FI-Lite SeriesPortable Raman for Liquids
Rapid on-site inspection of liquid samples
A high-performance Raman spectrometer in a one-piece protective clamshell, sized for liquid samples and SERS substrates. Four models at 785 or 830 nm, on Android or Windows.
Instrument
FI-Lite Clamshell Analyser
The screen folds over the sample bay like a laptop lid, protecting both in transport. The sample port sits on the top face of the base.
System Highlights
Features and Benefits
The FI-Lite trades the fibre probe of the FI-FO for a built-in sample port, a lighter housing and fanless operation — the right shape for liquids and SERS work in the field.
Laptop-Style Protection
The overhead lid design makes the whole machine sturdier and more durable; there is nothing to pack separately.
Fanless Heat Dissipation
Passive cooling with no fan to fail or draw dust — stability and reliability for on-site use.
Made for Liquids and SERS
Suited to liquid samples in vials and to SERS enhancers for trace-level rapid checks.
10-Inch Touch Screen
A large capacitive touch screen and an interactive interface that is easy to operate.
Windows or Android
Windows for convenient data processing and analysis; Android for fast checks, recommended with SERS enhancers for flexible on-site testing. Both include the built-in library.
More Than 4 Hours on Battery
A 10200 mAh, 75 Wh built-in battery; 12 V DC or 100–240 V AC external power at the bench.
Configurations
Four Models, Two Wavelengths
The suffix selects the operating system: -A for Android 7.1, -W for Windows 10. The E variants add a cooled CCD.
785 nm
Laser power 0–350 mW · linewidth < 0.1 nm · optical resolution 8–12 cm⁻¹
FI785-Lite-A / FI785-Lite-W
- Spectral range
- 200–2750 cm⁻¹
- Detector
- Room-temperature CCD
FI785E-Lite-A / FI785E-Lite-W
- Spectral range
- 200–2750 cm⁻¹
- Detector
- Cooled CCD
| Part number | Spectral range | Detector |
|---|---|---|
| FI785-Lite-A / FI785-Lite-W | 200–2750 cm⁻¹ | Room-temperature CCD |
| FI785E-Lite-A / FI785E-Lite-W | 200–2750 cm⁻¹ | Cooled CCD |
830 nm
Laser power 0–350 mW · linewidth < 0.1 nm · optical resolution 8–12 cm⁻¹
FI830-Lite-A / FI830-Lite-W
- Spectral range
- 200–2500 cm⁻¹
- Detector
- Room-temperature CCD
FI830E-Lite-A / FI830E-Lite-W
- Spectral range
- 200–2500 cm⁻¹
- Detector
- Cooled CCD
| Part number | Spectral range | Detector |
|---|---|---|
| FI830-Lite-A / FI830-Lite-W | 200–2500 cm⁻¹ | Room-temperature CCD |
| FI830E-Lite-A / FI830E-Lite-W | 200–2500 cm⁻¹ | Cooled CCD |
Technical Specifications
Common to All Configurations
| Parameter | Specification |
|---|---|
| Laser wavelength | 785 nm or 830 nm (one per instrument) |
| Laser power | 0–350 mW, adjustable |
| Laser linewidth | < 0.1 nm |
| Optical resolution | 8–12 cm⁻¹ |
| Display | 10-inch capacitive touch screen |
| Operating system | -A: Android 7.1 · -W: Windows 10 |
| Software | Raman Spectrum Software app (Android or Windows) with built-in library |
| External power | DC 12 V at 4.17 A; AC 100–240 V, 50/60 Hz, 1.7 A |
| Built-in battery | 10200 mAh, 75 Wh; more than 4 hours of portable use |
| Dimensions and weight | 300 × 240 × 70 mm, 4 kg |
We will confirm the wavelength, detector and operating-system variant before quotation.
Applications
Where the FI-Lite Is Used
Food and Pharmaceutical
- Food and drug safety on-site rapid inspection
- Pharmaceutical raw-material detection
Trace Analysis
- Surface-enhanced Raman spectroscopy (SERS) with enhancer substrates
Science and Industry
- Agriculture and environmental science
- Chemistry and materials science
- Custom and OEM applications
Choosing a Raman System
Other Raman Systems in the Range
Every Raman instrument we supply, from handheld to fully automatic confocal, is compared on the Raman spectroscopy systems overview.
