558 nm Green Lasers

Green · CW · Datasheets & quote request

558 nm Green Lasers

The 558 nm emission line operates in the Green region of the optical spectrum. Our portfolio includes configurations across CW Lasers, supporting CW operation. Compare power levels, linewidth, stability, and package dimensions below.

2 models1 seriesquote after qualification

Key applications

Raman spectroscopy excitation
Particle image velocimetry (PIV)
Confocal microscopy (GFP, FITC, Alexa Fluor 488)
Flow cytometry
Holography and precision interferometry
Laser display and projection

Other Green lines in catalog (35)

Explore all 400+ wavelengths →

495 nm 496 nm 501 nm 505 nm 507 nm 509 nm 510 nm 513 nm 514 nm 514.5 nm 515 nm 518 nm 520 nm 522 nm 523.5 nm 524 nm 525 nm 526.5 nm 527 nm 530 nm 532 nm 535 nm 536 nm 537 nm

Popular benchmark wavelengths

266 nm 355 nm 405 nm 450 nm 488 nm 515 nm 520 nm 532 nm 561 nm 589 nm 633 nm 640 nm

2 models · 1 series

558 NM Yellow Green Laser.

2 models

Model	Wavelength	Output / average power	Power Stability (rms, 4 hours ± 3°C)	Transverse mode	M2	Beam divergence, full angle (mrad)	Warm-up time (minutes)	Pointing Stability Over Temperature (urad/°C)	Polarization ratio	Operating temperature (°C)	Power supply (100-240VAC)	Expected lifetime (hours)
MGL-N-558	558 nm	1~100 mW	<5%, <3%, (<2% optional)	Near TEM00	1.5-3.0	<1.5	<10	<20	>50:1(100:1 optional), Horizontal(Vertical optional)	10-35	PSU-H-FDA/PSU-H-LED/PSU-H-OEM	>10000	Datasheet
FC-558	558 nm	1~450 mW	–	–	–	–	–	–	–	–	–	–

Not sure which model fits?

Send the physics — wavelength, mode, power or energy, linewidth or pulse width, delivery, control and safety — and we qualify the source.
