Microscopy Camera/Microscope Camera
SCMOS00920KPA
SCMOS00920KPA Microscopy Camera/Microscope Camera with BG0703 (C) sensor, 0.92MP (1280×720) for professional imaging.
- Sensor
- BG0703 (C)
- Resolution
- 0.92MP (1280×720)
- Pixel Size
- 4.5 µm × 4.5 µm
- Frame Rate
- 25 fps @ 1280×720; 25 fps @ 640×480
- Interface
- USB2.0
Specifications
SCMOS00920KPA
22 specification rows
The SCMOS00920KPA is a microscopy camera in the SCMOS series, built around a BG0703 (C) sensor, 0.92MP (1280×720) resolution, 4.5 µm × 4.5 µm pixels, frame rates up to 25 fps @ 1280×720; 25 fps @ 640×480, a USB2.0 interface. It suits microscopy camera/microscope camera where reliable imaging performance and interface compatibility matter.
Key Parameters
| Model | SCMOS00920KPA |
|---|---|
| Sensor | BG0703 (C) |
| Effective Pixels / Resolution | 0.92MP (1280×720) |
| Frame Rate (Full Resolution) | 25 fps @ 1280×720; 25 fps @ 640×480 |
| Shutter Type | Electronic Rolling Shutter |
| Color Type | Color |
Imaging Performance
| Pixel Size | 4.5 µm × 4.5 µm |
|---|---|
| Sensor Size | 5.80 mm × 3.28 mm |
| Diagonal | 1/2.5" (6.66 mm) |
| Dynamic Range | 65 dB |
| Bit Depth | Available on request |
| Sensitivity | 5.8 V/Lux-sec |
Interface & Mechanical
| Data Interface | USB2.0 |
|---|---|
| GPIO | Available on request |
| Lens Mount | 23.2 mm eyepiece tube type |
| Dimensions | Dia. 27.2 mm × 40 mm |
| Weight | 0.15~0.16Kg |
| Power Supply | USB powered |
Environment & Certification
| Operating Temperature / Humidity | 10 °C ~ +50 °C / 30%~80%RH |
|---|---|
| Storage Temperature / Humidity | 20 °C ~ +60 °C / 10%~60%RH |
| Operating System | Microsoft Windows XP/Vista/7/8/10/11(32&64-bit) |
| Certification | CE, FCC |
System integration
Integration and compatibility
Use these checks to connect SCMOS00920KPA to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
- Lens and microscope interface
- Lens Mount: 23.2 mm eyepiece tube type
- Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
- Sensor and sampling
- Sensor: BG0703 (C) · Resolution: 0.92MP (1280×720)
- Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
- Interface and data rate
- Frame Rate: 25 fps @ 1280×720; 25 fps @ 640×480 · Interface: USB2.0
- Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
- Hardware synchronization
- GPIO: Available on request
- Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
- Cooling and noise floor
- Dynamic Range: 65 dB
- Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Technical FAQ
Integration questions for SCMOS00920KPA
What lens mount is required for the SCMOS00920KPA?
Lens Mount: 23.2 mm eyepiece tube type. Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
What sensor and pixel pitch does the SCMOS00920KPA use?
Sensor: BG0703 (C) · Resolution: 0.92MP (1280×720). Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
How does the SCMOS00920KPA connect to the acquisition computer?
Frame Rate: 25 fps @ 1280×720; 25 fps @ 640×480 · Interface: USB2.0. Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
Does the SCMOS00920KPA support hardware triggering?
GPIO: Available on request. Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
What is the noise performance of the SCMOS00920KPA?
Dynamic Range: 65 dB. Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Need help choosing?
Tell us your sensor, resolution, spectral range, frame-rate, interface, and software requirements and we will confirm the matching configuration and lead time.
Model selection
Nearby series comparison
Compare SCMOS00920KPA with the closest available models in the SCMOS family.
| Selection parameter | SCMOS00920KPA (current) | SCMOS00350KPA | SCMOS00921KPA |
|---|---|---|---|
| Sensor | BG0703 (C) | Aptina (C) | OV9732 (C) |
| Resolution | 0.92MP (1280×720) | 0.35MP (640×480) | 0.92MP (1280×720) |
| Sensor size | 5.80 mm × 3.28 mm | 3.58 mm × 2.69 mm | 3.888 mm × 2.208 mm |
| Pixel size / frame rate | 4.5 µm × 4.5 µm | 5.6 µm × 5.6 µm | 3 µm × 3 µm |
