ABC-35
ABC Series Beam Dumps
Brief Introduction: The ABC series beam damper is mainly used to damper the useless laser beam.
Datasheet (PDF) ↗CAD Model (RAR) ↗Specifications
| Model | ABC-35 |
|---|---|
| Internal Diameter(mm) | Ø35 |
| Main Body Material and Treatment | Black anodized aluminium alloy |
| External Diameter (mm) | Ø49 |
| Overall Thickness(mm) | 50 |
| Mounting Hole | M6 |
| Net Weight(g) | 180 |
Model selection
Why specify ABC-35?
ABC-35 is a ABC Series Beam Dumps model. Key selection data: Model: ABC-35; Internal Diameter(mm): Ø35; Main Body Material and Treatment: Black anodized aluminium alloy; External Diameter (mm): Ø49.
Applications
Beam cleanup
Remove higher-order structure and scatter to recover a clean Gaussian profile.
Preparing a reference wavefront
Produce the smooth wavefront interferometry and holography need at the input.
Beam expansion with filtering
Combine pinhole filtering and collimation in one assembly ahead of the experiment.
