Diode/TEC Controller
This LDCD series of Compact Laser Diode Driver and TEC Temperature Controller is based on a proven design that have wide deployments. The module provides a low noise laser driving current up to 1A, and TEC colling current up to 2A. It is designed for easy integration into your laser system: 1) connect the LDCD to a DC power supply using the accompanied cable with a connector, 2) select a mounting hardware for your type of laser and connect to the LDCD with the prefabricated latching connector. The setups are detailed in the following pages. The laser controller setting adjustments are straightforward with turning pots, once the limits have been set to protect the laser.
Configuration options
Build & quote
Configure the options below and add your exact build to the enquiry — we confirm the part number and availability.
We confirm the exact part number for your configuration on enquiry.
Configuration: Standard · Laser Current: 1A · TEC Current: 2.2A · Type: Standard · Package: Module · Power Supply: Non · Laser Mount: None
