Microscopy Camera/Microscope Camera
ICMOS14000KPA Microscopy Camera/Microscope Camera with Aptina MT9F002 (C) sensor, 14MP (4096×3288) for professional imaging.
Application context
ICMOS14000KPA: The Aptina MT9F002 (C) sensor, 14MP (4096×3288) resolution, and 1.4 µm × 1.4 µm pixels defines the sensitivity, sampling and field coverage available for Scientific imaging. The 2.7 fps @ 4096×3288 frame-rate listing also sets the fastest full-frame acquisition regime.
ICMOS14000KPA: The Aptina MT9F002 (C) sensor, 14MP (4096×3288) resolution, and 1.4 µm × 1.4 µm pixels defines the sensitivity, sampling and field coverage available for Instrument integration. The 2.7 fps @ 4096×3288 frame-rate listing also sets the fastest full-frame acquisition regime.
Specifications
22 specification rows
The ICMOS14000KPA is a microscopy camera in the ICMOS series, built around a Aptina MT9F002 (C) sensor, 14MP (4096×3288) resolution, 1.4 µm × 1.4 µm pixels, frame rates up to 2.7 fps @ 4096×3288, a USB2.0 (UVC) interface. It suits microscopy camera/microscope camera where reliable imaging performance and interface compatibility matter.
| Model | ICMOS14000KPA |
|---|---|
| Sensor | Aptina MT9F002 (C) |
| Effective Pixels / Resolution | 14MP (4096×3288) |
| Frame Rate (Full Resolution) | 2.7 fps @ 4096×3288 |
| Shutter Type | Rolling Shutter |
| Color Type | Color |
| Pixel Size | 1.4 µm × 1.4 µm |
|---|---|
| Sensor Size | 5.73 mm × 4.60 mm |
| Diagonal | 1/2.3" (7.33 mm) |
| Dynamic Range | 65.3 dB |
| Bit Depth | 8-bit |
| Sensitivity | 0.724 V/lux-sec |
| Data Interface | USB2.0 (UVC) |
|---|---|
| GPIO | Not supported (no external trigger) |
| Lens Mount | C-mount |
| Dimensions | 29 mm × 29 mm × 29 mm |
| Weight | Available on request |
| Power Supply | USB powered |
| Operating Temperature / Humidity | 10 °C ~ 50 °C / 30%~80%RH |
|---|---|
| Storage Temperature / Humidity | 20 °C ~ 60 °C / 10%~60%RH |
| Certification | CE, FCC |
| OS Support | Windows/Linux/macOS UVC + SDK (native C/C++, C#/VB.NET, Python, Java, DirectShow, TWAIN, etc.) |
|---|
System integration
Use these checks to connect ICMOS14000KPA to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
Technical FAQ
Lens Mount: C-mount. Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
Sensor: Aptina MT9F002 (C) · Resolution: 14MP (4096×3288). Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
Frame Rate: 2.7 fps @ 4096×3288 · Interface: USB2.0 (UVC). Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
GPIO: Not supported (no external trigger). Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
Dynamic Range: 65.3 dB. Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Tell us your sensor, resolution, spectral range, frame-rate, interface, and software requirements and we will confirm the matching configuration and lead time.
Model selection
Compare ICMOS14000KPA with the closest available models in the ICMOS family. Confirm option-dependent values on the final configuration before ordering.
| Selection parameter | ICMOS14000KPA (current) | ICMOS10000KPA | ICMOS03100KPA |
|---|---|---|---|
| Sensor | Aptina MT9F002 (C) | Aptina MT9J003 (C) | Aptina MT9T001 (C) |
| Resolution | 14MP (4096×3288) | 10MP (3584×2748) | 3.1MP (2048×1536) |
| Sensor size | 5.73 mm × 4.60 mm | 5.99 mm × 4.59 mm | 6.55 mm × 4.92 mm |
| Pixel size / frame rate | 1.4 µm × 1.4 µm | 1.67 µm × 1.67 µm | 3.2 µm × 3.2 µm |
The MT9F002 appears in 5 models across the catalogue, differing in cooling, shutter, interface and colour filter. Compare them side by side before settling on a variant.
