SLM, narrow linewidth, coherence
11221122 nm infrared narrow-linewidth single-frequency laser
1122 nmThe 1122 is a 1122 nm laser source. Output power describes the optical energy delivered per second. At the sample, irradiance also depends on the beam area and losses through the optical path, so the delivered spot must be considered along with the source rating.
Specifications
1122
3 specification rows
| Wavelength | 1122 nm |
|---|---|
| Output / average power | 1~250 mW |
| Spectral linewidth | <1 MHz |
| M² | <1.2 |
What do you need?
The full datasheet for this model is on request. Tell us the output power, linewidth and beam delivery you need, and we'll reply with the matching configuration and lead time.
Model selection
Nearby series comparison
Compare 1122 with the closest available models in the Single-Frequency Lasers family.
| Selection parameter | 1122 (current) | 1112 | TUN-1054~1074 |
|---|---|---|---|
| Wavelength | 1122 nm | 1112 nm | 1073 nm |
| Optical power / pulse energy | 1~250 mW | 1~200 mW | 1~40 mW |
| Beam quality | <1.2 | <1.2 | Near TEM00 |
Related single-frequency lasers
Compare the 1122 with nearby single-frequency lasers across the wavelength range.
