Monochrome · Microscopy Cameras/Microscope Cameras
EXCCD01400KMA
- Sensor
- ICX285AL CCD (M)
- Resolution
- 1.4MP (1360×1024)
- Pixel Size
- 6.45 µm × 6.45 µm
- Frame Rate
- 15 fps @ 1360×1024
- Interface
- USB2.0
Complete Specifications
Sensor & Imaging
| Sensor | ICX285AL CCD (M) |
|---|---|
| Effective Pixels / Resolution | 1.4MP (1360×1024) |
| Shutter Type | Rolling Shutter |
| Color Type | Monochrome |
| Pixel Size | 6.45 µm × 6.45 µm |
| Sensor Size | 8.77 mm × 6.60 mm |
| Diagonal | 2/3" (10.98 mm) |
| Resolution | 1.4MP (1360×1024) |
Performance
| Frame Rate (Full Resolution) | 15 fps @ 1360×1024 |
|---|---|
| Exposure Time | 0.12 ms ~ 240 s |
| Dynamic Range | Available on request |
| Bit Depth | 8-bit/12-bit |
| Sensitivity | 1300 mv with 1/30s |
| Frame Rate | 15 fps @ 1360×1024 |
Interface & Connectivity
| Data Interface | USB2.0 |
|---|---|
| GPIO | Available on request |
| Interface | USB2.0 |
Cooling & Mechanical
| Lens Mount | C-mount |
|---|---|
| Dimensions | Available on request |
| Weight | 0.67~0.8 Kg |
| Power Supply | USB2.0 Power Supply |
| Operating Temperature / Humidity | 10 °C ~ +50 °C / 30%~80%RH |
| Storage Temperature / Humidity | 20 °C ~ +60 °C / 10%~60%RH |
Other Published Specifications
| Model | EXCCD01400KMA |
|---|---|
| Operating System | Windows XP/Vista/7/8/10/11(32&64-bit)/OS X/Linux |
| Certification | CE, FCC |
