Scientific Camera
MAX251AC-U3
MAX251AC-U3 MAX Sony scientific camera combines Exmor CMOS imaging, TEC cooling, anti-condensation optics and SDK support.
- Sensor
- IMX811AQR (C, RS)
- Resolution
- 251 MP (19200×12800)
- Pixel Size
- 2.81 µm × 2.81 µm
- Frame Rate
- 1.5 fps @ 19200×12800
- Interface
- USB3.0
Specifications
MAX251AC-U3
25 specification rows
Specifications
| Model | MAX251AC-U3 |
|---|---|
| Sensor | IMX811AQR (C, RS) |
| Shutter Type | Rolling Shutter |
| Color Type | Color |
| Resolution | 251 MP (19200×12800) |
| Sensor Size | 53.95 mm × 35.97 mm |
| Sensor Diagonal | 4.1" (64.84 mm) |
| Pixel Size | 2.81 µm × 2.81 µm |
Performance Parameters
| Frame Rate | 1.5 fps @ 19200×12800 |
|---|---|
| Exposure Time | 150 µs ~ 3600 s |
| Bit Depth | 8/16-bit |
| Dynamic Range | Available on request |
| Sensitivity | Available on request |
Interface Parameters
| GPIO | 1× opto-isolated input, 1× opto-isolated output, 2× direct-connect GPIO |
|---|---|
| Lens Mount | M72×0.75 (native) |
| Data Interface | USB3.0 |
| Power Supply | USB3.0 bus power / DC 19 V |
Physical Parameters
| Dimensions | 110 mm × 110 mm × 123.8 mm |
|---|---|
| Weight | 1.44 kg |
Environmental Parameters
| Operating Temperature | 10 °C to +50 °C |
|---|---|
| Operating Humidity | 20%–80% (non-condensing) |
| Storage Temperature | 30 °C to +70 °C |
| Storage Humidity | 20%–80% (non-condensing) |
Other Parameters
| OS Support | Multi-platform SDK for Windows/Linux/macOS/Android (native C/C++, C#/VB.NET, Python, Java, DirectShow, TWAIN, etc.) |
|---|---|
| Certification | CE, FCC |
