APFP-UM

Opto-Mechanics · Fiber Alignment Accessories

APFP-UM

APFP-UM universal mounting module

Universal dovetail module with threaded mounting points for adapting custom optics and fixtures to fiber stages.

View quote list

Datasheet (PDF) ↗

Specifications

Type	Universal mounting module
Threaded holes	M3 and M4
Release	Jackscrew
Base	APFP dovetail

Applications

Set-and-forget alignment

Adjust once during setup and lock, on axes that do not need to move again during the run.

Coarse positioning ahead of fine stages

Establish the optical axis by hand before a piezo or motorised stage takes the fine motion.

Prototyping and teaching rigs

Reconfigure a layout quickly, with no cabling, controllers or electrical noise added to the experiment.
