Scientific Camera
MAX24AC MAX Sony scientific camera combines Exmor CMOS imaging, TEC cooling, anti-condensation optics and SDK support.
Application context
MAX24AC: The IMX410 (C, RS) sensor, 24 MP (6064×4040) resolution, and 5.94 µm × 5.94 µm pixels defines the sensitivity, sampling and field coverage available for Scientific imaging. The 15.3 fps @ 6064×4040 (14-bit); 41 fps @ 3024×2012; 114 fps @ 2016×1342 frame-rate listing also sets the fastest full-frame acquisition regime.
MAX24AC: The IMX410 (C, RS) sensor, 24 MP (6064×4040) resolution, and 5.94 µm × 5.94 µm pixels defines the sensitivity, sampling and field coverage available for Instrument integration. The 15.3 fps @ 6064×4040 (14-bit); 41 fps @ 3024×2012; 114 fps @ 2016×1342 frame-rate listing also sets the fastest full-frame acquisition regime.
Specifications
25 specification rows
The MAX24AC is a scientific camera in the MAX Sony series, built around a IMX410 (C, RS) sensor, 24 MP (6064×4040) resolution, 5.94 µm × 5.94 µm pixels, frame rates up to 15.3 fps @ 6064×4040 (14-bit); 41 fps @ 3024×2012; 114 fps @ 2016×1342, a USB3.0 interface. It suits scientific camera where reliable imaging performance and interface compatibility matter.
| Model | MAX24AC |
|---|---|
| Sensor | IMX410 (C, RS) |
| Shutter Type | Rolling Shutter |
| Color Type | Color |
| Resolution | 24 MP (6064×4040) |
| Sensor Size | 36.02 mm × 24.00 mm |
| Sensor Diagonal | 1.8" (43.28 mm) |
| Pixel Size | 5.94 µm × 5.94 µm |
| Frame Rate | 15.3 fps @ 6064×4040 (14-bit); 41 fps @ 3024×2012; 114 fps @ 2016×1342 |
|---|---|
| Exposure Time | 0.1 ms ~ 1000 s |
| Bit Depth | 8/14-bit |
| Dynamic Range | 87.3 dB |
| Sensitivity | 573 mV @ 1/30 s; 0.037 mV @ 1/30 s |
| GPIO | 1× opto-isolated input, 1× opto-isolated output, 2× direct-connect GPIO |
|---|---|
| Lens Mount | M54×0.75 (native); optional M42×1/EF/F adapters |
| Data Interface | USB3.0 |
| Power Supply | DC 19 V, 4 A |
| Dimensions | Available on request |
|---|---|
| Weight | Available on request |
| Operating Temperature | 10 °C to +50 °C |
|---|---|
| Operating Humidity | 30%–80% RH (non-condensing) |
| Storage Temperature | 20 °C to +60 °C |
| Storage Humidity | 10%–60% RH (non-condensing) |
| OS Support | Multi-platform SDK for Windows/Linux/macOS/Android (native C/C++, C#/VB.NET, Python, Java, DirectShow, TWAIN, etc.) |
|---|---|
| Certification | Available on request |
System integration
Use these checks to connect MAX24AC to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
Technical FAQ
Lens Mount: M54×0.75 (native); optional M42×1/EF/F adapters. Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
Sensor: IMX410 (C, RS) · Resolution: 24 MP (6064×4040). Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
Frame Rate: 15.3 fps @ 6064×4040 (14-bit); 41 fps @ 3024×2012; 114 fps @ 2016×1342 · Interface: USB3.0. Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
GPIO: 1× opto-isolated input, 1× opto-isolated output, 2× direct-connect GPIO. Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
Dynamic Range: 87.3 dB. Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Tell us your sensor, resolution, spectral range, frame-rate, interface, and software requirements and we will confirm the matching configuration and lead time.
Model selection
Compare MAX24AC with the closest available models in the MAX Sony family. Confirm option-dependent values on the final configuration before ordering.
| Selection parameter | MAX24AC (current) | MAX151AM-U3 | MAX251AC-10G |
|---|---|---|---|
| Sensor | IMX410 (C, RS) | IMX411ALR (M, RS) | IMX811AQR (C, RS) |
| Resolution | 24 MP (6064×4040) | 151 MP (14176×10640) | 251 MP (19200×12800) |
| Sensor size | 36.02 mm × 24.00 mm | 60.30 mm × 47.9 mm | 53.95 mm × 35.97 mm |
| Pixel size / frame rate | 5.94 µm × 5.94 µm | 3.76 µm × 3.76 µm | 2.81 µm × 2.81 µm |
The IMX410 appears in 3 models across the catalogue, differing in cooling, shutter, interface and colour filter. Compare them side by side before settling on a variant.
