Zoom lenses
Zoom Lenses forMachine Vision & Inspection
Premium zoom optics, without the premium price.
C-mount zoom lenses from 0.21× to 7.6×: 12.5X, 14X and 6.5X continuous zoom lenses with detented or motorized zoom, coaxial illumination and fine focus; 4K zoom lenses for 1-inch sensors; linear-guide and telecentric zoom lenses. Every model has a full specification and a downloadable datasheet.
44
Zoom lenses
Each with its own datasheet
14:1
Highest zoom ratio
PMS-Z14, 0.55× to 7.6×
1 inch
Largest sensor
4K and high-resolution 6.5X lenses
0.21× – 7.6×
Magnification
Across the range
Widest zoom range on a 2/3-inch camera?
The 12.5X lenses cover 0.58× to 7.5× at a 77.4 mm working distance, the 14X lens 0.55× to 7.6× with coaxial illumination. The 6.5X lenses cover 0.7× to 4.5× at 80 to 87 mm.
A 1-inch sensor or 4K resolution?
The 4K zoom lenses cover 0.68× to 5.0× at 80 mm and reach 4K horizontal resolution on a 1-inch camera; the 6.5X high-resolution lens covers 0.7× to 4.5× at 88 mm.
Repeatable or automated magnification?
Detented versions lock into fixed magnification positions, motorized versions run from a controller over RS232 or USB, and two detented 6.5X versions report the magnification setting.
2/3-inch sensors
12.5X and 14X Zoom Lenses
The widest zoom ranges: 0.58× to 7.5× at 77.4 mm, or 0.55× to 7.6× with coaxial illumination. Continuous, detented or motorized zoom, with coaxial illumination and 3 mm or 12 mm fine focus.
12.5X Zoom Lenses
0.58× – 7.5× · 12.5:1 · up to 2/3 inch · compare 12 versions
PMS-Z125C
12.5X Continuous Zoom Lens
- Magnification
- 0.58× – 7.5×
- Working distance
- 77.4 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, continuous
PMS-Z125C-C
12.5X Zoom Lens with Coaxial Illumination
- Magnification
- 0.58× – 7.5×
- Working distance
- 77.4 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, continuous · coaxial illumination
PMS-Z125C-H3
12.5X Zoom Lens with 3 mm Fine Focus
- Magnification
- 0.58× – 7.5×
- Working distance
- 71 to 74 mm
- Sensor
- up to 2/3 inch
Manual, continuous · 3 mm fine focus
PMS-Z125C-H12
12.5X Zoom Lens with 12 mm Fine Focus
- Magnification
- 0.58× – 7.5×
- Working distance
- 62 to 74 mm (± 2 mm)
- Sensor
- up to 2/3 inch
Manual, continuous · 12 mm fine focus
PMS-Z125D
12.5X Detented Zoom Lens
- Magnification
- 0.58× – 7.5×
- Working distance
- 77.4 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, detented
PMS-Z125D-C
12.5X Detented Zoom Lens with Coaxial Illumination
- Magnification
- 0.58× – 7.5×
- Working distance
- 77.4 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, detented · coaxial illumination
PMS-Z125D-CH3
12.5X Detented Zoom Lens with Coaxial Illumination and 3 mm Fine Focus
- Magnification
- 0.58× – 7.5×
- Working distance
- 68 to 71 mm (± 2 mm)
- Sensor
- up to 2/3 inch
Manual, detented · coaxial illumination · 3 mm fine focus
PMS-Z125D-CH12
12.5X Detented Zoom Lens with Coaxial Illumination and 12 mm Fine Focus
- Magnification
- 0.58× – 7.5×
- Working distance
- 62 to 74 mm (± 2 mm)
- Sensor
- up to 2/3 inch
Manual, detented · coaxial illumination · 12 mm fine focus
PMS-Z125M
12.5X Motorized Zoom Lens
- Magnification
- 0.58× – 7.5×
- Working distance
- 77.4 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized
PMS-Z125M-C
12.5X Motorized Zoom Lens with Coaxial Illumination
- Magnification
- 0.58× – 7.5×
- Working distance
- 77.4 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized · coaxial illumination
PMS-Z125M-CH12
12.5X Motorized Zoom Lens with Coaxial Illumination and 12 mm Fine Focus
- Magnification
- 0.58× – 7.5×
- Working distance
- 54 to 66 mm (± 2 mm)
- Sensor
- up to 2/3 inch
Motorized · coaxial illumination · 12 mm fine focus
PMS-Z125M-CH12M
12.5X Motorized Zoom Lens with Coaxial Illumination and 12 mm Motorized Fine Focus
- Magnification
- 0.58× – 7.5×
- Working distance
- 70 to 80 mm (± 2 mm)
- Sensor
- up to 2/3 inch
Motorized · coaxial illumination · 12 mm, motorized fine focus
2/3-inch sensors
6.5X and 8X Zoom Lenses
0.7× to 4.5× at 80 to 87 mm in continuous, detented, RS-232 feedback and motorized versions, and 0.6× to 5.0× with a telecentric optical design.
6.5X Zoom Lenses
0.7× – 4.5× · 6.5:1 · up to 2/3 inch · compare 15 versions
PMS-Z65C
6.5X Continuous Zoom Lens
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, continuous
PMS-Z65C(A)
6.5X Continuous Zoom Lens, 80 mm Working Distance
- Magnification
- 0.7× – 4.5×
- Working distance
- 80 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, continuous
PMS-Z65C-C
6.5X Zoom Lens with Coaxial Illumination
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, continuous · coaxial illumination
PMS-Z65C-H3
6.5X Zoom Lens with 3 mm Fine Focus
- Magnification
- 0.7× – 4.5×
- Working distance
- 84 to 87 mm (± 2 mm)
- Sensor
- up to 2/3 inch
Manual, continuous · 3 mm fine focus
PMS-Z65C-H12
6.5X Zoom Lens with 12 mm Fine Focus
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, continuous · 12 mm fine focus
PMS-Z65C-CH3
6.5X Zoom Lens with Coaxial Illumination and 3 mm Fine Focus
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, continuous · coaxial illumination · 3 mm fine focus
PMS-Z65C-CH12
6.5X Zoom Lens with Coaxial Illumination and 12 mm Fine Focus
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, continuous · coaxial illumination · 12 mm fine focus
PMS-Z65D
6.5X Detented Zoom Lens
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, detented
PMS-Z65D-C
6.5X Detented Zoom Lens with Coaxial Illumination
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, detented · coaxial illumination
PMS-Z65D-RS9
6.5X Detented Zoom Lens with RS-232 Magnification Feedback
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, detented
PMS-Z65F-RS
6.5X Detented Zoom Lens with Magnification Output
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, detented
PMS-Z65M
6.5X Motorized Zoom Lens
- Magnification
- 0.7× – 4.5×
- Working distance
- 82 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized
PMS-Z65M(A)
6.5X Motorized Zoom Lens, 80 mm Working Distance
- Magnification
- 0.7× – 4.5×
- Working distance
- 80 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized
PMS-Z65M-C(A)
6.5X Motorized Zoom Lens with Coaxial Illumination, 80 mm Working Distance
- Magnification
- 0.7× – 4.5×
- Working distance
- 80 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized · coaxial illumination
PMS-Z65M(A)-MH12
6.5X Motorized Zoom Lens with 12 mm Motorized Fine Focus
- Magnification
- 0.7× – 4.5×
- Working distance
- 61.6 to 76.6 mm (± 2 mm)
- Sensor
- up to 2/3 inch
Motorized · 12 mm, motorized fine focus
8X Zoom Lenses
0.6× – 5.0× · 8:1 · up to 2/3 inch · compare 3 versions
PMS-Z80D
8X Detented Zoom Lens
- Magnification
- 0.6× – 5.0×
- Working distance
- 84 ± 2 mm
- Sensor
- up to 2/3 inch
Manual, detented
PMS-Z80M
8X Motorized Zoom Lens
- Magnification
- 0.6× – 5.0×
- Working distance
- 84 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized
PMS-Z80M-C
8X Motorized Zoom Lens with Coaxial Illumination
- Magnification
- 0.6× – 5.0×
- Working distance
- 84 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized · coaxial illumination
1-inch sensors
4K and High-Resolution Zoom Lenses
For large sensors: 4K zoom lenses with 0.68× to 5.0× at 80 mm, and a 6.5X high-resolution lens with 0.7× to 4.5× at 88 mm.
4K Zoom Lenses
0.68× – 5.0× · 7.5:1 · up to 1 inch · compare 6 versions
PMS-K75C
4K Continuous Zoom Lens
- Magnification
- 0.68× – 5.0×
- Working distance
- 80 mm
- Sensor
- up to 1 inch
Manual, continuous
PMS-K75C-C
4K Continuous Zoom Lens with Coaxial Illumination
- Magnification
- 0.68× – 5.0×
- Working distance
- 80 mm
- Sensor
- up to 1 inch
Manual, continuous · coaxial illumination
PMS-K75D
4K Detented Zoom Lens
- Magnification
- 0.68× – 5.0×
- Working distance
- 80 mm
- Sensor
- up to 1 inch
Manual, detented
PMS-K75D-C
4K Detented Zoom Lens with Coaxial Illumination
- Magnification
- 0.68× – 5.0×
- Working distance
- 80 mm
- Sensor
- up to 1 inch
Manual, detented · coaxial illumination
PMS-K75M
4K Motorized Zoom Lens
- Magnification
- 0.68× – 5.0×
- Working distance
- 80 mm
- Sensor
- up to 1 inch
Motorized
PMS-K75M-C
4K Motorized Zoom Lens with Coaxial Illumination
- Magnification
- 0.68× – 5.0×
- Working distance
- 80 mm
- Sensor
- up to 1 inch
Motorized · coaxial illumination
Linear guide
Linear Zoom Lenses
Motorized 12.5X and 6.5X zoom lenses on a double linear guide, with or without coaxial illumination.
12.5X Linear Zoom Lenses
0.58× – 7.5× · 12.5:1 · up to 2/3 inch · compare 2 versions
PMS-L125
12.5X Linear Zoom Lens
- Magnification
- 0.58× – 7.5×
- Working distance
- 77.4 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized, linear guide
PMS-L125-C
12.5X Linear Zoom Lens with Coaxial Illumination
- Magnification
- 0.58× – 7.5×
- Working distance
- 77.4 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized, linear guide · coaxial illumination
6.5X Linear Zoom Lenses
0.7× – 4.5× · 6.5:1 · up to 2/3 inch · compare 2 versions
PMS-L65
6.5X Linear Zoom Lens
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized, linear guide
PMS-L65-C
6.5X Linear Zoom Lens with Coaxial Illumination
- Magnification
- 0.7× – 4.5×
- Working distance
- 87 ± 2 mm
- Sensor
- up to 2/3 inch
Motorized, linear guide · coaxial illumination
Telecentric
Telecentric Zoom Lenses
A telecentric macro zoom lens (0.5× to 1.0×, F5) and an object-side telecentric zoom lens for 1-inch sensors (0.21× to 1.97×).
Telecentric Macro Zoom Lens
0.5× – 1.0× · 2:1 · up to 2/3 inch · view lens
Side by side
All Zoom Lenses Compared
Before you specify
Field of view, sampling and the camera behind the lens
Work out the magnification your sensor needs before you pick the zoom range.
Scientific imagingCalculating camera field of view and diffraction sampling
Calculate object-space pixel size, field of view, Rayleigh resolution, and sampling using real MAX and sMAX sensor formats.
Open guide
Scientific camerasChoosing a scientific camera
Which sensor technology your photon budget actually needs, why rolling and global shutter answer different questions, and how to check the data can leave the camera at all.
Open guideWhich zoom lens fits your camera?
Tell us your camera sensor, the field of view and working distance you need, and whether the zoom should be manual, detented or motorized. We will recommend the lens, adapter tubes, attachments and illumination and send a quotation.
Request a QuoteAlready have a quote for a zoom lens? Send it to us.
