5 models · 2 series
Optical Spectrum Analyzer, Spectrometer |
1 model| Model | Wavelength | |
|---|---|---|
| LED light source/ solid-state light source | — |
Supercontinuum Source
4 models| Model | Wavelength | Output / average power | Repetition rate | Pulse width | Power stability | M² | Fiber connector | Fiber jacket | Polarization ratio | Warm-up time (minutes) | Cooled method | Operating temperature (℃) | Operating voltage (VDC) | Expected lifetime (hours) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FL-SC-OEM (1~200 mW) | 470~2400 nm | 1~200 mW | 2 MHz | ~350 ps | <2% | <1.1 | FC/APC | PVC | Random | <15 | Air cooled | 15-35 | 12V/11.5A | >10000 | Datasheet |
| FL-SC-OEM (200~350 mW) | 470~2400 nm | 200~350 mW | 4 MHz | ~350 ps | <1% | <1.1 | FC/APC | PVC | Random | <15 | Air cooled | 15-35 | 12V/11.5A | >10000 | Datasheet |
| FL-SC-OEM (350~500 mW) | 470~2400 nm | 350~500 mW | 50kHz~200kHz, 1 MHz | ~350 ps | <1% | <1.1 | FC/APC | PVC | Random | <15 | Air cooled | 15-35 | 12V/11.5A | >10000 | Datasheet |
| FL-SC-OEM (500~1000 mW) | 470~2400 nm | 500~1000 mW | 1 MHz | 1.5 ns | <2%, <1% | <1.1 | FC/APC | PVC | Random | <15 | Air cooled | 15-35 | 12V/11.5A | >10000 | Datasheet |
Not sure which model fits?
Send the physics — wavelength, mode, power or energy, linewidth or pulse width, delivery, control and safety — and we qualify the source.
