Microscopy Camera/Microscope Camera
SCMOS02100KPB Microscopy Camera/Microscope Camera with SC2332 (C) sensor, 2.1MP (1920×1080) for professional imaging.
Application context
SCMOS02100KPB: The SC2332 (C) sensor, 2.1MP (1920×1080) resolution, and 2.7 µm × 2.7 µm pixels defines the sensitivity, sampling and field coverage available for Scientific imaging. The 30 fps @ 1920×1080; 30 fps @ 960×540 frame-rate listing also sets the fastest full-frame acquisition regime.
SCMOS02100KPB: The SC2332 (C) sensor, 2.1MP (1920×1080) resolution, and 2.7 µm × 2.7 µm pixels defines the sensitivity, sampling and field coverage available for Instrument integration. The 30 fps @ 1920×1080; 30 fps @ 960×540 frame-rate listing also sets the fastest full-frame acquisition regime.
Specifications
22 specification rows
The SCMOS02100KPB is a microscopy camera in the SCMOS series, built around a SC2332 (C) sensor, 2.1MP (1920×1080) resolution, 2.7 µm × 2.7 µm pixels, frame rates up to 30 fps @ 1920×1080; 30 fps @ 960×540, a USB2.0 interface. It suits microscopy camera/microscope camera where reliable imaging performance and interface compatibility matter.
| Model | SCMOS02100KPB |
|---|---|
| Sensor | SC2332 (C) |
| Effective Pixels / Resolution | 2.1MP (1920×1080) |
| Frame Rate (Full Resolution) | 30 fps @ 1920×1080; 30 fps @ 960×540 |
| Shutter Type | Electronic Rolling Shutter |
| Color Type | Color |
| Pixel Size | 2.7 µm × 2.7 µm |
|---|---|
| Sensor Size | 5.18 mm × 2.92 mm |
| Diagonal | 1/2.5" (5.95 mm) |
| Dynamic Range | 74 dB |
| Bit Depth | Available on request |
| Sensitivity | 4510 mV/lux-s |
| Data Interface | USB2.0 |
|---|---|
| GPIO | Available on request |
| Lens Mount | 23.2 mm eyepiece tube type |
| Dimensions | Dia. 27.2 mm × 40 mm |
| Weight | 0.15~0.16Kg |
| Power Supply | USB powered |
| Operating Temperature / Humidity | 10 °C ~ +50 °C / 30%~80%RH |
|---|---|
| Storage Temperature / Humidity | 20 °C ~ +60 °C / 10%~60%RH |
| Operating System | Microsoft Windows XP/Vista/7/8/10/11(32&64-bit) |
| Certification | CE/FCC |
System integration
Use these checks to connect SCMOS02100KPB to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
Technical FAQ
Lens Mount: 23.2 mm eyepiece tube type. Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
Sensor: SC2332 (C) · Resolution: 2.1MP (1920×1080). Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
Frame Rate: 30 fps @ 1920×1080; 30 fps @ 960×540 · Interface: USB2.0. Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
GPIO: Available on request. Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
Dynamic Range: 74 dB. Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Tell us your sensor, resolution, spectral range, frame-rate, interface, and software requirements and we will confirm the matching configuration and lead time.
Model selection
Compare SCMOS02100KPB with the closest available models in the SCMOS family. Confirm option-dependent values on the final configuration before ordering.
| Selection parameter | SCMOS02100KPB (current) | SCMOS02100KPA | SCMOS03000KPA |
|---|---|---|---|
| Sensor | SC2332 (C) | IMX307 (C) | Aptina (C) |
| Resolution | 2.1MP (1920×1080) | 2.1MP (1920×1080) | 3.0MP (2048×1536) |
| Sensor size | 5.18 mm × 2.92 mm | 5.73 mm × 4.3 mm | 4.51 mm × 3.38 mm |
| Pixel size / frame rate | 2.7 µm × 2.7 µm | 2.9 µm × 2.9 µm | 2.2 µm × 2.2 µm |
