Microscopy Camera/Microscope Camera
ICMOS01300KMA Microscopy Camera/Microscope Camera with onsemi MT9M001 (M) sensor, 1.3MP (1280×1024) for professional imaging.
Application context
ICMOS01300KMA: The onsemi MT9M001 (M) sensor, 1.3MP (1280×1024) resolution, and 5.2 µm × 5.2 µm pixels defines the sensitivity, sampling and field coverage available for Scientific imaging. The 30 fps @ 1280×1024 frame-rate listing also sets the fastest full-frame acquisition regime.
ICMOS01300KMA: The onsemi MT9M001 (M) sensor, 1.3MP (1280×1024) resolution, and 5.2 µm × 5.2 µm pixels defines the sensitivity, sampling and field coverage available for Instrument integration. The 30 fps @ 1280×1024 frame-rate listing also sets the fastest full-frame acquisition regime.
Specifications
22 specification rows
The ICMOS01300KMA is a microscopy camera in the ICMOS series, built around a onsemi MT9M001 (M) sensor, 1.3MP (1280×1024) resolution, 5.2 µm × 5.2 µm pixels, frame rates up to 30 fps @ 1280×1024, a USB2.0 (UVC) interface. It suits microscopy camera/microscope camera where reliable imaging performance and interface compatibility matter.
| Model | ICMOS01300KMA |
|---|---|
| Sensor | onsemi MT9M001 (M) |
| Effective Pixels / Resolution | 1.3MP (1280×1024) |
| Frame Rate (Full Resolution) | 30 fps @ 1280×1024 |
| Shutter Type | Rolling Shutter |
| Color Type | Monochrome |
| Pixel Size | 5.2 µm × 5.2 µm |
|---|---|
| Sensor Size | 6.66 mm × 5.32 mm |
| Diagonal | 1/2" (8.52 mm) |
| Dynamic Range | 68.2 dB |
| Bit Depth | 8-bit |
| Sensitivity | 2.1 V/lux-sec |
| Data Interface | USB2.0 (UVC) |
|---|---|
| GPIO | Not supported (no external trigger) |
| Lens Mount | C-mount |
| Dimensions | 29 mm × 29 mm × 29 mm |
| Weight | Available on request |
| Power Supply | USB powered |
| Operating Temperature / Humidity | 10 °C ~ 50 °C / 30%~80%RH |
|---|---|
| Storage Temperature / Humidity | 20 °C ~ 60 °C / 10%~60%RH |
| Certification | CE, FCC |
| OS Support | Windows/Linux/macOS UVC + SDK (native C/C++, C#/VB.NET, Python, Java, DirectShow, TWAIN, etc.) |
|---|
System integration
Use these checks to connect ICMOS01300KMA to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
Technical FAQ
Lens Mount: C-mount. Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
Sensor: onsemi MT9M001 (M) · Resolution: 1.3MP (1280×1024). Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
Frame Rate: 30 fps @ 1280×1024 · Interface: USB2.0 (UVC). Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
GPIO: Not supported (no external trigger). Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
Dynamic Range: 68.2 dB. Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Tell us your sensor, resolution, spectral range, frame-rate, interface, and software requirements and we will confirm the matching configuration and lead time.
Model selection
Compare ICMOS01300KMA with the closest available models in the ICMOS family. Confirm option-dependent values on the final configuration before ordering.
| Selection parameter | ICMOS01300KMA (current) | ICMOS03100KPA | ICMOS10000KPA |
|---|---|---|---|
| Sensor | onsemi MT9M001 (M) | Aptina MT9T001 (C) | Aptina MT9J003 (C) |
| Resolution | 1.3MP (1280×1024) | 3.1MP (2048×1536) | 10MP (3584×2748) |
| Sensor size | 6.66 mm × 5.32 mm | 6.55 mm × 4.92 mm | 5.99 mm × 4.59 mm |
| Pixel size / frame rate | 5.2 µm × 5.2 µm | 3.2 µm × 3.2 µm | 1.67 µm × 1.67 µm |
Compare the ICMOS01300KMA with other ICMOS models and microscopy cameras in the range.
