Microscopy Camera/Microscope Camera
SPCMOS05100KPB
SPCMOS05100KPB Microscopy Camera/Microscope Camera with IMX335(C) sensor, 5.1M (2592×1944) for professional imaging.
- Sensor
- IMX335(C)
- Resolution
- 5.1M (2592×1944)
- Pixel Size
- 2.0 µm × 2.0 µm
- Frame Rate
- 26 fps @ 2592×1944; 26 fps @ 1280×960; 26 fps @ 640×480
- Interface
- USB2.0
Specifications
SPCMOS05100KPB
22 specification rows
The SPCMOS05100KPB is a microscopy camera in the SPCMOS series, built around a IMX335(C) sensor, 5.1M (2592×1944) resolution, 2.0 µm × 2.0 µm pixels, frame rates up to 26 fps @ 2592×1944; 26 fps @ 1280×960; 26 fps @ 640×480, a USB2.0 interface. It suits microscopy camera/microscope camera where reliable imaging performance and interface compatibility matter.
Key Parameters
| Model | SPCMOS05100KPB |
|---|---|
| Sensor | IMX335(C) |
| Effective Pixels / Resolution | 5.1M (2592×1944) |
| Frame Rate (Full Resolution) | 26 fps @ 2592×1944; 26 fps @ 1280×960; 26 fps @ 640×480 |
| Shutter Type | Rolling Shutter |
| Color Type | Color |
Imaging Performance
| Pixel Size | 2.0 µm × 2.0 µm |
|---|---|
| Sensor Size | 5.18 mm × 3.89 mm |
| Diagonal | 1/2.5" (6.48 mm) |
| Dynamic Range | 70 dB |
| Bit Depth | 8-bit/12-bit |
| Sensitivity | 505 mV |
Interface & Mechanical
| Data Interface | USB2.0 |
|---|---|
| GPIO | Available on request |
| Lens Mount | 23.2 mm eyepiece tube interface |
| Dimensions | Dia. 33 mm × 79 mm |
| Weight | 0.26~0.27Kg |
| Power Supply | USB powered |
Environment & Certification
| Operating Temperature / Humidity | 10 °C ~ 50 °C / 30%~80%RH |
|---|---|
| Storage Temperature / Humidity | 20 °C ~ 60 °C / 10%~60%RH |
| Operating System | Windows |
| Certification | CE, FCC |
System integration
Integration and compatibility
Use these checks to connect SPCMOS05100KPB to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
- Lens and microscope interface
- Lens Mount: 23.2 mm eyepiece tube interface
- Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
- Sensor and sampling
- Sensor: IMX335(C) · Resolution: 5.1M (2592×1944)
- Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
- Interface and data rate
- Frame Rate: 26 fps @ 2592×1944; 26 fps @ 1280×960; 26 fps @ 640×480 · Interface: USB2.0
- Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
- Hardware synchronization
- GPIO: Available on request
- Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
- Cooling and noise floor
- Dynamic Range: 70 dB
- Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Technical FAQ
Integration questions for SPCMOS05100KPB
What lens mount is required for the SPCMOS05100KPB?
Lens Mount: 23.2 mm eyepiece tube interface. Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
What sensor and pixel pitch does the SPCMOS05100KPB use?
Sensor: IMX335(C) · Resolution: 5.1M (2592×1944). Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
How does the SPCMOS05100KPB connect to the acquisition computer?
Frame Rate: 26 fps @ 2592×1944; 26 fps @ 1280×960; 26 fps @ 640×480 · Interface: USB2.0. Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
Does the SPCMOS05100KPB support hardware triggering?
GPIO: Available on request. Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
What is the noise performance of the SPCMOS05100KPB?
Dynamic Range: 70 dB. Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Need help choosing?
Tell us your sensor, resolution, spectral range, frame-rate, interface, and software requirements and we will confirm the matching configuration and lead time.
Model selection
Nearby series comparison
Compare SPCMOS05100KPB with the closest available models in the SPCMOS family.
| Selection parameter | SPCMOS05100KPB (current) | SPCMOS05000KPA | SPCMOS03000KPA |
|---|---|---|---|
| Sensor | IMX335(C) | Aptina(C) | Aptina(C) |
| Resolution | 5.1M (2592×1944) | 5.0M (2592×1944) | 3.0M (2048×1536) |
| Sensor size | 5.18 mm × 3.89 mm | 5.70 mm × 4.28 mm | 4.51 mm × 3.38 mm |
| Pixel size / frame rate | 2.0 µm × 2.0 µm | 2.2 µm × 2.2 µm | 2.2 µm × 2.2 µm |
Other cameras on the IMX335 sensor
The IMX335 appears in 8 models across the catalogue, differing in cooling, shutter, interface and colour filter. Compare them side by side before settling on a variant.
