Industrial Cameras/Analytical Imaging
IUE1800KMA Industrial Cameras/Analytical Imaging with CMOS Sensor sensor, 1.8 MP (1200×1536) for professional imaging.
Application context
IUE1800KMA: The CMOS Sensor sensor, 1.8 MP (1200×1536) resolution, and 96.0 µm × 96.0 µm pixels defines the sensitivity, sampling and field coverage available for Scientific imaging. The 120 fps @ 1200×1536 frame-rate listing also sets the fastest full-frame acquisition regime.
IUE1800KMA: The CMOS Sensor sensor, 1.8 MP (1200×1536) resolution, and 96.0 µm × 96.0 µm pixels defines the sensitivity, sampling and field coverage available for Instrument integration. The 120 fps @ 1200×1536 frame-rate listing also sets the fastest full-frame acquisition regime.
Specifications
23 specification rows
The IUE1800KMA is an industrial & analytical camera in the IUE series, built around a CMOS Sensor sensor, 1.8 MP (1200×1536) resolution, 96.0 µm × 96.0 µm pixels, frame rates up to 120 fps @ 1200×1536, a USB3.0 interface. It suits industrial cameras/analytical imaging where reliable imaging performance and interface compatibility matter.
| Model | IUE1800KMA |
|---|---|
| Sensor | CMOS Sensor |
| Effective Pixels / Resolution | 1.8 MP (1200×1536) |
| Frame Rate (Full Resolution) | 120 fps @ 1200×1536 |
| Exposure Time | 10 µs ~ 15 s |
| Shutter Type | Rolling Shutter |
| Color Type | Monochrome |
| Pixel Size | 96.0 µm × 96.0 µm |
|---|---|
| Sensor Size | 115.2 mm × 147.5 mm |
| Diagonal | 4.1" (187.16 mm) |
| Dynamic Range | Available on request |
| Bit Depth | 8/12-bit |
| Sensitivity | Available on request |
| Data Interface | USB3.0 |
|---|---|
| GPIO | 1 opto-isolated input, 1 opto-isolated output, 2 non-isolated I/O ports |
| Lens Mount | Available on request |
| Dimensions | 220 mm × 160 mm × 28.6 mm |
| Weight | Available on request |
| Power Supply | USB3.0 interface powered |
| Operating Temperature / Humidity | 10 °C to +50 °C / 20% to 80% (non-condensing) |
|---|---|
| Storage Temperature / Humidity | 30 °C to +70 °C / Available on request |
| Operating System | Windows/Linux/macOS/Android multi-platform SDK (native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc.) |
| Certification | CE/FCC |
System integration
Use these checks to connect IUE1800KMA to the surrounding optical, mechanical and control system. Every value shown is taken from this model's own specification record.
Technical FAQ
Lens Mount: Available on request. Use a lens image circle that covers the sensor and check flange distance before adding C/CS, F-mount or M42 adapters.
Sensor: CMOS Sensor · Resolution: 1.8 MP (1200×1536). Match pixel pitch to the diffraction-limited spot the optics deliver. Sampling finer than the optics resolve multiplies data volume without adding information; sampling coarser discards resolution you have paid for.
Frame Rate: 120 fps @ 1200×1536 · Interface: USB3.0. Confirm the host can sustain the interface bandwidth continuously, not in burst. A camera that outruns the write path stalls acquisition rather than dropping quietly to a lower rate.
GPIO: 1 opto-isolated input, 1 opto-isolated output, 2 non-isolated I/O ports. Confirm edge polarity, pulse-width limits and whether each line is opto-isolated before connecting TTL or GPIO signals. A software exposure command is not equivalent to a hardware trigger.
Dynamic Range: Available on request. Judge these figures at the exposure time you will actually use. Cooling matters where dark current accumulates over seconds; read noise dominates short exposures where it never does.
Tell us your sensor, resolution, spectral range, frame-rate, interface, and software requirements and we will confirm the matching configuration and lead time.
Compare the IUE1800KMA with other IUE models and industrial & analytical cameras in the range.
