MDL-XS-405405 nm violet CW laser
405 nmMDL-XS-405 is a 405 nm CW laser. Used for medical imaging, flow cytometry, dna sequencing. Features: Near TEM 00. Key specifications: output / average power 1~200 mW, power stability <0.5%, operating mode CW. View specifications, datasheet and enquiry options from Precisometer.
Specifications
MDL-XS-405
16 specification rows
| Output / average power | 1~200 mW |
|---|---|
| Power stability | <0.5% |
| Beam / notes | Features: Near TEM 00 |
| Operating mode | CW |
| Transverse mode | Multimode |
| Beam divergence, full angle (mrad) | ~2.5×0.2 |
| Warm-up time (minutes) | <5 |
| Cooled method | Air cooled |
| Operating temperature (°C) | 10-35 |
| Power supply (100-240VAC) | PSU-H-FDA/PSU-H-LED |
| Expected lifetime (hours) | >10000 |
| Central wavelength (nm) | 405±5 |
| Output power (W) | 1-3 |
| Beam diameter at the aperture (1/e2, mm) | ~3.5×3.5 |
| Beam height from base plate (mm) | 29 |
| Modulation option | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional |
Applications
Uses named on this model’s datasheet.
- Medical imaging
- Flow cytometry
- DNA sequencing
