ICP-MS
DPS-532-A: 532 nm emission determines compatible optics, coatings and detectors for ICP-MS. The catalogued beam parameter (<3) helps predict how the source will focus and propagate through the instrument.
Pulse energy, repetition rate, pulse width
DPS-532-A532 nm green pulsed laser
532 nmDPS-532-A is a 532 nm Pulsed laser. Used for icp-ms, lcd repair, scientific research. Key specifications: pulse energy 1-10 mJ, repetition rate <10 Hz, pulse duration (ns) <10. View specifications, datasheet and enquiry options from Precisometer.
Specifications
DPS-532-A
18 specification rows
| Pulse energy | 1-10 mJ |
|---|---|
| Repetition rate | <10 Hz |
| Pulse duration (ns) | <10 |
| Jitter (ns, sdev) | <1ns (Int.) |
| Energy stability (std dev/mean) | <5%, <3% |
| Beam diameter (mm) | ~2.5 |
| Warm-up time (minutes) | <15 |
| Cooled method | Conduction cooled |
| Operating temperature (℃) | 15-30 |
| Power supply (110/220VAC) | PSU-DPS-A-I/PSU-DPS-A-II/PSU-DPS-A-OEM |
| Expected lifetime (pulses) | 10 9 |
| Pulse width | Air cooled |
| Wavelength (nm) | 532±1 |
| Single pulse energy (mJ) | 1-5 |
| Rep. rate | 1-10Hz (adjustable) |
| Beam divergence, full angle (mrad) | <3 |
| Beam height from base plate (mm) | 37 |
| Available options | Battery powered; Attenuator; |
Application context
Why this design is used
Applications named on this model’s datasheet, expanded with the model’s optical specifications.
LCD repair
DPS-532-A: 532 nm emission determines compatible optics, coatings and detectors for LCD repair. The catalogued beam parameter (<3) helps predict how the source will focus and propagate through the instrument.
Scientific research
DPS-532-A: 532 nm emission determines compatible optics, coatings and detectors for Scientific research. The catalogued beam parameter (<3) helps predict how the source will focus and propagate through the instrument.
System integration
Integration and compatibility
Use these checks to connect DPS-532-A to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
- Thermal management
- Cooled method: Conduction cooled · Operating temperature (℃): 15-30
- Provide the stated cooling method and keep the laser-head base thermally coupled; temperature drift moves wavelength, output power and beam pointing.
- Beam parameters at the output
- Beam diameter (mm): ~2.5 · Beam divergence, full angle (mrad): <3
- Size the downstream optics from the stated beam diameter and divergence rather than from the aperture of the housing, and confirm the polarisation state before specifying isolators or polarising optics.
Technical FAQ
Integration questions for DPS-532-A
What cooling does the DPS-532-A require?
Cooled method: Conduction cooled · Operating temperature (℃): 15-30. Provide the stated cooling method and keep the laser-head base thermally coupled; temperature drift moves wavelength, output power and beam pointing.
What beam does the DPS-532-A deliver?
Beam diameter (mm): ~2.5 · Beam divergence, full angle (mrad): <3. Size the downstream optics from the stated beam diameter and divergence rather than from the aperture of the housing, and confirm the polarisation state before specifying isolators or polarising optics.
Need this configured?
Share wavelength, operating mode, output power or pulse energy, linewidth or pulse width, delivery, control, and safety requirements and we will qualify the matching configuration and lead time.
Model selection
Nearby series comparison
Compare DPS-532-A with the closest available models in the Pulsed Lasers family. Confirm option-dependent values on the final configuration before ordering.
| Selection parameter | DPS-532-A (current) | FS-H- 5 32A | FS-H- 5 32B |
|---|---|---|---|
| Wavelength | 532 nm | 532 nm | 532 nm |
| Optical power / pulse energy | 1-10 mJ | 1-100 mW | 100-2000 mW |
| Operating mode / pulse width | <10 Hz | Pulsed | Pulsed |
| Beam quality | <3 | TEM00 | TEM00 |
