Color · Microscopy Camera/Microscope Camera
SCMOS03100KPA
- Sensor
- Aptina (C)
- Resolution
- 3.1MP (2048×1536)
- Pixel Size
- 2.8 µm × 2.8 µm
- Frame Rate
- 30 fps @ 2048×1536; 30 fps @ 1024×768
- Interface
- USB2.0
Complete Specifications
Sensor & Imaging
| Sensor | Aptina (C) |
|---|---|
| Effective Pixels / Resolution | 3.1MP (2048×1536) |
| Shutter Type | Electronic Rolling Shutter |
| Color Type | Color |
| Pixel Size | 2.8 µm × 2.8 µm |
| Sensor Size | 5.73 mm × 4.3 mm |
| Diagonal | 1/2.5" (7.16 mm) |
| Resolution | 3.1MP (2048×1536) |
Performance
| Frame Rate (Full Resolution) | 30 fps @ 2048×1536; 30 fps @ 1024×768 |
|---|---|
| Dynamic Range | 73 dB |
| Bit Depth | Available on request |
| Sensitivity | 18.8 ke-/lux |
| Frame Rate | 30 fps @ 2048×1536; 30 fps @ 1024×768 |
Interface & Connectivity
| Data Interface | USB2.0 |
|---|---|
| GPIO | Available on request |
| Interface | USB2.0 |
Cooling & Mechanical
| Lens Mount | 23.2 mm eyepiece tube type |
|---|---|
| Dimensions | Dia. 27.2 mm × 40 mm |
| Weight | 0.15~0.16Kg |
| Power Supply | USB powered |
| Operating Temperature / Humidity | 10 °C ~ +50 °C / 30%~80%RH |
| Storage Temperature / Humidity | 20 °C ~ +60 °C / 10%~60%RH |
Other Published Specifications
| Model | SCMOS03100KPA |
|---|---|
| Operating System | Microsoft Windows XP/Vista/7/8/10/11(32&64-bit) |
| Certification | CE/FCC |
