Power stability, linewidth, beam quality
TUN-W-1480~16601480 nm infrared tunable CW laser
1480 nmThe TUN-W-1480~1660 is a precision 1480 nm CW laser delivering 1~2000 mW output power, with <5%, <3% power stability. View technical specifications, download the datasheet, and request configuration options from Precisometer.
Specifications
TUN-W-1480~1660
14 specification rows
| Output / average power | 1~2000 mW |
|---|---|
| Spectral linewidth | <2 nm |
| Power stability | <5%, <3% |
| Beam / notes | Tunable W avelength Band: 1480~1660 nm |
| Operating mode | CW |
| Beam divergence, full angle (mrad) | <10 |
| Cooled method | Air Cooled |
| Operating temperature (℃) | 15-35 |
| Power supply (100-240VAC) | RAD1PS |
| Expected lifetime (hours) | >10000 |
| Wavelength deviation(nm) | ±10 |
| Beam diameter at the aperture (1/e2,mm) | <10 |
| Beam height from base plate (mm) | 103 |
| Warm-up time (minutes) | <10 |
What do you need?
Tell us the output power, beam quality and beam delivery you need, and we'll reply with the matching configuration and lead time.
Model selection
Nearby series comparison
Compare TUN-W-1480~1660 with the closest available models in the CW Lasers family.
| Selection parameter | TUN-W-1480~1660 (current) | TEM-LN-1480 | TEM-F-1480 |
|---|---|---|---|
| Wavelength | 1480 nm | 1480 nm | 1480 nm |
| Optical power / pulse energy | 1~2000 mW | 1~350 mW | 1~350 mW |
| Operating mode / pulse width | CW | CW | CW |
| Beam quality | <10 | <1.1 | <1.1 |
