nm | 1~100 mW | <2%, <1%, <0.5% | <1%, <0.5% | <1.1 | <1.5 | <5 | 25±3 | PSU-III-FDA/PSU-III-LED/PSU-A-D | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-III-642 | 642 nm | 1~200 mW | <2%, <1%, <0.5% | <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Near TEM00 | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-III-642-SM | 642 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| TEM-F-642 | 642 nm | 1~100 mW | <2%, <1%, <0.5% | – | <1.1 | <1.5 | <5 | 25±3 | PSU-III-FDA/PSU-III-LED/PSU-A-D | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| TEM-FN-642 | 642 nm | 1~180 mW | – | – | – | <1.5 | <5 | – | – | 10000 | – | – | <2%, <1%, <0.5% | <1.1 | 25+/-3 | PSU-III-LED / PSU-III-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 1 year | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XS-642 | 642 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-642 | 642 nm | 1~200 mW | <2%, <1%, <0.5% | – | <1.5 / <1.2 | <1.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| DL-MD-642 | 642 nm | 1~2000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| DL-HD-642 | 642 nm | 2~4 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-642-SM | 642 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| FC-OEM-642 | 642 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-E-642 | 642 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-NS-642 | 642 nm | 1~200 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-PS-642 | 642 nm | 1~50 mW | <2%, <1%, <0.5% | – | <1.5 / <1.2 | <1.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-642 | 642 nm | 1~3 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-HD-642 | 642 nm | 2~4 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-642 | 642 nm | 1~2000 mW | <2%, <1%, <0.5% | – | – | – | <5 | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Multimode | – | – | – | 25±3 | – | – | – | Horizontal/ Vertical | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MRL-642(FC) | 642 nm | 1~160 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-642 | 642 nm | 1~130 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | – | – | – | – | – | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | – | – | – | – | Datasheet |
| TUN-F-638~644 | 642 nm | 1~40 mW | – | – | – | – | <5 | – | – | 10000 | TEM00 | – | <3%, <2%,<1%, | – | 10~30 | – | – | – | – | – | – | – | – | – | – | – | <1.1 | <0.05 | PSU-A-D | 1 year | Datasheet |
650 NM RED Laser, RED Diode Laser, RED Laser Module |
18 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Cooled method | Polarization direction | Operating temperature (℃) | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TEM-LN-650 | 650 nm | 1~50 mW | <2%, <1%, <0.5% | TEM00 | <1%, <0.5% | <1.1 | <1.5 | <5 | 25±3 | PSU-III-FDA/PSU-III-LED/PSU-A-D | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-III-650L | 650 nm | 1~180 mW | <2%, <1%, <0.5% | Near TEM00 | <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Conduction | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-III-650 | 650 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <1%, <0.5% | – | <3.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Conduction | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-III-650-SM | 650 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <1%, <0.5% | – | <3.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Conduction | – | – | – | – | – | – | – | – | – | Datasheet |
| TEM-F-650 | 650 nm | 1~50 mW | <2%, <1%, <0.5% | TEM00 | – | <1.1 | <1.5 | <5 | 25±3 | PSU-III-FDA/PSU-III-LED/PSU-A-D | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-650-SLD | 650 nm | 1~8 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-650 | 650 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-650L | 650 nm | 1~180 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-650R | 650 nm | 1~200 mW | <3%, <2%, <1% | Round | – | – | ~10 / ~20 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Conduction | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-650 | 650 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-MD-650 | 650 nm | 1~1500 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-HD-650 | 650 nm | 1.5~3 W | <2%, <1%, <0.5% | Multimode | – | – | ~2.5×2.5 | <5 | – | PSU-N-FDA/PSU-N-LED | >10000 | – | Horizontal+ Vertical | 25±3 | – | – | – | – | – | – | – | Datasheet |
| MDL-XD-650 | 650 nm | 3~4.5 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-650-SLD-SM | 650 nm | 1~8 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-650-SM | 650 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| FC-OEM-650 | 650 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| FC-650 | 650 nm | 1~5 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-LF-650 | 650 nm | 1~130 mW | – | – | – | – | – | – | -10°C to +45°C | – | – | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | Datasheet |
375 NM UV Diode Laser.
12 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | Polarization direction | Operating temperature (℃) | stability | Operating voltage(internal PCB) | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Dimensions of laser head (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-375(FC) | 375 nm | 1~700 mW | <2%, <1%, <0.5% | Multimode | ~2.5×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | |
| MDL-C-375 | 375 nm | 1~15 mW | <2%, <1%, <0.5% | Multimode | ~2.5×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XS-375 | 375 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | ~2.5×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-375L | 375 nm | 1~50 mW | <2%, <1%, <0.5% | Near TEM00 | <0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 / <1.2 | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-375 | 375 nm | 1~400 mW | <2%, <1%, <0.5% | Multimode | ~2.0×0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-375 | 375 nm | 400~800 mW | <2%, <1%, <0.5% | Multimode | ~2.5×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-375 | 375 nm | 1~1500 mW | <2%, <1%, <0.5% | Multimode | ~8.0×0.5 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | – | Horizontal | 25±3 | – | – | – | – | – | – | – | Datasheet |
| MDL-380 | 380 nm | 1~300 mW | <2%, <1%, <0.5% | Multimode | ~4.0×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | |
| PGL-VI-FC-375 | 375 nm | 1~30 mW | – | – | – | – | – | 10°C to 35°C | – | – | – | – | – | lifetime | 5VDC | TTL or Analog0-3V,0-5V | Cable with flying leads | -10°C to 70°C | <90 %, non-condensing | Φ56×250mm2 / (PGL-FC-375/589) | Datasheet |
| MDL-E-375 | 375 nm | 1~15 mW | <2%, <1%, <0.5% | Multimode | ~2.5×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-375 | 375 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | ~2.5×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-375 | 375 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | ~2.5×1.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
400 NM Blue Violet Diode Laser.
9 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-400(FC) | 400 nm | 1~250 mW | <2%, <1%, <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | |
| MDL-C-400 | 400 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-XS-400 | 400 nm | 1~200 mW | <2%, <1%, <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-III-400L | 400 nm | 1~300 mW | <2%, <1%, <0.5% | Near TEM00 | ~0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 / <1.2 | Datasheet |
| MDL-III-400 | 400 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <2.5×1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| MDL-H-400 | 400 nm | 1~3 W | <2%, <1%, <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-E-400 | 400 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-NS-400 | 400 nm | 1~200 mW | <2%, <1%, <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-PS-400 | 400 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | ~2.5×0.2 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
442 NM Blue Violet Diode Laser.
12 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Operating temperature (℃) | Polarization direction | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | M2 after fiber | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-442(FC) | 442 nm | 1~3500 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | |
| MDL-C-442 | 442 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-442 | 442 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-442L | 442 nm | 1~80 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-442 | 442 nm | 1~1000 mW | <2%, <1%, <0.5% | – | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | Datasheet |
| MDL-F-442 | 442 nm | 1~4 W | – | – | 1.4×0.2 / 1.4×0.2 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | Multimode | 10-35 | – | – | – | – | – | – | Datasheet |
| MDL-MD-442 | 442 nm | 1~8000 mW | <2%, <1%, <0.5% | – | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Multimode | 25±3 | Horizontal+ Vertical / Horizontal/ Vertical | – | – | – | – | – | Datasheet |
| MDL-HD-442 | 442 nm | 8~16 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XD-442 | 442 nm | 16~20 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-442-SM | 442 nm | 1~15 mW | <2%, <1%, <0.5% | – | – | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | TEM00 | – | – | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | ~1.1 | Datasheet |
| FC-OEM-442 | 442 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-E-442 | 442 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
445 NM Blue Violet Diode Laser.
24 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Operating temperature (℃) | Polarization direction | Power stability (rms, over 4 hours) | Warranty | Beam diameter at the aperture(1/e2) (mm) | Operating voltage(external PCB1) | Operating voltage(external PCB2) | Operating voltage(external PCB3) | Connection | Operating temperature | Storage temperature | Humidity | Power stability(rms, over 4 hours) | Warm-up time minutes | Operating voltage(PSU-V-OEM) | Dimensions of laser head | Operating voltage(internal PCB) | Operating voltage(internal PCB1) | Dimensions of internal PCB mm | Dimensions of internal PCB1 mm | Warranty months | Operating voltage(PSU-I-OEM) | Modulation optional | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-445(FC) | 445 nm | 1~15 W | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-C-445 | 445 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-445 | 445 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-445L | 445 nm | 1~500 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-445 | 445 nm | 1~1000 mW | <2%, <1%, <0.5% | – | <2.5×1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-F-445 | 445 nm | 1~4 W | – | – | 1.4×0.2 / 1.4×0.2 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | Multimode | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-445 | 445 nm | 1~8000 mW | <2%, <1%, <0.5% | – | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Multimode | 25±3 | Horizontal+ Vertical / Horizontal/ Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-HD-445 | 445 nm | 8~16 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XD-445 | 445 nm | 16~20 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-445-SM | 445 nm | 1~50 mW | – | – | – | <5 | – | – | – | 10000 | Multimode | 10~35 | – | <3%, <2%, <1%, <0.5% | 1 year | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-445 | 445 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| YL-I-445 | 445 nm | 1~40 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| OEM-I-445 | 445 nm | 1~13 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-D8-445 | 445 nm | 1~30 mW | – | – | <1 | – | – | – | – | 10000 | Near TEM00 | – | – | – | – | ~3.5 | 6VDC | 5VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-D12-445 | 445 nm | 1~50 mW | – | – | <1 | – | – | – | – | 10000 | Near TEM00 | – | – | – | – | ~3.5 | 6VDC | 5VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-F-445 | 445 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-FP-445 | 445 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-FS-445 | 445 nm | 1~80 mW | – | – | <1 | – | – | – | – | 10000 | Near TEM00 | – | – | – | – | ~4.5 | – | – | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | <10 | 100-240VAC(TTL30kH and Analog 0-5V,optional) | 77(L)×30(W)×30(H)mm3 | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-445 | 445 nm | 1~80 mW | – | – | <1 | – | – | – | – | 10000 | Near TEM00 | – | – | – | – | ~4.5 | – | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | – | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | – | – | – | – | 6VDC | 5VDC(TTL30kHz and Analog0-3V,0-5V, optional) | Φ12×50 | Φ15×90 | – | – | – | Datasheet |
| PGL-V-H-445 | 445 nm | 1~80 mW | – | – | – | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | <10 | 100-240VAC | 92(L)×40(W)×40(H)mm3 | – | – | – | – | 1 | 12VDC | TTL30kHz and Analog 0-5V | Datasheet |
| PGL-H-445 | 445 nm | 1~1000 mW | – | – | <1 | – | – | – | – | 10000 | Near TEM00 | – | – | – | – | ~4.5 | – | – | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | <10 | 100-240VAC(TTL30kH and Analog 0-5V,optional) | 77(L)×30(W)×30(H)mm3 | – | – | – | – | – | – | – | Datasheet |
| MDL-E-445 | 445 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-NS-445 | 445 nm | 1~80 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-445 | 445 nm | 1~60 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
447 NM Blue Violet Diode Laser.
18 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Polarization direction | Operating temperature (℃) | Operating voltage(external PCB2) | Operating voltage(external PCB3) | Connection | Operating temperature | Storage temperature | Humidity | Operating voltage(internal PCB1) | Dimensions of internal PCB mm | Dimensions of internal PCB1 mm | Power stability(rms, over 4 hours) | Operating voltage(PSU-V-OEM) | Dimensions of laser head | Modulation optional | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-447(FC) | 447 nm | 1~15 W | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-447 | 447 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-447L | 447 nm | 1~500 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-447 | 447 nm | 1~1000 mW | <2%, <1%, <0.5% | – | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-F-447 | 447 nm | 1~4 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-447 | 447 nm | 1~8000 mW | <2%, <1%, <0.5% | – | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Multimode | Horizontal+ Vertical / Horizontal/ Vertical | 25±3 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-HD-447 | 447 nm | 8~16 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XD-447 | 447 nm | 16~20 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-447-SM | 447 nm | 1~50 mW | <2%, <1%, <0.5% | – | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-447 | 447 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-D8-447 | 447 nm | 1~30 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | 5VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | – | Datasheet |
| PGL-D12-447 | 447 nm | 1~50 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | 5VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-447 | 447 nm | 1~80 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | – | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | 5VDC(TTL30kHz and Analog0-3V,0-5V, optional) | Φ12×50 | Φ15×90 | – | – | – | – | Datasheet |
| PGL-FS-447 | 447 nm | 1~80 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | – | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | <5%, <3%, <1% | 100-240VAC(TTL30kH and Analog 0-5V,optional) | 77(L)×30(W)×30(H)mm3 | – | Datasheet |
| PGL-H-447 | 447 nm | 1~1000 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | – | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | <5%, <3%, <1% | 100-240VAC(TTL30kH and Analog 0-5V,optional) | 77(L)×30(W)×30(H)mm3 | – | Datasheet |
| PGL-V-H-447 | 447 nm | 1~3000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | <5%, <3%, <1% | 100-240VAC | 92(L)×40(W)×40(H)mm3 | TTL30kHz and Analog 0-5V | Datasheet |
| MDL-NS-447 | 447 nm | 1~80 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-447 | 447 nm | 1~60 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
450 NM Blue Violet Diode Laser.
24 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Operating temperature (℃) | Polarization direction | Fiber Core Diameter (um) | Fiber Connector | ultra-compact design, a long lifetime, and Fiber Jacket | Modulation option | Power supply (90-264VAC) | Warranty | Operating voltage(external PCB2) | Operating voltage(external PCB3) | Connection | Operating temperature | Storage temperature | Humidity | Power stability(rms, over 4 hours) | Operating voltage(PSU-V-OEM) | Modulation optional | Dimensions of laser head | Beam divergence (mrad) | Laser operation mode | Storage temperature (°C) | Humidity (%) | Weight (g) | Operating voltage(internal PCB1) | Dimensions of internal PCB mm | Dimensions of internal PCB1 mm | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-450(FC) | 450 nm | 1~15 W | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-450 | 450 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-450L | 450 nm | 1~500 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-450 | 450 nm | 1~1000 mW | <2%, <1%, <0.5% | – | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-F-450 | 450 nm | 1~4 W | – | – | 1.4×0.2 / 1.4×0.2 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | Multimode | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-450 | 450 nm | 1~8000 mW | <2%, <1%, <0.5% | – | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Multimode | 25±3 | Horizontal+ Vertical / Horizontal/ Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-HD-450 | 450 nm | 8~16 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XD-450 | 450 nm | 16~20 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-450-SM | 450 nm | 1~50 mW | <2%, <1%, <0.5% | – | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-450 | 450 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| YL-I-450 | 450 nm | 1~200 W | – | – | – | – | – | – | – | – | – | – | – | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | PVC, Metal optional | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| OEM-DH-450 | 450 nm | 15-30 W | – | – | – | <5 | – | – | – | 10000 | – | 25+/-3 (OEM-DH-450) / 10-35 (OEM-DH-450-Water) | – | – | – | – | – | PSU-H-LED | 1 year | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-D8-450 | 450 nm | 1~30 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | – | – | – | – | – | – | 5VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-D12-450 | 450 nm | 1~50 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | – | – | – | – | – | – | 5VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-V-FC-450 | 450 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | 100-240VAC | TTL30kHz and Analog 0-5V | 92(L)×40(W)×40(H)mm3 | – | – | – | – | – | – | – | – | Datasheet |
| PGL-F-450 | 450 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-LF-450 | 450 nm | 1~50 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | – | – | – | – | – | – | – | – | – | – | Cable with flying leads | – | – | – | – | – | TTL 30kHz or analog (0-3V or 0-5V) | – | <1.5 | CW | -20°C to +80°C | < 90 %, non-condensing | 45g | – | – | – | Datasheet |
| PGL-VI-450 | 450 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-FS-450 | 450 nm | 1~80 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | – | – | – | – | – | – | – | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | 100-240VAC(TTL30kH and Analog 0-5V,optional) | – | 77(L)×30(W)×30(H)mm3 | – | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-FC-450 | 450 nm | 1~100 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | – | – | – | – | – | – | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | – | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | – | – | – | – | – | – | – | – | – | 5VDC(TTL30kHz and Analog0-3V,0-5V, optional) | Φ12×50 | Φ15×90 | Datasheet |
| PGL-H-450 | 450 nm | 1~1000 mW | – | – | – | – | – | – | – | – | Near TEM00 | – | – | – | – | – | – | – | – | – | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | 100-240VAC(TTL30kH and Analog 0-5V,optional) | – | 77(L)×30(W)×30(H)mm3 | – | – | – | – | – | – | – | – | Datasheet |
| PGL-V-H-450 | 450 nm | 1~3000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | 100-240VAC | TTL30kHz and Analog 0-5V | 92(L)×40(W)×40(H)mm3 | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-450 | 450 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-PS-450 | 450 nm | 1~60 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
520 NM Green Laser.
29 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | Polarization direction | Operating temperature (℃) | Beam divergence, half angle (mrad) | Power supply | TTL / Analog modulation | Warranty | Power stability (rms, 4 hours±3℃) | Power supply (24VDC) | Modulation option | Operating voltage(external PCB1) | Connection | Operating temperature | Storage temperature | Humidity | Beam divergence (mrad) | Laser operation mode | Modulation optional | Storage temperature (°C) | Humidity (%) | Weight (g) | Power stability(rms, over 4 hours) | Warm-up time | Warranty (years) | Operating voltage(PSU-V-OEM) | Operating voltage(PSU-I-OEM) | Dimensions of laser head | Operating voltage(internal PCB) | Dimensions of internal PCB | Operating voltage(PSU-II-OEM) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-520 | 520 nm | 1~40 mW | <2%, <1%, <0.5% | Multimode | ~4.0×0.5 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XS-520 | 520 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | ~4.0×0.5 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-520L | 520 nm | 1~100 mW | <2%, <1%, <0.5% | – | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 / <1.2 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-520 | 520 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | <4.0×0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-520 | 520 nm | 800~1000 mW | <2%, <1%, <0.5% | Multimode | ~4.0×0.5 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-520 | 520 nm | 1-2 W | <2%, <1%, <0.5% | Multimode | ~2.2×1.2 / ~2.1×1.2 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | – | Horizontal+ Vertical / Horizontal/ Vertical | 25±3 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-HD-520 | 520 nm | 2~4 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XD-520 | 520 nm | 4~10 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-520-SM | 520 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <4.0×0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-520 | 520 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| YL-I-520 | 520 nm | 1~70 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| OEM-F-520 | 520 nm | 1~800 mW | – | Multimode | – | <5 | – | – | – | 10000 | – | – | 25+/-3 (OEM-F-520) / 10-35 (F-520-HS) | <1.3×0.1 | PSU-SD-OEM | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 1 year | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| OEM-JD-520 | 520 nm | 30~55 W | – | – | ~1.2 | <5 | Air cooled | – | – | >10000 | – | – | 0-30 | – | – | – | – | <2%, <1% | PSU-PNDT-OEM (24V/ 14.6A) | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL/ Analog optional | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| OEM-AD-520 | 520 nm | 55~60 W | – | – | ~1.2 | <5 | Air cooled | – | – | >10000 | – | – | 0-30 | – | – | – | – | <2%, <1% | PSU-PNDT-OEM (24V/ 14.6A) | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL/ Analog optional | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-D8-520 | 520 nm | 1~30 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | 7.5-8VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-D12-520 | 520 nm | 1~50 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | 7.5-8VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-LF-520 | 520 nm | 1~50 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | – | – | – | – | – | – | – | – | – | – | Cable with flying leads | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | -20°C to +80°C | < 90 %, non-condensing | 45g | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-F-520 | 520 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-FP-520 | 520 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-V-FC-520 | 520 nm | 1~50 mW | – | Near TEM00 / Multimode | <1 / <3×0.5 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | – | – | – | Datasheet |
| PGL-VI-520 | 520 nm | 1~100 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | – | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | – | 7.5-8VDC | mm2 / Φ12×50 | – | Datasheet |
| PGL-FS-520 | 520 nm | 1~100 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | <5%, <3%, <1% | minutes / <10 | – | – | – | 77(L)×30(W)×30(H)mm3 | – | – | 7V / (TTL30kHz or Analog 0-5V,optional) | Datasheet |
| PGL-VI-FC-520 | 520 nm | 1~100 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | – | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | – | – | – | – | – | – | – | – | – | – | – | – | 7.5-8VDC | mm2 / Φ12×50 | – | Datasheet |
| PGL-V-H-520 | 520 nm | 1~800 mW | – | Near TEM00 / Multimode | <1 / <3×0.5 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | – | – | – | Datasheet |
| PGL-V-H-FC-520 | 520 nm | 1~800 mW | – | Near TEM00 / Multimode | <1 / <3×0.5 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | – | – | – | Datasheet |
| PGL-H-520 | 520 nm | 1~800 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | – | – | – | – | – | – | – | Cable with flying leads | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | – | – | – | <5%, <3%, <1% | minutes / <10 | – | – | – | 77(L)×30(W)×30(H)mm3 | – | – | 7V / (TTL30kHz or Analog 0-5V,optional) | Datasheet |
| MDL-E-520 | 520 nm | 1~40 mW | <2%, <1%, <0.5% | Multimode | ~4.0×0.5 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-520 | 520 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | ~4.0×0.5 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-520 | 520 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | ~4.0×0.5 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
Infrared Laser, 1030 NM Infrared Laser Module, Infrared DPSS Lasers.
44 models| Model | Wavelength | Output / average power | Pulse energy | Power stability (rms, 4 hours ± 3°C) | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Cooled method | Power stability (rms, 4 hours , ±3°C) | Spectral line width (nm) | Beam diameter at the aperture (1/e2, mm) | Polarization ratio | Operating voltage (VDC) | Fiber type | Fiber Core diameter | Fiber connector | Fiber length | Fiber jacket | M2 after fiber | Beam divergence (mrad) | Modulation optional | Longitudinal mode | Spectral line width (MHz) | Pointing stability over temperature (urad/°C) | Frequency shift (MHz) (over ±2°C and 8hrs) (optional) | Power stability (rms, 4 hours , ±3℃) | Fiber length(m) | Polarization ratio (dB) | Relative intensity noise (rms, 10Hz-10MHz) | Relative intensity noise (dBc/Hz) | Peak intensity noise (dBc/Hz) | Relaxation oscillation peak frequency (MHz) | Operating temperature (℃) | Current adjustment range | Relative intensity noise (rms, 10Hz-3MHz) | Frequency shift (MHz) (over ±2℃and 8 hours ) | Beam diameter (mm) | Power supply (VAC) | Spectral linewidth (nm) | Frequency shift (MHz) (over ±2℃and 8 hours) | Excess relative intensity noise (rms, 10Hz-3MHz) | laser radar, etc. Fiber length(m) | Single pulse energy (nJ) | Rep. Rate( | Ave power stability (rms, 4 hours±3℃) | Pulse duration (ns) | Fiber length (m) | Fiber Jacket | Power stability (rms, over 4 hours) | Pulse duration (ps) | Rep. rate | Operating voltage (VDC/VAC) | Single pulse energy (uJ) | pulse | Pulse | Rep. Rate | Rep. rate (MHz) | Beam quality(M2) | Rep. rate (kHz) | Rep. Rate (kHz) | Pulse duration | Pulse duration (fs) | M2 factor | Operating voltage (VAC) | Beam diameter at the aperture (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TEM-LN-1030 | 1030 nm | 1~500 mW | – | <2%, <1%, <0.5% | <1%, <0.5% | <1.1 | <1.5 | <5 | 25±3 | PSU-III-FDA/PSU-III-LED/PSU-A-D | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-III-1030L | 1030 nm | 1~500 mW | – | <2%, <1%, <0.5% | <1%, <0.5% | <1.1 | <1.5 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | TEM00 | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-III-1030 | 1030 nm | 1~1000 mW | – | <2%, <1%, <0.5% | <1%, <0.5% | – | <3.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-F-1030 | 1030 nm | 1~100 mW | – | – | – | – | – | <5 | 10-35 | PSU-H-FDA | >10000 | – | – | <3%, <2% | <0.1 | ~2.0 | >100:1, Horizontal (Vertical optional) | PSU-SR-OEM (12V/25A) | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-III-1030-SM | 1030 nm | 1~500 mW | – | <2%, <1%, <0.5% | <1%, <0.5% | – | – | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | TEM00 | Conduction | – | – | – | – | – | SM fiber, PM fiber optional | 6μm, 0.12NA | FC/PC, FC/APC optional | 1m | Metal, PVC optional | ~1.1 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| TEM-F-1030 | 1030 nm | 1~500 mW | – | <2%, <1%, <0.5% | – | <1.1 | <1.5 | <5 | 25±3 | PSU-III-FDA/PSU-III-LED/PSU-A-D | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1030L | 1030 nm | 1~500 mW | – | <2%, <1%, <0.5% | – | <1.1 | <1.5 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | TEM00 | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1030 | 1030 nm | 1~1000 mW | – | <2%, <1%, <0.5% | – | – | <3.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-F-1030 | 1030 nm | 1~600 mW | – | – | – | – | – | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | TEM00 | – | – | – | ~1.5 | >100:1, Horizontal (Vertical optional) | – | – | – | – | – | – | – | <2.0 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1030DFB-SM | 1030 nm | 1~200 mW | – | <2%, <1%, <0.5% | – | – | <3.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1030-SM | 1030 nm | 1~500 mW | – | <2%, <1%, <0.5% | – | – | <3.0 | <5 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Conduction | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-1030 | 1030 nm | 1~500 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MSL-U-1030-SU | 1030 nm | 1~50 mW | – | – | – | <1.2 | – | <5 | 10-35 | PSU-H-FDA | >10000 | TEM00 | – | – | – | <1.0 | >100:1, Horizontal (Vertical optional) | PSU-SR-OEM (12V/25A) | – | – | – | – | – | – | <1.5 | – | Single | <1MHz | <8 | <±200 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-SLM-Seed(1014-1120) | 1014 nm | 1~50 mW | – | – | – | <1.05 | – | – | – | – | >10000 | TEM00 | Conduction cooled | – | – | – | – | 12V/11.5A | – | – | FC/APC | – | PVC, Metal optional | – | – | – | – | – | – | – | <3%, <2%, <1% | 1 | >20, after PM fiber | <0.1%, <0.05%, (<0.03% optional) | <-140 (10MHz) | <-130 | 2-3 | 15-30 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1030-SLM | 1030 nm | 1~10 W | – | – | – | <1.1 | – | <30 | – | – | >10000 | TEM00 | Air cooled or Water cooled | – | – | – | – | – | – | – | FC/APC, Collimator optional | – | PVC, Metal optional | – | – | – | SLM | – | – | – | <2%, <1%, <0.5% | 1 | >15, after PM fiber | – | – | – | – | 15-30 | 1-100% | <0.3%, <0.1%, (<0.05% optional) | <±200 | 4±1 (Collimator output) | 110/220VAC | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1030-LN-L | 1030 nm | 1~10 W | – | – | – | <1.1 | – | <30 | – | – | >10000 | TEM00 | Air cooled or Water cooled | – | – | – | – | – | – | – | FC/APC, Collimator optional | – | PVC, Metal optional | – | – | – | SLM | – | – | – | <2%, <1%, <0.5% | 1 | >15, after PM fiber | – | – | – | – | 15-30 | 1-100% | <0.1%, <0.05% | – | 4±1 (Collimator output) | 110/220VAC | <0.004 | <±200 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-LN-FA(1014-1120) | 1014 nm | 1~10 W | – | – | – | – | – | – | – | – | >10000 | – | Air cooled (≤30W) or Water cooled (≤50W) | – | – | – | – | – | – | – | FC/APC, Collimator optional | – | PVC, Metal optional | – | – | – | – | – | – | – | <2%, <1%, <0.5% | – | >15, after PM fiber | – | – | – | – | 15-30 | – | – | – | 4±1 (Collimator output) | 110/220VAC | – | – | <0.03% | 1 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-H-1030-PS | 1030 nm | 1~20 W | – | – | – | <1.2 | <1 | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | 1-500 | 20-120 | <2%, <1% | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1030-CW | 1030 nm | 1~100 W | – | – | – | <1.2 | <1 | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | 1-500 | 20-120 | <2%, <1% | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1030-S | 1030 nm | 1 uW | – | – | – | <1.2 | – | <5 | – | – | >10000 | – | Conduction | – | – | – | – | 12V/11.5A | – | – | FC/APC, Collimator optional | – | – | – | – | – | – | – | – | – | <3%, <2%, <1% | – | Random / >15 | – | – | – | – | 15-35 | – | – | – | 4±1 (Collimator output) | – | – | – | – | – | – | – | – | 5-100 (adjustable) | 1 | PVC, Metal optional | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1030-PS-Seed | 1030 nm | 0.5-1 mW | – | – | – | <1.2 | – | <15 | – | – | >10000 | – | – | – | – | – | – | 12V/11.5A | – | – | FC/APC | – | PVC, Metal optional | – | – | – | – | – | – | – | – | – | Random / > 15 | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | 1 | – | <3%, <2%, <1% | <10 | 20-50MHz | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1030-PS | 1030 nm | 1-2000 mW | – | – | – | <1.2 | <1 | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | 1-500 | 20-120 | <2%, <1% | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1030-Pico | 1030 nm | 10-5000 mW | – | – | – | <1.2 / <1.8 | – | <15 | – | – | >10000 | – | Air cooled | – | – | – | – | – | – | – | FC/APC, Collimator optional | – | PVC, Metal optional | – | – | – | – | – | – | – | <3%, <2% | – | Random / >15 | – | – | – | – | 15-35 | – | – | – | 4±1 (Collimator output) | – | – | – | – | – | – | – | – | – | 1 | – | – | 100-900 | 100kHz-20MHz | 12V/11.5A | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1030-Nano | 1030 nm | 0.5-10 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PS-FG-1030A | 1030 nm | 1~5 W | – | – | – | <1.3 | <1.5 | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | <5%, <3% | – | – | – | – | – | – | – | 1-10 | duration, / high | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PS-FG-1030B | 1030 nm | 5~40 W | – | – | – | <1.3 | <1.5 | <10 | – | RAD1PS | >10000 | TEM00 | – | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | <5%, <3% | – | – | – | – | – | – | – | 10-80 | duration, / high | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PS-HG-1030A | 1030 nm | 1~5 W | – | – | – | <1.3 | <1.5 | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | 1-250 | – | <5%, <3% | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PS-HG-1030B | 1030 nm | 5~50 W | – | – | – | <1.3 | <1.5 | <10 | – | RAD1PS | – | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | <5%, <3% | – | – | – | – | – | – | – | 1-2.5 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FS-H-1030A | 1030 nm | 1~500 mW | – | – | – | <1.2 | – | <10 | – | 12V/6.67A | >10000 | TEM00 | Air cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | <2%, <1% | – | – | – | – | – | 80±2 | – | – | duration, / high | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FS-H-1030B | 1030 nm | 500~3000 mW | – | – | – | <1.2 | – | <10 | – | RAD1PS | >10000 | TEM00 | Air cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | 6.25-30 | – | <2%, <1% | – | – | – | – | – | 80±2 | – | – | – | <150 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FS-H-1030C | 1030 nm | 3~20 W | – | – | – | <1.2 | – | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | <2%, <1% | – | – | – | – | – | – | – | – | – | <250 | 20-120 | – | – | – | – | – | – | – | – | – | Datasheet |
| FS-H-1030D | 1030 nm | 20~50 W | – | – | – | <1.2 | – | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | <2%, <1% | – | – | – | – | – | 20-120 | – | – | duration, / high | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FS-H-1030E | 1030 nm | 50~100 W | – | – | – | <1.3 | – | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | <2%, <1% | – | – | – | – | – | 20-120 | – | – | duration, / high | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FS-F-1030A | 1030 nm | 1~10 W | – | – | – | – | – | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | <2%, <1% | – | – | – | – | – | – | – | – | duration, / high | – | – | 1 | <1.3 | – | – | – | – | – | – | – | Datasheet |
| FS-F-1030B | 1030 nm | 10~20 W | – | – | – | – | – | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | <2%, <1% | – | – | – | – | – | – | – | – | – | <300 | – | – | <1.2 | 100-1000 | – | – | – | – | – | – | Datasheet |
| FS-F-1030C | 1030 nm | 20~50 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FS-F-1030D | 1030 nm | 50~100 W | – | – | – | – | – | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | <2%, <1% | – | – | – | – | – | – | – | – | – | – | – | – | <1.3 | – | 100-1000 | <300 | – | – | – | – | Datasheet |
| FS-G-1030A | 1030 nm | 1~10 W | – | – | – | – | – | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 50-1000 | – | – | <800 | <1.3 | – | – | Datasheet |
| FS-G-1030B | 1030 nm | 10~40 W | – | – | – | – | – | <10 | – | RAD1PS | >10000 | TEM00 | Water cooled | – | – | – | >100:1 Vertical | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 15-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 50-1000 | – | <800 | – | <1.3 | – | – | Datasheet |
| EO-LS-1030 | 1030 nm | 1~2 W | 1~2 mJ | – | – | – | – | <10 | – | PSU-AOM(3U) | >10000 | – | Air cooled | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | <5%, <3% | <20 | – | – | – | – | – | – | – | – | – | – | – | – | 1 | – | – | – | <1.3 | – | – | Datasheet |
| FC-1030 | 1030 nm | 1~550 mW | – | <2%, <1%, <0.5% | – | – | – | – | – | – | >10000 | – | Air cooled | – | – | – | – | – | – | – | SMA905, FC/PC optional | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 100-240 | – | Datasheet |
| MIL-1030(FC) | 1030 nm | 1~550 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MPL-F-1030 | 1030 nm | 1~300 mW | 0.1~150 uJ | – | – | – | – | <5 | – | PSU-H-FDA/PSU-H-LED | >10000 | TEM00 | – | <5%, <3%, <2% | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | ~1.2 | Datasheet |
| MPL-S-1030 | 1030 nm | 1~450 mW | 1~70 uJ | – | – | – | – | – | – | PSU-SR | >10000 | TEM00 | – | <5%, <3%, <2% | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | ~1.0 | Datasheet |
Infrared Laser,1060 NM Infrared Diode Lasers,infrared Diode Laser System.
18 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Operating temperature (℃) | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | Operating temperature | Storage temperature | Humidity | Dimensions of internal PCB | Warranty | Operating voltage(external PCB1) | Operating voltage(external PCB2) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-1060(FC) | 1060 nm | 1~2000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1060-SLD | 1060 nm | 1~17 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1060L | 1060 nm | 1~200 mW | <2%, <1%, <0.5% | – | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1060 | 1060 nm | 1~1500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-1060 | 1060 nm | 1.5~2.5 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XF-1060 | 1060 nm | 2.5~5 W | – | Multimode | <3.0 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1060-SLD-SM | 1060 nm | 1~17 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1060-SM | 1060 nm | 1~500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1064-SM | 1064 nm | 1~500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-1060 | 1060 nm | 1~500 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-1060 | 1060 nm | 1~10 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-1060 | 1060 nm | 1~100 mW | – | NearTEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | Cable with flying leads | – | – | – | 10°C to 35°C | -20°C to 80°C | < 90 %, non-condensing | mm2 / Φ15×90 | – | – | – | Datasheet |
| PGL-H-1060 | 1060 nm | 1~1500 mW | – | Multimode | <5 | – | – | – | – | 10,000 | – | – | – | – | Cable with flying leads | – | – | – | 0°C to 40°C | -20°C to 80°C | <90 %, non-condensing | – | months / 6 | 3VDC | 5VDC(TTL10kHz or Analog0-5V) | Datasheet |
| MDL-E-1060 | 1060 nm | 1~40 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-1060 | 1060 nm | 1~280 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-1064 | 1064 nm | 1~280 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-1060 | 1060 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-1064 | 1064 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
Infrared Laser,1310 NM Infrared Diode Lasers,infrared Diode Laser System.
13 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | Warranty (years) | Operating voltage(internal PCB) | Operating temperature | Storage temperature | Humidity | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-1310(FC) | 1310 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1310L | 1310 nm | 1~10 mW | <2%, <1%, <0.5% | Near TEM00 | <2.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1310-SLD | 1310 nm | 1~17 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1310 | 1310 nm | 10~800 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-1310 | 1310 nm | 800~3000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1310-SM | 1310 nm | 1~180 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1310DFB-SM | 1310 nm | 1~180 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1310-SLD-SM | 1310 nm | 1~17 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-1310 | 1310 nm | 1~180 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-1310 | 1310 nm | 1~10 mW | – | – | – | – | – | -10°C to +45°C | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | – | – | – | – | – | Datasheet |
| PGL-VI-1310 | 1310 nm | 1~10 mW | – | Near TEM00 | <3 | – | – | – | – | 10000 | – | – | – | Cable with flying leads | – | – | – | 1 | 3VDC (TTL10kHz, optional) | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | Datasheet |
| PGL-FP-1310 | 1310 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-NS-1310 | 1310 nm | 1~10 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
Infrared Laser, 1313 NM Infrared Laser Module,infrared Lasers.
9 models| Model | Wavelength | Output / average power | Pulse energy | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam diameter at the aperture (1/e2, mm) | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Power supply (12VDC) | Expected lifetime (hours) | Spectral line width (nm) | Beam divergence (mrad) | Modulation optional | Longitudinal mode | Spectral line width (MHz) | Pointing stability over temperature (urad /°C) | Frequency shift (MHz) (over ±2°C and 8hrs) (optional) | Operating voltage (VDC) | Power stability (rms, 4 hours ± 3°C) | Fiber connector | Cooled method | Operating temperature (℃) | Operating voltage (VAC) | Beam diameter at the aperture (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-U-1313-SU | 1313 nm | 1~1000 mW | – | TEM00 | <1% | <1.2 | ~1.5 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-H-1313 | 1313 nm | 1~1000 mW | – | TEM00 | <1% | <1.5 | – | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | <0.1 | <2.0 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-H-1313 | 1313 nm | 1~1000 mW | – | TEM00 | – | <1.5 | – | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | <2.0 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-U-1313-SU | 1313 nm | 1000~2000 mW | – | TEM00 | – | <1.5 | ~1.0 | – | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | – | – | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MSL-U-1313-SU | 1313 nm | 1~500 mW | – | TEM00 | <1% | <1.2 | <1.0 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | – | >10000 | – | <1.5 | – | Single | <1MHz | <8 | <±200 | PSU-SR-OEM (12V/25A) | – | – | – | – | – | – | Datasheet |
| FC-1313 | 1313 nm | 1~1800 mW | – | – | – | – | – | – | – | – | – | – | >10000 | – | – | – | – | – | – | – | – | <2%, <1%, <0.5% | SMA905, FC/PC optional | Air cooled | 10-35 | 100-240 | – | Datasheet |
| MIL-1313(FC) | 1313 nm | 1~1800 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MPL-H-1313 | 1313 nm | 1~100 mW | 10~20 uJ | TEM00 | – | – | – | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | – | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | ~1.5 | Datasheet |
| MPL-U-1313-SU | 1313 nm | 1~100 mW | 1~20 uJ | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
Infrared Laser, 1319 NM Infrared Laser Module,infrared Lasers.
13 models| Model | Wavelength | Output / average power | Pulse energy | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Polarization ratio | Warm-up time (minutes) | Operating temperature (°C) | Power supply (100-240VAC) | Power supply (12VDC) | Expected lifetime (hours) | Power stability (rms, 4 hours , ±3°C) | Spectral line width (nm) | Beam divergence (mrad) | Power Stability (rms, 4 hours ± 3°C) | Beam divergence, full angle (mrad) | Pointing Stability Over Temperature (urad/°C) | Ave power stability (rms, 4 hours±3℃) | Operating temperature (℃) | Power supply (220-240AC) | Longitudinal mode | Spectral line width (MHz) | Beam diameter at the aperture (1/e2, mm) | Pointing stability over temperature (urad /°C) | Frequency shift (MHz) (over ±2°C and 8hrs) (optional) | Operating voltage (VDC) | Power stability (rms, 4 hours ± 3°C) | Cooled method | Fiber connector | Operating voltage (VAC) | Power stability (rms, over 4 hours) | Fiber core diameter (μm) | Fiber NA | Fiber length (m) | Warranty | Pulse duration (ns) | Beam diameter at the aperture (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-U-1319-SU | 1319 nm | 1~200 mW | – | TEM00 | <1% | <1.5 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | PSU-SR-OEM (12V/25A) | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MLL-U-1319-FL | 1319 nm | 1~1000 mW | – | TEM00 | <1% | <2.0 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | – | >10000 | <3%, <2%, <1% | <1.0 | <1.5 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-U-1319-FL | 1319 nm | 1~1500 mW | – | TEM00 | – | <1.5 / <2.0 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA/PSU-H-LED/PSU-SR | – | >10000 | <3%, <2%, <1% | – | <1.5 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-V-1319 | 1319 nm | 1~5 W | – | – | – | <1.3 | >50:1(100:1 optional), Horizontal(Vertical optional) | <10 | 10-35 | PSU-W-LED | – | >10000 | – | – | – | <3%, <2%, (<1% optional) | <3.0 | <20 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MIL-W-1319A | 1319 nm | 5~10 W | – | – | – | – | >50:1(100:1 optional), Horizontal(Vertical optional) | – | 10-35 | PSU-W-LED | – | >10000 | – | – | – | <3%, <2%, (<1% optional) | <1.0 | <20 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| HPL-1319-CW | 1319 nm | 20~50 W | – | – | – | – | – | <10 | – | – | – | >10000 | – | – | – | – | <3.5 | – | <5%, <3% | 15-35 | PSU-HPL-CW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MSL-U-1319-SU | 1319 nm | 1~100 mW | – | TEM00 | <1% | <1.2 | >100:1, Horizontal (Vertical optional) | <5 | 10-35 | PSU-H-FDA | – | >10000 | – | – | <1.5 | – | – | – | – | – | – | Single | <1MHz | <1.0 | <8 | <±200 | PSU-SR-OEM (12V/25A) | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| AO-Mini-E-1319 | 1319 nm | 100~500 mW | 10~100 uJ | – | – | – | – | <10 | – | – | – | >10000 | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | 24V/14.5A | <3%, <2%,<1% | Air cooled | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-1319 | 1319 nm | 1~1350 mW | – | – | – | – | – | – | – | – | – | >10000 | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | <2%, <1%, <0.5% | Air cooled | SMA905, FC/PC optional | 100-240 | – | – | – | – | – | – | – | Datasheet |
| FC-W-1320B | 1320 nm | 1~15 W | – | – | – | – | – | – | – | – | – | 10000 | – | – | – | – | – | – | – | 10~40 | – | – | – | – | – | – | – | – | – | SMA905 | – | <2%, <1%, <0.5% | 400/600 | 0.22 | 2 | 1 year | – | – | Datasheet |
| MIL-1319(FC) | 1319 nm | 1~1350 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MPL-H-1319 | 1319 nm | 100~150 mW | 7~15 uJ | TEM00 | – | – | >100:1, Horizontal (Vertical optional) | <5 | – | PSU-H-FDA | – | >10000 | – | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | ~15 | – | Datasheet |
| MPL-U-1319-SU | 1319 nm | 1~150 mW | 1~30 uJ | TEM00 | – | – | – | <5 | – | PSU-H-FDA/ PSU-SR | – | >10000 | <5%, <3%, <2% | – | – | – | – | – | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | ~1.2 | Datasheet |
Infrared Laser, 1573 NM Infrared Laser Module, DPSS Infrared Lasers.
9 models| Model | Wavelength | Output / average power | Pulse energy | Repetition rate | Power stability (rms, 4 hours±3℃) | Cooled method | Power stability (rms, 4 hours , ±3℃) | Beam diameter (mm) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (VAC) | Expected lifetime (hours) | Pulse duration (ns) | Transverse mode | Beam diameter at the aperture (mm) | Polarization ratio | Power supply (100-240VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-III-1573-SM | 1573 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| TEM-F-1573DFB | 1573 nm | 1~20 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MIL-W-1573 | 1573 nm | 100~2000 mW | – | – | <5%, <3% | Air Cooled | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1573-SM | 1573 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1573DFB-SM | 1573 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| FC-OEM-1573 | 1573 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| AO-1573(FC) | 1573 nm | 1~800 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| EO-1573-Q | 1573 nm | – | 1 mJ | 1 kHz | – | Water cooled | <5%, <3% | ~4 | <15 | 15-30 | 110/220VAC | >10000 | – | – | – | – | – | Datasheet |
| MPL-H-1573 | 1573 nm | 1~30 mW | 1~30 uJ | – | – | – | – | – | <5 | 10-35 | – | >10000 | 1-2 | TEM00 | ~1.5 | >100:1, Horizontal (Vertical optional) | PSU-H-FDA | Datasheet |
Infrared Diode Laser AT 1870 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-H-1870 | 1870 nm | 1~800 mW | <1%, <2%, <3% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1KHz 1KHz-10KHz, 10KHz-30KHz optional | 10000 | 1 year | Datasheet |
| MDL-1870(FC) | 1870 nm | 1~650 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser AT 1900 NM.
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (℃) | Power supply (100-240VAC) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-1900(FC) | 1900 nm | 1~400 mW | <3%, <2%, <1% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | |
| MDL-H-1900 | 1900 nm | 1~500 mW | <3%, <2%, <1% | Multimode | <3. 0 | <5 | 10~35 | PSU-H-LED / PSU-H-FDA | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 10000 | 1 year | Datasheet |
Infrared Laser,785 NM Infrared Diode Lasers,infrared Diode Laser System.
18 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | Operating voltage(internal PCB) | Connection | Operating temperature | Storage temperature | Humidity | Dimensions of internal PCB | Power stability(rms, over 4 hours) | Warm-up time | Warranty (years) | Operating voltage(PSU-V-OEM) | Operating voltage(PSU-I-OEM) | Dimensions of laser head | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-785(FC) | 785 nm | 1~2000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-C-785 | 785 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XS-785 | 785 nm | 1~80 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-785L | 785 nm | 1~100 mW | <2%, <1%, <0.5% | – | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-785R | 785 nm | 1~350 mW | <3%, <2%, <1% | Round | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-785 | 785 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-785 | 785 nm | 2500~4000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-785-SM | 785 nm | 1~150 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-785-A | 785 nm | 1~150 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| FC-OEM-785-B | 785 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-F-785 | 785 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-785 | 785 nm | 1~100 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | 3VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | mm2 / Φ12×50 | – | – | – | – | – | – | Datasheet |
| PGL-VI-FC-785 | 785 nm | 1~100 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | 3VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | mm2 / Φ12×50 | – | – | – | – | – | – | Datasheet |
| PGL-V-H-785 | 785 nm | 1~2000 mW | – | Multimode | <5 | – | – | – | – | 10000 | – | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | Datasheet |
| MDL-E-785 | 785 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-785 | 785 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-785 | 785 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-785-Lock | 785 nm | 1~600 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser,790 NM Infrared Diode Lasers,infrared Diode Laser System.
7 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-790(FC) | 790 nm | 1~800 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | |
| MDL-III-790L | 790 nm | 1~10 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| MDL-III-790 | 790 nm | 1~1000 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Datasheet |
| MDL-III-790-SLD | 790 nm | 1~12 mW | – | – | – | – | – | – | – | – | – | |
| MDL-III-790-SM | 790 nm | 1~10 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Datasheet |
| MDL-III-790-SLD-SM | 790 nm | 1~12 mW | – | – | – | – | – | – | – | – | – | |
| FC-OEM-790 | 790 nm | 1~10 mW | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser, 800 NM Infrared Diode Lasers, High Power Diode Laser System.
4 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-800(FC) | 800 nm | 1 mW~2 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | |
| MDL-III-800R | 800 nm | 1~500 mW | <3%, <2%, <1% | Round | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-H-800 | 800 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-800 | 800 nm | 1 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
Infrared Diode Laser, 808 NM Infrared Diode Lasers, High Power Diode Laser System.
20 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Power stability (rms, over 4 hours) | Operating temperature (℃) | Power supply | TTL / Analog modulation | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-808 | 808 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | Datasheet |
| MDL-XS-808 | 808 nm | 1~80 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | Datasheet |
| MDL-III-808R | 808 nm | 1~500 mW | <3%, <2%, <1% | Round | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | Datasheet |
| MDL-III-808 | 808 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | Datasheet |
| MDL-I-808 | 808 nm | 1~2500 mW | – | Multimode | <3. 0 | <5 | – | – | – | 10000 | <1%, <3%, <5% | 10~35 | PSU-III-OEM | TTL or Analog with 1Hz-1KHz 1KHz-10KHz, 10KHz-30KHz optional | 1 year | Datasheet |
| MDL-H-808 | 808 nm | 2.5~6 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | Datasheet |
| MDL-F-808 | 808 nm | 6~8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XF-808 | 808 nm | 8~12 W | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-SN-808 | 808 nm | 6~12 W | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-808-SM | 808 nm | 1~400 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | Datasheet |
| FC-OEM-808 | 808 nm | 1~400 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-E-808 | 808 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | Datasheet |
| FC-W-808/810 | 808 nm | 20~50 W | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-W-808H | 808 nm | 50~2000 W | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-808 | 808 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | Datasheet |
| MDL-PS-808 | 808 nm | 1~60 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | Datasheet |
| MDL-808(FC) | 808 nm | 1 mW~10 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | |
| FC-808 | 808 nm | 1~20 W | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-808(Line) | 808 nm | 1 mW~10 W | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-808L | 808 nm | 1~100 mW | <2%, <1%, <0.5% | – | – | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | Datasheet |
830 NM Infrared Diode Laser.
20 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | Operating voltage(internal PCB) | Operating temperature | Storage temperature | Humidity | Dimensions of internal PCB | Power stability(rms, over 4 hours) | Warm-up time | Warranty (years) | Operating voltage(PSU-V-OEM) | Operating voltage(PSU-I-OEM) | Dimensions of laser head | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-830(FC) | 830 nm | 1~1500 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-C-830 | 830 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-830-SLD | 830 nm | 1~8 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XS-830 | 830 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-830L | 830 nm | 1~120 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-830R | 830 nm | 1~500 mW | <3%, <2%, <1% | – | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Round | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-830 | 830 nm | 1~2000 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-830-SLD-SM | 830 nm | 1~8 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-830-SM | 830 nm | 1~270 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-830-A | 830 nm | 1~270 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| FC-OEM-830-B | 830 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-830 | 830 nm | 1~10 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-F-830 | 830 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-830 | 830 nm | 1~100 mW | – | – | <1 | – | – | – | – | 10000 | Near TEM00 | – | – | – | Cable with flying leads | – | – | – | 3VDC | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | mm2 / Φ12×50 | – | – | – | – | – | – | Datasheet |
| PGL-VI-FC-830 | 830 nm | 1~100 mW | – | – | <1 | – | – | – | – | 10000 | Near TEM00 | – | – | – | Cable with flying leads | – | – | – | 3VDC | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | mm2 / Φ12×50 | – | – | – | – | – | – | Datasheet |
| PGL-FP-830 | 830 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-V-H-830 | 830 nm | 1~1000 mW | – | – | <5 | – | – | – | – | 10000 | Multimode | – | – | – | 9 pin connector | – | – | – | – | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | Datasheet |
| PGL-V-H-FC-830 | 830 nm | 1~1000 mW | – | – | <5 | – | – | – | – | 10000 | Multimode | – | – | – | 9 pin connector | – | – | – | – | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | Datasheet |
| MDL-E-830 | 830 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-NS-830 | 830 nm | 1~120 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
Infrared Laser, 852 NM Infrared Diode Lasers.
12 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-852(FC) | 852 nm | 1~1200 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | |
| MDL-C-852 | 852 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-852 | 852 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-852L | 852 nm | 1~150 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-852R | 852 nm | 1~300 mW | <3%, <2%, <1% | – | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Round | – | – | – | – | – | – | – | Datasheet |
| MDL-III-852 | 852 nm | 1~1500 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | Datasheet |
| MDL-III-852-SM | 852 nm | 1~350 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-852 | 852 nm | 1~350 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-852 | 852 nm | 1~10 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | Datasheet |
| MDL-E-852 | 852 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-NS-852 | 852 nm | 1~150 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-852 | 852 nm | 1~30 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | Datasheet |
Infrared Laser, 940 NM Infrared Diode Lasers, High Power Diode Laser System.
19 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | Operating temperature (℃) | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | Operating voltage(internal) | Operating voltage(external PCB1) | Operating temperature | Storage temperature | Humidity | Power stability(rms, over 4 hours) | Warm-up time | Warranty (years) | Operating voltage(PSU-V-OEM) | Operating voltage(PSU-I-OEM) | Dimensions of laser head | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XS-940 | 940 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-940L | 940 nm | 1~250 mW | <2%, <1%, <0.5% | – | <1.0 | – | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-940R | 940 nm | 1~350 mW | <3%, <2%, <1% | Round | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-940 | 940 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-940 | 940 nm | 1~4.5 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XF-940 | 940 nm | 4.5~6 W | – | Multimode | <3.0 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | – | 10-35 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-940-SM | 940 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-940 | 940 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-940 | 940 nm | 1~10 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-F-940 | 940 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-940 | 940 nm | 1~100 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | – | Cable with flying leads | – | – | – | 3VDC (TTL10kHz, optional) | 5VDC(TTL30kHz or Analog 0-3V,0-5V, optional) | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | – | – | – | – | – | – | Datasheet |
| PGL-VI-FC-940 | 940 nm | 1~100 mW | – | Near TEM00 | <1 | – | – | – | – | 10000 | – | – | – | – | – | Cable with flying leads | – | – | – | 3VDC (TTL10kHz, optional) | 5VDC(TTL30kHz or Analog 0-3V,0-5V, optional) | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | – | – | – | – | – | – | Datasheet |
| PGL-FP-940 | 940 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-V-H-940 | 940 nm | 1~1500 mW | – | Multimode | <10 | – | – | – | – | 10000 | – | – | – | – | – | 9 pin connector | – | – | – | – | – | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | Datasheet |
| PGL-V-H-FC-940 | 940 nm | 1~1000 mW | – | Multimode | <10 | – | – | – | – | 10000 | – | – | – | – | – | 9 pin connector | – | – | – | – | – | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | Datasheet |
| MDL-E-940 | 940 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-940 | 940 nm | 1~300 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-940 | 940 nm | 1~60 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-940(FC) | 940 nm | 1~5 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 975 NM Infrared Diode Lasers, High Power Diode Laser System.
14 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | monitoring, | Operating temperature (℃) | Operating voltage (VDC) | Modulation option | Expected lifetime (hours) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XS-975 | 975 nm | 1~50 mW | <2%, <1%, <0.5% | Near TEM00 | <1%, <0.5% | ~1.5 | <1.0 | <5 | inspection | 10-35 | 12V/4A | AMOD (Analog) DC-100kHz | >10000 | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-975L | 975 nm | 1~200 mW | <2%, <1%, <0.5% | Near TEM00 | – | <1.5 | <1.0 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | – | – | – | – | – | – | – | Datasheet |
| MDL-III-975R | 975 nm | 1~500 mW | <3%, <2%, <1% | Round | – | – | ~10 / ~20 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | – | – | – | – | – | – | – | Datasheet |
| MDL-III-975 | 975 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | – | – | <3.0 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | – | – | – | – | – | – | – | Datasheet |
| MDL-H-975 | 975 nm | 2.5~5 W | <2%, <1%, <0.5% | Multimode | – | – | <3.0 | <5 | – | – | – | – | >10000 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | – | – | – | – | – | – | – | Datasheet |
| MDL-F-975 | 975 nm | 5~8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XF-975 | 975 nm | 8~12 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-975-SM | 975 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | – | – | <3.0 | <5 | – | – | – | – | >10000 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-975 | 975 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-975 | 975 nm | 1~10 mW | – | – | – | – | – | – | – | – | – | – | – | – | -10°C to +45°C | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | Datasheet |
| MDL-E-975 | 975 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | – | – | <3.0 | <5 | – | – | – | – | >10000 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-975 | 975 nm | 1~200 mW | <2%, <1%, <0.5% | Multimode | – | – | <3.0 | <5 | – | – | – | – | >10000 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-975 | 975 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | – | – | <3.0 | <5 | – | – | – | – | >10000 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | – | – | – | – | – | – | – | Datasheet |
| MDL-975(FC) | 975 nm | 1 mW~8 W | <2%, <1%, <0.5% | Multimode | – | – | <3.0 | <5 | – | – | – | – | >10000 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | – | – | – | – | – | – | – |
Infrared Laser, 980 NM Infrared Diode Lasers, High Power Diode Laser System.
14 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | Power Stability (rms, 4 hours ± 3°C) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XS-980 | 980 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-III-980L | 980 nm | 1~200 mW | <2%, <1%, <0.5% | – | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 | – | Datasheet |
| MDL-III-980R | 980 nm | 1~500 mW | <3%, <2%, <1% | Round | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | Datasheet |
| MDL-III-980 | 980 nm | 1~2500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | Datasheet |
| MDL-H-980 | 980 nm | 2.5~5 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-F-980 | 980 nm | 5~8 W | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-XF-980 | 980 nm | 8~12 W | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-SN-980 | 980 nm | 6~12 W | – | Multimode | <3.0 | <5 | – | 10-35 | – | >10000 | – | <2%, <1%, (<0.5% optional) | Datasheet |
| MDL-III-980-SM | 980 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | Datasheet |
| MDL-E-980 | 980 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-NS-980 | 980 nm | 1~200 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| MDL-PS-980 | 980 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | Datasheet |
| FC-OEM-980 | 980 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | |
| MDL-980(FC) | 980 nm | 1 mW~10 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – |
RED Laser, 633 NM RED Laser, HE NE Laser |
8 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-633 | 633 nm | 1~50 mW | – | – | – | – | – | – | – | – | |
| MDL-III-633L | 633 nm | 1~100 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-633-SM | 633 nm | 1~30 mW | – | – | – | – | – | – | – | – | |
| FC-OEM-633 | 633 nm | 1~30 mW | – | – | – | – | – | – | – | – | |
| PGL-FP-633 | 633 nm | 1~50 mW | – | – | – | – | – | – | – | – | |
| MDL-E-633 | 633 nm | 1~50 mW | – | – | – | – | – | – | – | – | |
| MDL-NS-633 | 633 nm | 1~100 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-PS-633 | 633 nm | 1~50 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
640 NM RED Diode Laser.
10 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Polarization direction | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-640 | 640 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-640 | 640 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-640 | 640 nm | 1~200 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | Datasheet |
| MDL-III-640-SM | 640 nm | 1~100 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | Datasheet |
| FC-OEM-640 | 640 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-E-640 | 640 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-NS-640 | 640 nm | 1~200 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | Datasheet |
| MDL-PS-640 | 640 nm | 1~50 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | Datasheet |
| MDL-HD-640 | 640 nm | 2~4 W | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-MD-640 | 640 nm | 1~2000 mW | <2%, <1%, <0.5% | – | – | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | Multimode | Horizontal/ Vertical | 25±3 | Datasheet |
655 NM RED Diode Laser.
11 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Polarization direction | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-655 | 655 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-655 | 655 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-655L | 655 nm | 1~180 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | Datasheet |
| MDL-III-655R | 655 nm | 1~200 mW | <3%, <2%, <1% | – | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Round | – | – | Datasheet |
| MDL-III-655 | 655 nm | 1~1000 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | Datasheet |
| MDL-MD-655 | 655 nm | 1~1500 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-HD-655 | 655 nm | 1.5~3 W | <2%, <1%, <0.5% | – | ~2.5×2.5 | <5 | – | – | PSU-N-FDA/PSU-N-LED | >10000 | Multimode | Horizontal+ Vertical | 25±3 | Datasheet |
| MDL-XD-655 | 655 nm | 3~4.5 W | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-E-655 | 655 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-NS-655 | 655 nm | 1~180 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | Datasheet |
| MDL-PS-655 | 655 nm | 1~50 mW | <2%, <1%, <0.5% | <1.5 / <1.2 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | Datasheet |
730 NM RED Diode Laser.
10 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | Operating voltage(internal PCB) | Connection | Operating temperature | Storage temperature | Humidity | Dimensions of internal PCB | Power stability(rms, over 4 hours) | Warm-up time | Warranty (years) | Operating voltage(PSU-V-OEM) | Operating voltage(PSU-I-OEM) | Dimensions of laser head | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-730 | 730 nm | 1~10 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-730 | 730 nm | 1~30 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-730L | 730 nm | 1~30 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-730 | 730 nm | 1~1500 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-730-SM | 730 nm | 1~15 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-730 | 730 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-VI-730 | 730 nm | 1~20 mW | – | – | <1 | – | – | – | – | 10000 | Near TEM00 | 3VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | mm2 / Φ12×50 | – | – | – | – | – | – | Datasheet |
| PGL-V-H-730 | 730 nm | 1~1500 mW | – | – | <5 | – | – | – | – | 10000 | Multimode | – | 9 pin connector | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | <5%, <3%, <1% | minutes / <10 | 1 | 100-240VAC | 12VDC | 92(L)×40(W)×40(H)mm3 | Datasheet |
| MDL-E-730 | 730 nm | 1~10 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-NS-730 | 730 nm | 1~30 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
Yellow Laser, 589 NM Yellow DPSS Lasers.
4 models| Model | Wavelength | Output / average power | Transverse mode | Warm-up time (minutes) | Storage temperature (℃) | Expected lifetime (hours) | Beam divergence, full angle (mrad) | Warranty (years) | Operating voltage(internal PCB) | Connection | Operating temperature | Storage temperature | Humidity | Dimensions of PGL-VI-589 | Dimensions of PGL-VI-1-589 | Operating temperature (℃) | Power supply | TTL modulation | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OEM-S-589-MD | 589 nm | 1~800 mW | TEMn1 | <10 | 0-60 | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-VI-589 | 589 nm | 1~20 mW | TEM00 | – | – | 10000 | <1.5 | 1 | 3VDC | Cable with flying leads | 10°C to 35°C | -20°C to 80°C | <90%, non-condensing | Φ20×100mm2 | Φ15×65mm2 | – | – | – | – | Datasheet |
| PGL-H1-589 | 589 nm | 1~50 mW | TEM00 | – | – | 10000 | <15 | – | – | – | – | – | – | – | – | 15~30 | DC 3V PCB / DC 5V PCB | Optional, 1Hz-1KHz, 1KHz-10KHz, or higher on request | 6 months | Datasheet |
| PGL-VI-FC-589 | 589 nm | 1~50 mW | TEM00 | – | – | 10000 | <1.5 | 1 | 3VDC | Cable with flying leads | 10°C to 35°C | -20°C to 80°C | <90%, non-condensing | Φ20×100mm2 | Φ15×65mm2 | – | – | – | – | Datasheet |
395 NM UV Diode Laser.
4 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | Warm-up time (minutes) | Pulse width (ps) | Rep. | repetition | Operating voltage (VDC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-395 | 395 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | <2.0×0.5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | Datasheet |
| MDL-III-395L | 395 nm | 1~100 mW | <2%, <1%, <0.5% | Near TEM00 | <1.0 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 / <1.2 | <5 | – | – | – | – | Datasheet |
| MDL-NS-395 | 395 nm | 1~100 mW | <3%, <2%, <1% | Near TEM00 | <0.5 | Air cooled | 10-35 | – | >10000 | – | <5 | 200-1000 | 100kHz-20MHz | rate / 100kHz / to / 20MHz, | 12V/3.34A | Datasheet |
| MDL-PS-395 | 395 nm | 1~50 mW | <3%, <2%, <1% | Near TEM00 | <0.5 | Air cooled | 10-35 | – | >10000 | – | <5 | 200-1000 | 100kHz-20MHz | rate / 100kHz / to / 20MHz, | 12V/3.34A | Datasheet |
Infrared Laser, 915 NM Infrared Diode Lasers, High Power Diode Laser System.
13 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | M2 | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | Power stability(rms, over 4 hours) | Warm-up time minutes | Warranty (years) | Operating voltage(PSU-V-OEM) | Operating voltage(PSU-I-OEM) | Operating temperature | Storage temperature | Humidity | Operating voltage(internal PCB) | Operating voltage(internal PCB1) | Operating voltage(external PCB2) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XS-915 | 915 nm | 1~100 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-915L | 915 nm | 1~270 mW | <2%, <1%, <0.5% | – | <1.0 | – | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | <1.5 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-915R | 915 nm | 1~350 mW | <3%, <2%, <1% | Round | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-915 | 915 nm | 1~1500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-H-915 | 915 nm | 1.5~5 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-F-915 | 915 nm | 5~8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-915 | 915 nm | 1~200 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-PS-915 | 915 nm | 1~30 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-915(FC) | 915 nm | 1 mW~7 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-915 | 915 nm | 1~10 mW | – | – | – | – | – | -10°C to +45°C | – | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| PGL-V-H-915 | 915 nm | 1~1500 mW | – | Multimode | – | – | – | – | – | 10000 | – | – | – | TTL30kHz and Analog 0-5V | 9 pin connector | – | – | – | <5%, <3%, <1% | <10 | 1 | 100-240VAC | 12VDC | -10°C to 50°C | -20°C to 80°C | < 90%, non-condensing | – | – | – | Datasheet |
| PGL-V-H-FC-915 | 915 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-VI-915 | 915 nm | 1~100 mW | – | Near TEM00 | – | – | – | – | – | 10000 | – | – | – | – | Cable with flying leads | – | – | – | – | – | 1 | – | – | 0°C to 40°C | -20°C to 80°C | < 90 %, non-condensing | 3VDC | 5VDC(TTL30kHz and Analog0-3V,0-5V, optional) | 5-12VDC(TTL30kHz and Analog 0-3V,0-5V, optional) | Datasheet |
Infrared Laser, 1014 NM Infrared Laser Module, Infrared Fiber Lasers.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours , ±3℃) | Transverse mode | Longitudinal mode | Current adjustment range | Relative intensity noise (rms, 10Hz-3MHz) | Frequency shift (MHz) (over ±2℃and 8 hours ) | M2 | Fiber connector | Fiber length(m) | Fiber jacket | Beam diameter (mm) | Polarization ratio (dB) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (VAC) | Expected lifetime (hours) | Spectral linewidth (nm) | Frequency shift (MHz) (over ±2℃and 8 hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FL-1014-SLM | 1014 nm | 1~5 W | <2%, <1%, <0.5% | TEM00 | SLM | 1-100% | <0.3%, <0.1%, (<0.05% optional) | <±200 | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | – | – | Datasheet |
| FL-1014-LN-L | 1014 nm | 1~5 W | <2%, <1%, <0.5% | TEM00 | SLM | 1-100% | <0.1%, <0.05% | – | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | <0.004 | <±200 | Datasheet |
Infrared Laser, 1018 NM Infrared Laser Module, Infrared Fiber Lasers.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours , ±3℃) | Transverse mode | Longitudinal mode | Current adjustment range | Relative intensity noise (rms, 10Hz-3MHz) | Frequency shift (MHz) (over ±2℃and 8 hours ) | M2 | Fiber connector | Fiber length(m) | Fiber jacket | Beam diameter (mm) | Polarization ratio (dB) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (VAC) | Expected lifetime (hours) | Spectral linewidth (nm) | Frequency shift (MHz) (over ±2℃and 8 hours) | Line width(nm) | Fiber length (m) | Polarization state | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FL-1018-SLM | 1018 nm | 1~10 W | <2%, <1%, <0.5% | TEM00 | SLM | 1-100% | <0.3%, <0.1%, (<0.05% optional) | <±200 | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | – | – | – | – | – | Datasheet |
| FL-1018-LN-L | 1018 nm | 1~10 W | <2%, <1%, <0.5% | TEM00 | SLM | 1-100% | <0.1%, <0.05% | – | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | <0.004 | <±200 | – | – | – | Datasheet |
| FL-1018-CW | 1018 nm | 1~10 W | – | – | – | – | – | – | – | FC/APC, Collimator optional | – | PVC, Metal optional | 4±1 (Collimator output) | – | <15 | Air cooled | 15-35 | 110/220VAC | >10000 | – | – | <2nm | 1 | Random | Datasheet |
Infrared Laser, 1027 NM Infrared Laser Module, Infrared Fiber Lasers.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours , ±3℃) | Transverse mode | Longitudinal mode | Current adjustment range | Relative intensity noise (rms, 10Hz-3MHz) | Frequency shift (MHz) (over ±2℃and 8 hours ) | M2 | Fiber connector | Fiber length(m) | Fiber jacket | Beam diameter (mm) | Polarization ratio (dB) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (VAC) | Expected lifetime (hours) | Spectral linewidth (nm) | Frequency shift (MHz) (over ±2℃and 8 hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FL-1027-SLM | 1027 nm | 1~10 W | <2%, <1%, <0.5% | TEM00 | SLM | 1-100% | <0.3%, <0.1%, (<0.05% optional) | <±200 | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | – | – | Datasheet |
| FL-1027-LN-L | 1027 nm | 1~10 W | <2%, <1%, <0.5% | TEM00 | SLM | 1-100% | <0.1%, <0.05% | – | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | <0.004 | <±200 | Datasheet |
1080nm Laser, Infrared Laser |
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | Transverse mode | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1080-SM | 1080 nm | 1~400 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 6-9μm, 0.13NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| FC-OEM-1080 | 1080 nm | 1~400 mW | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser, 1100 NM Infrared Laser Module, Infrared Fiber Lasers.
7 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours , ±3℃) | Transverse mode | Longitudinal mode | Relative intensity noise (rms, 10Hz-3MHz) | Frequency shift (MHz) (over ±2℃and 8 hours ) | M2 | Fiber connector | Fiber length(m) | Fiber jacket | Beam diameter (mm) | Polarization ratio (dB) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Power supply (VAC) | Expected lifetime (hours) | Spectral linewidth (nm) | Frequency shift (MHz) (over ±2℃and 8 hours) | Line width(nm) | Fiber length (m) | Polarization state | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | M2 after fiber | Operating temperature (°C) | Power supply (100-240VAC) | Noise of amplitude (rms, 20Hz-20MHz) | Fiber | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FL-1100-SLM | 1100 nm | 1~5 W | <2%, <1%, <0.5% | TEM00 | SLM | <0.3%, <0.1%, (<0.05% optional) | <±200 | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1100-LN-L | 1100 nm | 1~5 W | <2%, <1%, <0.5% | TEM00 | SLM | <0.1%, <0.05% | – | <1.1 | FC/APC, Collimator optional | 1 | PVC, Metal optional | 4±1 (Collimator output) | >15, after PM fiber | <30 | Air cooled or Water cooled | 15-30 | 110/220VAC | >10000 | <0.004 | <±200 | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FL-1100-CW | 1100 nm | 1~10 W | – | – | – | – | – | – | FC/APC, Collimator optional | – | PVC, Metal optional | 4±1 (Collimator output) | – | <15 | Air cooled | 15-35 | 110/220VAC | >10000 | – | – | <2nm | 1 | Random | – | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1100-SM | 1100 nm | 1~400 mW | – | TEM00 | – | – | – | – | FC/PC, FC/APC optional | – | Metal, PVC optional | – | – | <5 | Conduction | – | – | >10000 | – | – | – | – | – | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | ~1.1 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | – | – | Datasheet |
| MLL-III-1100-SM | 1100 nm | 1~400 mW | – | TEM00 | – | – | – | – | – | – | – | – | – | <5 | Conduction | – | – | >10000 | – | – | – | – | – | <2%, <1%, <0.5% | – | – | ~1.1 | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | <1%, <0.5% | 1m | Datasheet |
| TEM-F-1100 | 1100 nm | 1~400 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| TEM-LN-1100 | 1100 nm | 1~400 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – |
1120 NM IR Laser, Infrared Diode Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1120 | 1120 nm | 1~1000 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| MDL-H-1120 | 1120 nm | 1~2.5 W | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | – | Datasheet |
| MDL-F-1120 | 1120 nm | 2.5~5 W | – | Multimode | <3.0 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | 10-35 | Datasheet |
1250nm DFB Laser, Infrared Laser, DPSS Laser |
2 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1250-SM | 1250 nm | 1~40 mW | |
| FC-OEM-1250 | 1250 nm | 1~40 mW |
1268nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | Transverse mode | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1268-SM | 1268 nm | 1~10 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-1268DFB-SM | 1268 nm | 1~10 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| FC-OEM-1268 | 1268 nm | 1~10 mW | – | – | – | – | – | – | – | – | – | – | – | – |
1273nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | Transverse mode | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1273DFB-SM | 1273 nm | 1~10 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-1273-SM | 1273 nm | 1~10 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| FC-OEM-1273 | 1273 nm | 1~10 mW | – | – | – | – | – | – | – | – | – | – | – | – |
1290nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1290DFB-SM | 1290 nm | 1~15 mW | |
| MDL-III-1290-SM | 1290 nm | 1~15 mW | |
| FC-OEM-1290 | 1290 nm | 1~15 mW |
1309nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1309DFB-SM | 1309 nm | 1~15 mW | |
| MDL-III-1309-SM | 1309 nm | 1~15 mW | |
| FC-OEM-1309 | 1309 nm | 1~15 mW |
1312nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1312DFB-SM | 1312 nm | 1~10 mW | |
| MDL-III-1312-SM | 1312 nm | 1~10 mW | |
| FC-OEM-1312 | 1312 nm | 1~10 mW |
1330nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1330-SM | 1330 nm | 1~15 mW | |
| MDL-III-1330DFB-SM | 1330 nm | 1~15 mW | |
| FC-OEM-1330 | 1330 nm | 1~15 mW |
1350nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1350-SM | 1350 nm | 1~15 mW | |
| MDL-III-1350DFB-SM | 1350 nm | 1~15 mW | |
| FC-OEM-1350 | 1350 nm | 1~15 mW |
1368nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1368-SM | 1368 nm | 1~10 mW | |
| MDL-III-1368DFB-SM | 1368 nm | 1~10 mW | |
| FC-OEM-1368 | 1368 nm | 1~10 mW |
1390nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1390-SM | 1390 nm | 1~15 mW | |
| MDL-III-1390DFB-SM | 1390 nm | 1~15 mW | |
| FC-OEM-1390 | 1390 nm | 1~15 mW |
1392nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1392-SM | 1392 nm | 1~15 mW | |
| MDL-III-1392DFB-SM | 1392 nm | 1~15 mW | |
| FC-OEM-1392 | 1392 nm | 1~15 mW |
1410nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1410-SM | 1410 nm | 1~15 mW | |
| MDL-III-1410DFB-SM | 1410 nm | 1~15 mW | |
| FC-OEM-1410 | 1410 nm | 1~15 mW |
Infrared Laser,1430 NM Infrared Diode Lasers,infrared Diode Laser System.
6 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1430 | 1430 nm | 1~500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-H-1430 | 1430 nm | 500~1500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Datasheet |
| MDL-III-1430-SM | 1430 nm | 1~15 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-1430DFB-SM | 1430 nm | 1~15 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| FC-OEM-1430 | 1430 nm | 1~15 mW | – | – | – | – | – | – | – | – | |
| MDL-1430(FC) | 1430 nm | 1~1300 mW | – | – | – | – | – | – | – | – |
1510nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1510-SM | 1510 nm | 1~15 mW | |
| MDL-III-1510DFB-SM | 1510 nm | 1~15 mW | |
| FC-OEM-1510 | 1510 nm | 1~15 mW |
1512nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1512-SM | 1512 nm | 1~10 mW | |
| MDL-III-1512DFB-SM | 1512 nm | 1~10 mW | |
| FC-OEM-1512 | 1512 nm | 1~10 mW |
1530nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1530-SM | 1530 nm | 1~15 mW | |
| MDL-III-1530DFB-SM | 1530 nm | 1~15 mW | |
| FC-OEM-1530 | 1530 nm | 1~15 mW |
1560nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-III-1560-SM | 1560 nm | 1~15 mW | |
| MDL-III-1560DFB-SM | 1560 nm | 1~15 mW | |
| FC-OEM-1560 | 1560 nm | 1~15 mW |
631 NM RED Diode Laser.
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-631 | 631 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | <3.0×0.5 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
460nm Blue Laser
10 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Operating temperature (℃) | Polarization direction | Power stability (rms, over 4 hours) | TTL / Analog modulation | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-460 | 460 nm | 1~800 mW | <2%, <1%, <0.5% | Multimode | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | Datasheet |
| MDL-F-460 | 460 nm | 800~1500 mW | – | Multimode | ~2.5×0.5 | <5 | Air cooled | – | PSU-H-FDA/PSU-H-LED | >10000 | 10-35 | – | – | – | – | Datasheet |
| MDL-MD-460 | 460 nm | 1~6000 mW | <2%, <1%, <0.5% | Multimode | ~3.4×3.8 / ~3.3×3.8 | <5 | – | – | PSU-H-FDA/PSU-H-LED/PSU-N-LED | >10000 | 25±3 | Horizontal+ Vertical / Horizontal/ Vertical | – | – | – | Datasheet |
| MDL-HD-460 | 460 nm | 4~8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XD-460 | 460 nm | 8~16 W | – | – | <2.4×2.0 | <5 | – | – | PSU-N-LED/ PSU-N-FDA | 10000 | 10-35 | Horizontal+Vertical | <1%, <2%, <3% | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 1 year | Datasheet |
| MDL-III-460-SM | 460 nm | 1~50 mW | <2%, <1%, <0.5% | Multimode | <2.1×1.6 / <2.5×0.2 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | Datasheet |
| PGL-FP-460 | 460 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| YL-I-460 | 460 nm | 1~20 W | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-460(FC) | 460 nm | 1 mW~14 W | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-460L | 460 nm | 1~80 mW | – | – | – | – | – | – | – | – | – | – | – | – | – |
Infrared Laser,1450 NM Infrared Diode Lasers,infrared Diode Laser System.
6 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | TTL / Analog modulation | Expected lifetime (hours) | Warranty | Power stability (rms, 4 hours ± 3°C) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1450R | 1450 nm | 1~200 mW | <1%, <2%, <3% | Round | ~10 / ~20 | <5 | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz, 30kHz-100kHz optional | 10000 | 1 year | – | – | – | – | Datasheet |
| MDL-III-1450 | 1450 nm | 1~1000 mW | – | Multimode | <3.0 | <5 | – | >10000 | – | <2%, <1%, <0.5% | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
| MDL-III-1450-SM | 1450 nm | 1~15 mW | – | Multimode | <3.0 | <5 | – | >10000 | – | <2%, <1%, <0.5% | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
| MDL-III-1450DFB-SM | 1450 nm | 1~15 mW | – | Multimode | <3.0 | <5 | – | >10000 | – | <2%, <1%, <0.5% | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
| FC-OEM-1450 | 1450 nm | 1~15 mW | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-1450(FC) | 1450 nm | 1~400 mW | – | – | – | – | – | – | – | – | – | – | – |
Infrared Diode Laser, 880 NM Infrared Diode Lasers.
9 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Transverse mode | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-880L | 880 nm | 1~5 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | Datasheet |
| MDL-III-880-SLD | 880 nm | 1~8 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Datasheet |
| MDL-III-880 | 880 nm | 1~1000 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Datasheet |
| MDL-H-880 | 880 nm | 1~2 W | <2%, <1%, <0.5% | – | <3.0 | <5 | Air cooled | 10-35 | PSU-H-FDA/PSU-H-LED | >10000 | Multimode | Datasheet |
| MDL-III-880-SM | 880 nm | 1~2 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Datasheet |
| MDL-III-880-SLD-SM | 880 nm | 1~8 mW | <2%, <1%, <0.5% | – | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Multimode | Datasheet |
| PGL-FP-880 | 880 nm | 1 mW | – | – | – | – | – | – | – | – | – | |
| MDL-880(FC) | 880 nm | 1~1500 mW | – | – | – | – | – | – | – | – | – | |
| PGL-LF-880 | 880 nm | 1~10 mW | – | – | – | – | – | – | – | – | – |
680 NM RED Diode Laser.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-680R | 680 nm | 1~200 mW | <3%, <2%, <1% | Round | ~10 / ~20 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-680 | 680 nm | 1~1500 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-680-SM | 680 nm | 1~20 mW | <2%, <1%, <0.5% | Multimode | <3.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
685 NM RED Diode Laser.
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | M2 | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-685L | 685 nm | 1~50 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-685-SM | 685 nm | 1~20 mW | – | – | – | – | – | – | – | – | |
| MDL-NS-685 | 685 nm | 1~20 mW | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
Infrared Laser AT 2120 NM
2 models| Model | Wavelength | Output / average power | Ave power stability (rms, 4 hours±3℃) | Rep.rate (kHz) | Single pulse energy (µJ) | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (℃) | Power supply | Expected lifetime (hours) | Power stability (rms, 4 hours±3℃) | Warm-up time (minutes) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OEM-AO-2120 | 2120 nm | 1~3 W | <5%, <3% | 10 | 100-300 | <3 | Water cooled | 10-30 | PSU-MIR (3U) | >10000 | – | – | Datasheet |
| OEM-IR-2120 | 2120 nm | 1~10 W | – | – | – | <3 | Water cooled | 10-30 | PSU-MIR (3U) | >10000 | <5%, <3% | <10 | Datasheet |
Infrared Laser AT 2096 NM
2 models| Model | Wavelength | Output / average power | Ave power stability (rms, 4 hours±3℃) | Rep.rate (kHz) | Single pulse energy (µJ) | Beam divergence, full angle (mrad) | Cooled method | Operating temperature (℃) | Power supply | Expected lifetime (hours) | Power stability (rms, 4 hours±3℃) | Warm-up time (minutes) | during operations, etc. | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OEM-AO-2096 | 2096 nm | 1~15 W | <5%, <3% | 10 | 100-1500 | <5 | Water cooled | 10-30 | PSU-MIR (3U) | >10000 | – | – | – | Datasheet |
| OEM-IR-2096 | 2096 nm | 1~20 W | – | – | – | <3 | – | 10-30 | PSU-MIR (3U) | >10000 | <5%, <3% | <10 | Cooled method / Water cooled | Datasheet |
Multi Line Laser/ Multi Wavelength Laser |
2 models| Model | Wavelength | |
|---|---|---|
| Multi-wavelength MM Fiber Output Laser | — | |
| OEM Laser Combiner | — |
Laser Measurement and Safety |
1 model| Model | Wavelength | |
|---|---|---|
| Integrated OEM Laser Power Meter | — |
Supercontinuum Source
4 models| Model | Wavelength | Output / average power | Repetition rate | Pulse width | Power stability | M² | Fiber connector | Fiber jacket | Polarization ratio | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Operating voltage (VDC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FL-SC-OEM (1~200 mW) | 470~2400 nm | 1~200 mW | 2 MHz | ~350 ps | <2% | <1.1 | FC/APC | PVC | Random | <15 | Air cooled | 15-35 | 12V/11.5A | >10000 | Datasheet |
| FL-SC-OEM (200~350 mW) | 470~2400 nm | 200~350 mW | 4 MHz | ~350 ps | <1% | <1.1 | FC/APC | PVC | Random | <15 | Air cooled | 15-35 | 12V/11.5A | >10000 | Datasheet |
| FL-SC-OEM (350~500 mW) | 470~2400 nm | 350~500 mW | 50kHz~200kHz, 1 MHz | ~350 ps | <1% | <1.1 | FC/APC | PVC | Random | <15 | Air cooled | 15-35 | 12V/11.5A | >10000 | Datasheet |
| FL-SC-OEM (500~1000 mW) | 470~2400 nm | 500~1000 mW | 1 MHz | 1.5 ns | <2%, <1% | <1.1 | FC/APC | PVC | Random | <15 | Air cooled | 15-35 | 12V/11.5A | >10000 | Datasheet |
470nm Blue Laser, Blue Diode Laser, Diode Laser Module |
2 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| FC-470 | 470 nm | 1~20 W | |
| MDL-470(FC) | 470 nm | 1 mW~14 W |
Ultra Compact OEM Laser,405 NM 1319 NM OEM Laser |
21 models| Model | Wavelength | Output / average power | Spectral linewidth | Power stability | Optical noise | M² | Fiber type | Fiber connector | Spectral line width (nm) | Fiber Core diameter | Fiber length | Fiber jacket | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Operating voltage (VDC) | Expected lifetime (hours) | Transverse mode | Beam divergence, full angle (mrad) | Pointing Stability Over Temperature (urad/°C) | Polarization ratio | Power supply (12VDC) | Storage temperature (℃) | Fiber Core Diameter (um) | Fiber Connector | Fiber lengths | Modulation option | Fiber Jacket | Operating temperature (℃) | Operating voltage (VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-OEM-1064-A | 1064 nm | 500 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-1064-B | 1064 nm | 1000 mW | – | <2%, <1%, <0.5% | – | – | MM fiber | SMA905, FC/PC optional | <0.2, (<0.1 optional) | 105μm, 0.22NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-460 | 460 nm | 50 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-488 | 488 nm | 150 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-514.5 | 514 nm | 10 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-637 | 637 nm | 100 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-660 | 660 nm | 80 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-670 | 670 nm | 80 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-680 | 680 nm | 20 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-685 | 685 nm | 20 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-705 | 705 nm | 15 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-880 | 880 nm | 2 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| FC-OEM-905 | 905 nm | 400 mW | – | <2%, <1%, <0.5% | – | 1.1 | SM fiber, PM fiber optional | FC/PC, FC/APC optional | – | 4-9μm, 0.12NA | 0.8m | 0.9mm PVC | <5 | Conduction | 10-35 | 5V | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| OEM-I-532 | 532 nm | 1-5000 mW | – | <3%, <2%, (<1% optional) | – | – | – | – | – | – | – | – | – | – | – | – | >10000 | Near TEM00 | ~1.0 | <20 | >50:1(100:1 optional), Horizontal(Vertical optional) | PSU-OEM-I / PSU-I-HS | – | – | – | – | – | – | – | – | Datasheet |
| OEM-S-561-MD | 561 nm | 1-800 mW | – | <5% (<1% optional) | – | – | – | – | – | – | – | – | <10 | – | – | – | >10000 | TEMn1 | – | – | – | – | 0-60 | – | – | – | – | – | – | – | Datasheet |
| OEM-S-588-MD | 588 nm | 1-800 mW | – | <5% (<1% optional) | – | – | – | – | – | – | – | – | <10 | – | – | – | >10000 | TEMn1 | – | – | – | – | 0-60 | – | – | – | – | – | – | – | Datasheet |
| YL-I-638/520/450/808/1064 | 638 nm | 74 W | – | <2%, <1% | – | – | – | – | – | – | – | – | – | – | – | – | >10000 | – | – | – | – | – | -20-50 | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | – | – | – | Datasheet |
| YL-I-638/520/450/808/980 | 638 nm | 71 W | – | <2%, <1% | – | – | – | – | – | – | – | – | – | Air cooled | – | – | >10000 | – | – | – | – | – | -20-50 | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | PVC, Metal optional | – | – | Datasheet |
| YL-I-638/525/450/808/980 | 638 nm | 71 W | – | <2%, <1% | – | – | – | – | – | – | – | – | – | Air cooled | – | – | >10000 | – | – | – | – | – | -20-50 | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | PVC, Metal optional | – | – | Datasheet |
| YL-I-640 | 640 nm | 8 W | 2 nm | <2%, <1% | 0.5% | – | – | – | – | – | – | – | <5 | Air cooled | – | – | >10000 | – | – | – | – | – | – | 100, 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | – | PVC, Metal optional | 0-30 | 100-240 | Datasheet |
| YL-I-660 | 660 nm | 8 W | 2 nm | <2%, <1% | 0.5% | – | – | – | – | – | – | – | <5 | Air cooled | – | – | >10000 | – | – | – | – | – | – | 200, 400, 600, 0.22NA | SMA905, FC/PC optional | 1m | – | PVC, Metal optional | 0-30 | 100-240 | Datasheet |
1305nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| FC-OEM-1305 | 1305 nm | 1~15 mW | |
| MDL-III-1305DFB-SM | 1305 nm | 1~15 mW | |
| MDL-III-1305-SM | 1305 nm | 1~15 mW |
1658nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber length | Fiber jacket | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Operating voltage (VDC) | Expected lifetime (hours) | Transverse mode | Power supply (100-240VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-OEM-1658 | 1658 nm | 1~5 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | 0.8m | 0.9mm PVC | ~1.1 | <5 | Conduction | 10-35 | 5V | >10000 | – | – | Datasheet |
| MDL-III-1658DFB-SM | 1658 nm | 1~5 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | – | Metal, PVC optional | ~1.1 | <5 | Conduction | 10-35 | – | >10000 | TEM00 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
| MDL-III-1658-SM | 1658 nm | 1~5 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | – | Metal, PVC optional | ~1.1 | <5 | Conduction | 10-35 | – | >10000 | TEM00 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
1742nm DFB Laser, Infrared Laser, DPSS Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber length | Fiber jacket | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Operating voltage (VDC) | Expected lifetime (hours) | Transverse mode | Power supply (100-240VAC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-OEM-1742 | 1742 nm | 1~5 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | 0.8m | 0.9mm PVC | ~1.1 | <5 | Conduction | 10-35 | 5V | >10000 | – | – | Datasheet |
| MDL-III-1742DFB-SM | 1742 nm | 1~5 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | – | Metal, PVC optional | ~1.1 | <5 | Conduction | 10-35 | – | >10000 | TEM00 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
| MDL-III-1742-SM | 1742 nm | 1~5 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | – | Metal, PVC optional | ~1.1 | <5 | Conduction | 10-35 | – | >10000 | TEM00 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | Datasheet |
505 NM Green Laser, Diode Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber length | Fiber jacket | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Operating voltage (VDC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-OEM-505 | 505 nm | 1~30 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | 0.8m | 0.9mm PVC | ~1.1 | <5 | Conduction | 10-35 | 5V | >10000 | Datasheet |
| MDL-III-505L | 505 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XS-G-505/SM/1-2/50 | 505 nm | >10 mW | – | – | – | – | – | – | – | – | – | – | – | – |
High Power Laser Diode Module |
93 models| Model | Wavelength | Output / average power | Operating Voltage | Fiber Core Diameter | Fiber Length | Fiber Connector | Operating Temperature | Operating Relative Humidity | Cooling Mode | Storage Temperature | Storage Relative Humidity | Lead Soldering Temperature(10 s max) | Fiber Cladding Diameter | Fiber Buffer Diameter | Main power supply port | Operating Voltage(Simplex) | Fiber Armor | Lead Soldering Temperature (10 s max) | Weight | Lead Soldering Temperature, 10 s max | Soldering | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LDM-1064-100-2 | 1064 nm | 100 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1064-10-2 | 1064 nm | 10 W | - / 1.7 / - / V | - / 200 / - / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1064-30-2 | 1064 nm | 30 W | - / 5 / - / V | 200 / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1064-976-808-2 | 1064 nm | 10/ 10 W/ 10 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1064-980-915-808-640-450-4 | 1064 nm | 15/ 15 W/ 15/ 15/ 0. 5/ 6 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1470-10-2 | 1470 nm | 10 W | 5.3 / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | 220 | - / 500 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-1470-15-2 | 1470 nm | 15 W | 9.5 / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | 220 | - / 500 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-1470-30-2 | 1470 nm | 30 W | - / 21.0 / 22.0 / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 10 / 40 | - / 75 / % | – | -20 / 80 | - / 90 / % | - / 250 / ℃ | 220 | 500 | – | – | – | – | – | – | – | Datasheet |
| LDM-1470-50-2 | 1470 nm | 50 W | - / 20.2 / - / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | – | -20 / 80 / ℃ | - / 90 / % | - / 250 | 220 | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1470-5-2 | 1470 nm | 5 W | - / 3.26 / - / V | 200 / μm | 1-5 / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | - / 220 / - / μm | - / 500 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-1470-980-2 | 1470 nm | 30/ 30 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1470-980-635-2 | 1470 nm | 15/ 15 W/ 0.2 | – | m | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1470-980-640-2 | 1470 nm | 15/ 18 W/ 0.2 | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1550-10-2 | 1550 nm | 10 W | - / 8.6 / - / V | - / 200 / - / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1550-15-2 | 1550 nm | 15 W | 12 / V | 200 / μm | 1-5 / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-1940-15-2 | 1940 nm | 15 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-100-6 | 405 nm | 100 W | – | 600 / μm | 2 / m | SMA905-SMA905 / - | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-10-2 | 405 nm | 10 W | - / 17.2 / - / V | - / 200 / - / μm | - / 1-5 / - / m | – | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | - / 220 / - / μm | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-150-8 | 405 nm | 150 W | – | 800 / μm | 2 / m | Fixed-SMA905 / - | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-16-2 | 405 nm | 16 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-20-4 | 405 nm | 20 W | – | 400 / μm | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-24-4 | 405 nm | 24 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-30-4 | 405 nm | 30 W | – | 400 / μm | – | SMA905 / - | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-50-6 | 405 nm | 50 W | – | 600 / μm | 2 / m | SMA905-SMA905 / - | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-60-6 | 405 nm | 60 W | – | 600 / μm | 2 / m | SMA905-SMA905 / - | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-405-8-2 | 405 nm | 8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-450-100-1 | 450 nm | 100 W | – | 105 / μm | - / 2.5 / - / m | - / SMA905/ D80/ QBH / - / - | 15 / 35 | - / 75 / % | – | -20 / 50 | – | – | – | – | Monitor port / Indication light | - / 33 / - / V | - / Optional / - / - | - / 250 / ℃ | 3.8 / kg | – | – | Datasheet |
| LDM-450-10-1 | 450 nm | 10 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-450-15-1 | 450 nm | 15 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-450-200-2 | 450 nm | 200 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-450-30-1 | 450 nm | 30 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-450-3-1 | 450 nm | 3 W | 4.8 / V | 105 / μm | - / 1-5 / - / m | – | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | - / 250 | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-450-40-1 | 450 nm | 40 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-450-50-0.5 | 450 nm | 50 W | – | 50 / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | – | -20 / 50 | – | – | – | – | – | - / 36 / - / V | - / Optional / - / - | - / 250 | – | – | – | Datasheet |
| LDM-520-10-1 | 520 nm | 10 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-520-20-2 | 520 nm | 20 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-520-40-2 | 520 nm | 40 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-520-4-1 | 520 nm | 4 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-520-70-4 | 520 nm | 70 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-520-7-1 | 520 nm | 7 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-638-10-2 | 638 nm | 10 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-638-20-2 | 638 nm | 20 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-638-2.5-1 | 638 nm | 2.5 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-638-30-4 | 638 nm | 30 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-638-40-4 | 638 nm | 40 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-638-5-1 | 638 nm | 5 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-638-7-1 | 638 nm | 7 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-660-10-2 | 660 nm | 10 W | - / 16.5 / - / V | - / 200 / - / μm | 1-5 / m | – | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | – | - / 220 / - / μm | - / 500 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-660-15-2 | 660 nm | 15 W | - / 18.6 / - / V | - / 200 / - / μm | 1-5 / m | – | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | – | - / 220 / - / μm | - / 500 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-660-3-2 | 660 nm | 3 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-660-6-2 | 660 nm | 6 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-660-8-2 | 660 nm | 8 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-793-10-1 | 793 nm | 10 W | - / 3.8 / - / V | - / 105 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | – | -20 / 80 | - / 90 / % | - / 250 / ℃ | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-793-20-1 | 793 nm | 20 W | - / 7.6 / - / V | - / 105 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | – | -20 / 80 | - / 90 / % | – | - / 125 / - / μm | - / 250 / - / μm | – | – | – | - / 250 / ℃ | – | – | – | Datasheet |
| LDM-793-30-1 | 793 nm | 30 W | - / 11.3 / - / V | - / 105 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | – | -20 / 80 | - / 90 / % | – | - / 125 / - / μm | - / 250 / - / μm | – | – | – | - / 250 / ℃ | – | – | – | Datasheet |
| LDM-793-50-1 | 793 nm | 50 W | 22.7 / V | - / 105 / - / μm | - / 1-5 / - / m | SMA905 / - | 15 / 35 | - / 75 / % | – | -20 / 80 / ℃ | - / 90 / % | – | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | - / 250 | – | Datasheet |
| LDM-793-5-1 | 793 nm | 5 W | - / 1.9 / - / V | - / 105 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | – | -20 / 80 | - / 90 / % | - / 250 | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-793-90-1 | 793 nm | 90 W | - / 34 / - / V | - / 105 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | – | -20 / 80 | - / 90 / % | – | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | - / 250 / ℃ | – | Datasheet |
| LDM-808-100-4 | 808 nm | 100 W | - / 15 / - / V | - / 400 / - / μm | 1-5 / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | - / 440 | - / 700 | – | – | – | – | – | – | – | Datasheet |
| LDM-808-14-4 | 808 nm | 14 W | - / 3.6 / - / V | - / 400 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | - / 250 | 440 | - / 700 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-808-200-4 | 808 nm | 200 W | - / 28.8 / - / V | - / 400 / - / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | – | - / 440 / - / μm | - / 700 / - / μm | – | – | – | - / 250 / ℃ | – | – | – | Datasheet |
| LDM-808-20-4 | 808 nm | 20 W | - / 5.58 / - / V | - / 400 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | - / 250 | 440 | - / 700 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-808-300-2 | 808 nm | 300 W | – | – | – | – | – | – | thermal conduction | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-808-30-4 | 808 nm | 30 W | - / 7.1 / - / V | - / 400 / - / μm | – | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 / ℃ | - / 440 / - / μm | - / 700 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-808-4.5-1 | 808 nm | 4.5 W | - / 1.8 / - / V | - / 105 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | – | -20 / 80 | - / 90 / % | - / 250 / ℃ | 125 | - / 250 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-808-500-8 | 808 nm | 500 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-808-50-4 | 808 nm | 50 W | - / 11.1 / - / V | - / 400 / - / μm | 1-5 / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | - / 440 / - / - | - / 700 | – | – | – | – | – | – | – | Datasheet |
| LDM-878.6VBG-100-2 | 878 nm | 100 W | - / 15.8 / 18.0 / V | - / 200/400 / - / μm | - / 1-5 / - / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-878.6VBG-120-2 | 878 nm | 120 W | - / 21.1 / 24.0 / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | – | 220 | - / 500 / - / μm | – | – | – | – | – | – | Temperature(10 / s | Datasheet |
| LDM-878.6VBG-180-4 | 878 nm | 180 W | - / 28.5 / - / V | - / 400 / - / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | – | - / 440 / - / μm | - / 700 / - / μm | – | – | – | - / 250 / ℃ | – | – | – | Datasheet |
| LDM-878.6VBG-30-2 | 878 nm | 30 W | - / 5.3 / 6.0 / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | – | - / 220 / - / μm | 500 | – | – | – | - / 250 / ℃ | – | – | – | Datasheet |
| LDM-878.6VBG-40-2 | 878 nm | 40 W | – | - / 200 / - / μm | - / 1-5 / - / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | – | - / 220 / - / μm | 500 | – | – | – | - / 250 | – | – | – | Datasheet |
| LDM-878.6VBG-70-2 | 878 nm | 70 W | - / 12.3 / 14.0 / V | - / 200 / - / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | – | 220 | 500 | – | – | – | – | – | – | Temperature / (10 / s | Datasheet |
| LDM-915-100-2 | 915 nm | 100 W | 12.25 / V | – | 1-5 / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-915-150-4 | 915 nm | 150 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-915-200-4 | 915 nm | 200 W | - / 22.4 / 25.0 / V | - / 400 / - / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | – | - / 440 / - / μm | - / 700 / - / μm | – | – | – | - / 250 / ℃ | – | – | – | Datasheet |
| LDM-915-300-2 | 915 nm | 300 W | - / 29.7 / - / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 / ℃ | - / 220 / - / μm | 500 | – | – | – | – | – | – | – | Datasheet |
| LDM-915-30-2 | 915 nm | 30 W | 3.4 / V | - / 200 / - / μm | 1-5 / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-915-50-2 | 915 nm | 50 W | - / 8.7 / - / V | - / 200 / - / μm | - / 1-5 / - / m | – | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-940-100-2 | 940 nm | 100 W | - / 15.4 / - / V | - / 200 / - / μm | 1-5 / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | - / 220 / - / μm | - / 500 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-940-170-1 | 940 nm | 170 W | 32 / V | 105 / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | – | - / 125 / - / - | 250 / - | – | – | – | – | – | – | – | Datasheet |
| LDM-940-200-2 | 940 nm | 200 W | 31 / V | 200 / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 / ℃ | - / 220 / - / μm | - / 500 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-940-80-1 | 940 nm | 80 W | - / 14.4 / - / V | - / 105 / - / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 / ℃ | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 / ℃ | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-976VBG-100-1 | 976 nm | 100 W | - / 24.2 / 24.8 / V | - / 105 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | – | 125 | 250 | – | – | – | – | – | – | – | Datasheet |
| LDM-976VBG-140-1 | 976 nm | 140 W | - / 28.9 / 29.5 / V | - / 105 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | – | 125 | 250 | – | – | – | – | – | – | – | Datasheet |
| LDM-976VBG-30-1 | 976 nm | 30 W | 7.2 / V | 105 / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | - / 250 | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-976VBG-60-1 | 976 nm | 60 W | - / 12 / V | - / 105 / - / μm | 1-5 / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-976VBG-9-1 | 976 nm | 9 W | 1.62 / V | 105 / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 / ℃ | - / 90 / % | - / 250 | - / 125 / - / μm | - / 250 / - / μm | – | – | – | – | – | – | – | Datasheet |
| LDM-980-100-2 | 980 nm | 100 W | 13.6 / V | 200 / μm | 1-5 / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-980-200-4 | 980 nm | 200 W | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-980-300-2 | 980 nm | 300 W | - / 28.5. / - / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | - / 220 / - / μm | 500 | – | – | – | – | – | – | – | Datasheet |
| LDM-980-30-2 | 980 nm | 30 W | - / 5.1 / - / V | – | - / 1-5 / - / m | SMA905 / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | - / 250 | – | – | – | – | – | – | – | – | – | Datasheet |
| LDM-980-50-2 | 980 nm | 50 W | - / 8.5 / - / V | - / 200 / - / μm | - / 1-5 / - / m | - / SMA905 / - / - | 15 / 35 | - / 75 / % | - / Water cooling(25℃) / - | -20 / 80 | - / 90 / % | – | – | – | – | – | – | – | – | – | – | Datasheet |
1710 NM IR Laser, Infrared Diode Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-1710(FC) | 1710 nm | 1~430 mW |
410 NM Blue Violet Diode Laser.
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-410(FC) | 410 nm | 1~250 mW |
415 NM Blue Violet Diode Laser.
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-415(FC) | 415 nm | 1~250 mW | |
| MDL-III-415 | 415 nm | 1~300 mW | |
| MDL-III-415L | 415 nm | 1~100 mW |
440 NM Laser, Violet Blue Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-440(FC) | 440 nm | 1~2500 mW |
740 NM RED Diode Laser.
3 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-740(FC) | 740 nm | 1~2000 mW | |
| MDL-H-740 | 740 nm | 1~1000 mW | |
| MDL-XF-740 | 740 nm | 1~2.5 W |
755 NM RED Laser, RED Diode Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-755(FC) | 755 nm | 1~2600 mW |
Long Coherence Length MDL C Series Diode Lasers |
5 models| Model | Wavelength | Output / average power | Power stability | M² | Transverse mode | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-C-488 | 488 nm | 1~70 mW | <3%, <2%, <1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-C-514.5 | 514.5 nm | 1~20 mW | <3%, <2%, <1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-C-635 | 635 nm | 1~50 mW | <3%, <2%, <1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-C-637 | 637 nm | 1~50 mW | <3%, <2%, <1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-C-660 | 660 nm | 1~80 mW | <3%, <2%, <1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
Ultra Narrow Linewidth MDL E Series Diode Lasers |
7 models| Model | Wavelength | Output / average power | Spectral linewidth | Power stability | Optical noise | M² | Transverse mode | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-E-410 | 410 nm | 1~50 mW | <0.06 nm, <0.03 | <3%, <2%, <1% | ~1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-E-417.5 | 417.5 nm | 1~50 mW | <0.06 nm, <0.03 | <3%, <2%, <1% | ~1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-E-488 | 488 nm | 1~70 mW | <0.06 nm, <0.03 | <3%, <2%, <1% | ~1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-E-514.5 | 514.5 nm | 1~20 mW | <0.06 nm, <0.03 | <3%, <2%, <1% | ~1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-E-635 | 635 nm | 1~50 mW | <0.06 nm, <0.03 | <3%, <2%, <1% | ~1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-E-637 | 637 nm | 1~50 mW | <0.06 nm, <0.03 | <3%, <2%, <1% | ~1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
| MDL-E-660 | 660 nm | 1~80 mW | <0.06 nm, <0.03 | <3%, <2%, <1% | ~1% | <1.5 | Near TEM00 | <5 | Conduction | 20-30 | PSU-A-D | >10000 | Datasheet |
420nm Violet Blue Laser, Diode Laser, Violet Laser |
4 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-H-420 | 420 nm | 500~1300 mW | |
| MDL-III-420 | 420 nm | 1~500 mW | |
| MDL-III-420L | 420 nm | 1~100 mW | |
| MDL-420(FC) | 420 nm | 1~320 mW |
635 NM RED Diode Laser.
16 models| Model | Wavelength | Output / average power | Spectral line width (nm) | Power stability (rms, 4 hours ± 3°C) | Fiber | linewidth, short coherent length, long | Transverse mode | M2 after fiber | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-HD-635 | 635 nm | 1.5~3 W | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-635 | 635 nm | 1~1000 mW | ~5 | <2%, <1%, <0.5% | 1m | Fiber jacket / Metal, PVC optional | TEM00 | ~1.1 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-635L | 635 nm | 1~200 mW | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-635R | 635 nm | 1~150 mW | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-635-SM | 635 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | |
| MDL-MD-635 | 635 nm | 1~1500 mW | – | – | – | – | – | – | – | – | – | – | |
| MDL-XD-635 | 635 nm | 3~8 W | – | – | – | – | – | – | – | – | – | – | |
| PGL-D12-635 | 635 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | |
| PGL-D8-635 | 635 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | |
| PGL-FP-635 | 635 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | |
| PGL-FS-635 | 635 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | |
| PGL-H-635 | 635 nm | 1~500 mW | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-635 | 635 nm | 1~130 mW | – | – | – | – | – | – | – | – | – | – | |
| PGL-V-H-635 | 635 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | |
| PGL-V-H-FC-635 | 635 nm | 1~500 mW | – | – | – | – | – | – | – | – | – | – | |
| PGL-VI-635 | 635 nm | 1~120 mW | – | – | – | – | – | – | – | – | – | – |
660 NM RED Diode Laser.
9 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | Transverse mode | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-HD-660 | 660 nm | 1.5~3 W | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-660D | 660 nm | 1~1000 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-660L | 660 nm | 1~180 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-660R | 660 nm | 1~200 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-660-SM | 660 nm | 1~80 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, SMA905 optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-MD-660 | 660 nm | 1~1500 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-XD-660 | 660 nm | 3~4.5 W | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-F-660 | 660 nm | 1~50 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-660 | 660 nm | 1~130 mW | – | – | – | – | – | – | – | – | – | – | – | – |
SM Fiber Coupled Laser |
12 models| Model | Wavelength | Output / average power | Power stability | M² | Spectral line width (nm) | Transverse mode | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | machine vision, metrology, fiber optic | Fiber | linewidth, short coherent length, long | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-1300-SLD | 1300 nm | 1~10 mW | <2%, <1%, <0.5% | <1.5 | ~40 | Near TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1300-SLD-SM | 1300 nm | 1~10 mW | <2%, <1%, <0.5% | 1.1 | ~40 | TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | M2 after fiber / ~1.1 | – | – | Datasheet |
| MDL-III-1550-SLD | 1550 nm | 1~8 mW | <2%, <1%, <0.5% | <1.5 | ~60 | Near TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | Datasheet |
| MDL-III-1550-SLD-SM | 1550 nm | 1~8 mW | <2%, <1%, <0.5% | 1.1 | ~60 | TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | M2 after fiber / ~1.1 | – | – | Datasheet |
| MDL-III-514.5-SM | 514.5 nm | 1~10 mW | <2%, <1%, <0.5% | 1.1 | – | TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, SMA905 optional | Metal, PVC optional | – | – | – | Datasheet |
| MDL-III-635-SLD | 635 nm | 1~8 mW | <2%, <1%, <0.5% | <1.5 | ~5 | Near TEM00 | – | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | Datasheet |
| MDL-III-635-SLD-SM | 635 nm | 1~8 mW | <2%, <1%, <0.5% | 1.1 | ~5 | TEM00 | – | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | 1m | Fiber jacket / Metal, PVC optional | Datasheet |
| MDL-III-820-SLD | 820 nm | 1~12 mW | <2%, <1%, <0.5% | <1.5 | ~25 | Near TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | Datasheet |
| MDL-III-820-SLD-SM | 820 nm | 1~12 mW | <2%, <1%, <0.5% | 1.1 | ~25 | TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | 1m | Fiber jacket / Metal, PVC optional | Datasheet |
| MDL-III-850-SLD | 850 nm | 1~4 mW | <2%, <1%, <0.5% | <1.5 | ~35 | Near TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | Datasheet |
| MDL-III-850-SLD-SM | 850 nm | 1~4 mW | <2%, <1%, <0.5% | 1.1 | ~35 | TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | 1m | Fiber jacket / Metal, PVC optional | Datasheet |
| MDL-III-915-SM | 915 nm | 1~400 mW | <2%, <1%, <0.5% | 1.1 | – | TEM00 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | – | – | – | Datasheet |
670 NM RED Laser.
2 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | Transverse mode | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-670L | 670 nm | 1~100 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-670-SM | 670 nm | 1~80 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 4-9μm, 0.12NA | FC/PC, SMA905 optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
Infrared Laser, 845 NM Infrared Diode Lasers.
3 models| Model | Wavelength | Output / average power | Spectral linewidth | Power stability | M² | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Storage temperature (°C) | Humidity (%) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-845L | 845 nm | – | High Stability Infrared Laser nm | <2%, <1%, <0.5% | <1.5 | <1.0 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | – | – | – | – | – | – | – | Datasheet |
| MDL-845(FC) | 845 nm | 1~25 mW | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | – | |
| PGL-LF-845 | 845 nm | 1~10 mW | – | – | – | – | – | – | -10°C to +45°C | – | – | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -20°C to +80°C | < 90 %, non-condensing | 45g | Datasheet |
Nanosecond Pulse Diode Laser |
6 models| Model | Wavelength | Output / average power | Repetition rate | Pulse width | Power stability | M² | Transverse mode | Beam divergence, full angle (mrad) | Modulation Depth (extinction ratio) | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Operating voltage (VDC) | Expected lifetime (hours) | Operating temperature (°C) | Pulse width (FWHM) | Rep. | medical equipment manufacturing, etc. | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-III-P-1550 | 1550 nm | ~15.3 ( @6 kHz) | 1~6 kHz | ~150 ns ( @6 kHz) | – | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| MDL-NS-1550 | 1550 nm | 1-10 mW | – | – | <2%, <1%, <0.5% | <1.5 | Near TEM00 | <3.0 | >1000000:1 | <5 | Conduction | 10-35 | 12V/3.34A | >10000 | – | – | – | – | Datasheet |
| MDL-NS-488 | 488 nm | 1-100 mW | – | – | <2%, <1%, <0.5% | <1.2 | Near TEM00 | <1.0 | >1000000:1 | <5 | Conduction | – | 12V/3.34A | >10000 | 10-35 | – | – | – | Datasheet |
| MDL-NS-635 | 635 nm | 1-200 mW | – | – | <2%, <1%, <0.5% | <1.2 | Near TEM00 | <1.0 | >1000000:1 | <5 | Conduction | 10-35 | 12V/3.34A | >10000 | – | 10ns-10ms / 10ns-10ms | DC-40MHz / DC-25MHz | – | Datasheet |
| MDL-NS-637 | 637 nm | 1-200 mW | – | – | <2%, <1%, <0.5% | <1.2 | Near TEM00 | <1.0 | >1000000:1 | <5 | Conduction | 10-35 | 12V/3.34A | >10000 | – | 10ns-10ms / 10ns-10ms | DC-40MHz / DC-25MHz | – | Datasheet |
| MDL-NS-660 | 660 nm | 1~180 mW | – | – | <2%, <1%, <0.5% | <1.2 | – | <1.0 | – | <5 | Conduction | 10-35 | 12V/3.34A | >10000 | – | 10ns-10ms / 15ns-10ms | DC-30MHz / DC-30MHz | Modulation Depth (extinction ratio) / >1000000:1 | Datasheet |
Picosecond Diode Laser |
4 models| Model | Wavelength | Output / average power | Repetition rate | Power stability | Pulse width (ps) | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Operating voltage (VDC) | Expected lifetime (hours) | Operating temperature (℃) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-PS-488 | 488 nm | 1~50 mW | 0.1~20 MHz | <3%, <2%, <1% | 100-1000 | Near TEM00 | ~1.0 | <5 | Air cooled | 10-35 | 12V/3.34A | >10000 | – | Datasheet |
| MDL-PS-635 | 635 nm | 1~50 mW | 0.1~80 MHz | <3%, <2%, <1% | 100-1000 | Near TEM00 | ~1.0 | <5 | Air cooled | – | 12V/3.34A | >10000 | 10-35 | Datasheet |
| MDL-PS-637 | 637 nm | 1~50 mW | 0.1~80 MHz | <3%, <2%, <1% | 100-1000 | Near TEM00 | ~1.0 | <5 | Air cooled | – | 12V/3.34A | >10000 | 10-35 | Datasheet |
| MDL-PS-660 | 660 nm | 1~50 mW | 0.1~20 MHz | <3%, <2%, <1% | 100-1000 | Near TEM00 | ~1.0 | <5 | Air cooled | 10-35 | 12V/3.34A | >10000 | – | Datasheet |
Diode MDL XS Series Lasers |
2 models| Model | Wavelength | Output / average power | Power stability | M² | Transverse mode | Noise of amplitude (rms, 20Hz-20MHz) | Beam divergence, full angle (mrad) | Warm-up time (minutes) | monitoring, | Operating temperature (℃) | Operating voltage (VDC) | Modulation option | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-XS-635 | 635 nm | 1~100 mW | <2%, <1%, <0.5% | <1.2 | Near TEM00 | <1%, <0.5% | <1.0 | <5 | inspection | 10-35 | 12V/4A | AMOD (Analog) DC-100kHz | >10000 | Datasheet |
| MDL-XS-660 | 660 nm | 1~80 mW | <2%, <1%, <0.5% | <1.2 | Near TEM00 | <1%, <0.5% | <1.0 | <5 | inspection | 10-35 | 12V/4A | AMOD (Analog) DC-100kHz | >10000 | Datasheet |
High Stability 532nm Laser |
3 models| Model | Wavelength | Output / average power | Power stability | M² | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Operating temperature (°C) | Modulation optional | Power supply (100-240VAC) | Expected lifetime (hours) | Beam diameter at the aperture (1/e2, mm) | Beam divergence (mrad) | Pointing stability over temperature (μrad/°C) | Power supply (12VDC) | Polarization ratio | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MGL-FN-532 | 532 nm | 1500~4000 mW | <1% | <1.2 | TEM00 | <1.5 | <5 | 10-35 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | – | – | – | – | – | Datasheet |
| MGL-U-532 | 532 nm | 300~1500 mW | <0.5% | <1.2 | TEM00 | – | <5 | 10-35 | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional | PSU-H-FDA/PSU-H-LED/PSU-SR | >10000 | <1.0 | <1.5 | <8 | PSU-SR-OEM (12V/25A) | – | Datasheet |
| MGL-W-532A | 532 nm | 10~20 W | <1% | – | Near TEM00 | <2.0 | <10 | 10-35 | – | PSU-W-FDA/PSU-W-LED | >10000 | – | – | – | – | >50:1(>100:1 optional), Horizontal(Vertical optional) | Datasheet |
THE Manufacturer Miniature OEM Laser Module AT 1064nm
8 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MIL-S-1064-OEM | 1064 nm | 1~1500 mW | |
| PGL-FP-1064 | 1064 nm | 1~10 mW | |
| PGL-FS-1064 | 1064 nm | 1~500 mW | |
| PGL-H1-1064 | 1064 nm | 1~800 mW | |
| PGL-LF-1064 | 1064 nm | 1~10 mW | |
| PGL-V-H-1064 | 1064 nm | 1~800 mW | |
| PGL-V-H-FC-1064 | 1064 nm | 1~1000 mW | |
| S-1064-OEM | 1064 nm | 1~1500 mW |
THE Manufacturer LOW Noise 1064nm Laser
1 model| Model | Wavelength | Output / average power | Spectral linewidth | Power stability | Optical noise | Transverse mode | Beam divergence, full angle (mrad) | Warm-up time (minutes) | Pointing Stability Over Temperature (urad/°C) | Polarization ratio | Cooled method | Operating temperature (°C) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MLL-K-1064-OEM | 1064 nm | 20~40 W | <0.1 nm | <2%, <1%, <0.5% | <0.5% | TEM00 | ~1 | <10 | <20 | >50:1(>100:1 optional), Horizontal(Vertical optional) | Conduction | 25 | >10000 | Datasheet |
Compact Laser Module, Small Size Laser Modules |
3 models| Model | Wavelength | Output / average power | Transverse mode | Beam divergence, full angle (mrad) | Expected lifetime (hours) | Warranty (years) | Operating voltage(external PCB1) | Connection | Operating temperature | Storage temperature | Humidity | Operating voltage | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PGL-D12 | 405 nm | 1-100 mW | Near TEM00 | <0.5 | 10000 | 1 | 6VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90 %, non-condensing | – | Datasheet |
| PGL-D8 | 405 nm | 1-50 mW | Near TEM00 | <0.5 | 10000 | 1 | 6VDC | Cable with flying leads | 0°C to 40°C | -20°C to 80°C | <90%, non-condensing | – | Datasheet |
| PGL-H1 | 473 nm | 1-50 mW | – | – | – | – | – | – | – | – | – | 5VDC | Datasheet |
561 NM Yellow Green Laser.
2 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| PGL-H1-561 | 561 nm | 1~10 mW | |
| PGL-VI-561 | 561 nm | 1~5 mW |
860 NM IR Laser, Infrared Diode Laser |
2 models| Model | Wavelength | Output / average power | |
|---|---|---|---|
| PGL-LF-860 | 860 nm | 1~10 mW | |
| MDL-860(FC) | 860 nm | 1~4800 mW |
570 NM Yellow Laser, Solid State Laser, Yellow Laser Module |
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Fiber NA | Fiber Connector | Fiber Length (m) | Warm-up time (minutes) | Operating temperature (℃) | Cooling way | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-570 | 570 nm | 1~180 mW | <1%, <2%, <3%, <5% | 0.22 | SMA905 | 1 (Other lengths are available on request) | <5 | 10~35 | By air | 10000 | 1 year | Datasheet |
| MGL-570(FC) | 570 nm | 1~180 mW | – | – | – | – | – | – | – | – | – |
577 NM Yellow Laser, Solid State Laser, Yellow Laser Module |
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Fiber NA | Fiber Connector | Fiber Length (m) | Warm-up time (minutes) | Operating temperature (℃) | Cooling way | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-577 | 577 nm | 1~1100 mW | <1%, <2%, <3%, <5% | 0.22 | SMA905 | 1 (Other lengths are available on request) | <5 | 10~35 | By air | 10000 | 1 year | Datasheet |
| MGL-577(FC) | 577 nm | 1~3200 mW | – | – | – | – | – | – | – | – | – |
585 NM Yellow Laser, Solid State Laser, Yellow Laser Module |
2 models| Model | Wavelength | Output / average power | Power stability (rms, over 4 hours) | Fiber NA | Fiber Connector | Fiber Length (m) | Warm-up time (minutes) | Operating temperature (℃) | Cooling way | Expected lifetime (hours) | Warranty | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FC-585 | 585 nm | 1~45 mW | <1%, <2%, <3%, <5% | 0.22 | SMA905 | 1 (Other lengths are available on request) | <5 | 10~35 | By air | 10000 | 1 year | Datasheet |
| MGL-585(FC) | 585 nm | 1~45 mW | – | – | – | – | – | – | – | – | – |
1120 NM IR Laser, Infrared Diode Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-1120(FC) | 1120 nm | 1~4000 mW |
1480nm TEM00 Mode Laser, Infrared Laser, DPSS Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-1480(FC) | 1480 nm | 1~400 mW |
405 NM Blue Violet Diode Laser.
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-405(FC) | 405 nm | 1 mW~30 W |
496 NM Blue Solid State Laser.
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-496(FC) | 496 nm | 1~135 mW |
665nm RED Laser, RED Diode Laser |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MDL-665(FC) | 665 nm | 1~1600 mW |
760 NM RED Laser, RED Diode Laser |
3 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Fiber type | Fiber Core diameter | Fiber connector | Fiber jacket | Transverse mode | M2 after fiber | Warm-up time (minutes) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDL-760(FC) | 760 nm | 1~4500 mW | – | – | – | – | – | – | – | – | – | – | – | – | |
| MDL-III-760-SM | 760 nm | 1~150 mW | <2%, <1%, <0.5% | SM fiber, PM fiber optional | 6μm, 0.12NA | FC/PC, FC/APC optional | Metal, PVC optional | TEM00 | ~1.1 | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
| MDL-III-760L | 760 nm | 1~150 mW | <2%, <1%, <0.5% | – | – | – | – | TEM00 | – | <5 | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
Green Laser, 514.5 NM Laser, Argon Laser |
1 model| Model | Wavelength | Output / average power | Power stability (rms, 4 hours ± 3°C) | Cooled method | Operating temperature (°C) | Power supply (100-240VAC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|
| MDL-III-514.5 | 514.5 nm | 1~50 mW | <2%, <1%, <0.5% | Conduction | 10-35 | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM | >10000 | Datasheet |
571 NM Yellow Laser, Solid State Laser, Yellow Laser Module |
1 model| Model | Wavelength | Output / average power | |
|---|---|---|---|
| MGL-571(FC) | 571 nm | 1~180 mW |
RGB Laser for Show,blue Laser,green Laser, RED Laser and Beam Combiner.
10 models| Model | Wavelength | Output / average power | Power stability (rms, 4 hours±3℃) | Cooled method | Warm-up time (minutes) | Operating temperature (℃) | Power supply (24VDC) | Expected lifetime (hours) | Power stability (rms, over 4 hours) | Polarization direction | Power supply (90-264VAC) | Warranty | Power Supply | Transverse mode | TTL / Analog modulation | Warranty time | Power supply | TTL modulation/ Analog modulation | Power supply (14VDC) | Warranty period | Power supply (12VDC) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OEM-AD-635 | 635 nm | 45-50 W | <2%, <1% | Air cooled | <5 | 0-30 | PSU-PNDT-OEM (24V/ 14.9A) | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | – | Datasheet |
| OEM-D-447 | 447 nm | 4~8 W | – | – | – | – | – | 10000 | <1%, <3%, <5% | Horizontal+ Vertical | PSU-6R-OEM/ PSU-6R-OEM-H | 1 year | Adapter | – | – | – | – | – | – | – | – | Datasheet |
| OEM-D-532 | 532 nm | 20~30 W | – | – | – | 22.5+/-2.5 | – | 10000 | <3%, <5% | – | – | – | – | Near TEM00 | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | 1 year | – | – | – | – | – | Datasheet |
| OEM-F-447 | 447 nm | 1~3.5 W | – | – | <5 | – | – | 10000 | – | – | – | 1 year | – | – | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | – | PSU-SD-OEM | – | – | – | – | Datasheet |
| OEM-F-465 | 465 nm | 1~3 W | – | – | – | 25+/-3 (OEM-F-465)/ 10-35 (F-465-HS) | – | 10000 | – | – | – | 1 year | – | – | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | – | PSU-SD-OEM | – | – | – | – | Datasheet |
| OEM-F-532 | 532 nm | 0.5~3 W | – | – | <5 | – | – | 5000 | – | – | – | – | – | Near TEM00 | – | 1 Year | – | TTL on/off, 1Hz-1KHz, 1KHz-10KHz, 10KHz-30KHz; and Analog modulation option | – | – | – | Datasheet |
| OEM-JD-635 | 635 nm | 35-40 W | – | Air cooled | <5 | 0-30 | – | >10000 | – | – | – | – | – | – | – | – | – | – | PSU-PNDT-OEM (14V/ 29A) | – | – | Datasheet |
| OEM-N-532 | 532 nm | 3~5 W | – | – | <10 | 22.5+/-2.5 | – | 10000 | – | – | – | – | – | Near TEM00 | TTL or Analog with 1Hz-1kHz 1kHz-10kHz, 10kHz-30kHz optional | – | – | – | – | 1 year | – | Datasheet |
| OEM-TD-635 | 635 nm | 25-30 W | <2%, <1% | Air cooled | – | 0-30 | – | >10000 | – | – | – | – | – | – | – | – | – | – | – | – | PSU-PNDT-OEM (12V/ 29A) | Datasheet |
| OEM-W-532 | 532 nm | 6~18 W | – | – | <10 | 22.5+/-2.5 | – | 10000 | <3%, <5% | – | – | – | – | – | – | 1 year | – | – | – | – | – | Datasheet |
639 NM RED Solid State Laser.
1 model| Model | Wavelength | Output / average power | Beam divergence (mrad) | Laser operation mode | Modulation optional | Connection | Operating temperature (°C) | Storage temperature (°C) | Humidity (%) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| PGL-LF-639 | 639 nm | 1~130 mW | <1.5 | CW | TTL 30kHz or analog (0-3V or 0-5V) | Cable with flying leads | -10°C to +45°C | -20°C to +80°C | < 90 %, non-condensing | 45g | Datasheet |
Not sure which model fits?
Send the physics — wavelength, mode, power or energy, linewidth or pulse width, delivery, control and safety — and we qualify the source.
