MDL-HD-12081208 nm infrared CW laser
1208 nmMDL-HD-1208 is a 1208 nm CW laser. Used for laser projection, laser shows, biomedical applications, holography. Laser. Key specifications: output / average power 1~3500 mW, operating mode CW, power stability (rms, 4 hours ± 3°c) <2%, <1%, <0.5%. View specifications, datasheet and enquiry options from Precisometer.
Specifications
MDL-HD-1208
16 specification rows
| Output / average power | 1~3500 mW |
|---|---|
| Beam / notes | Laser |
| Operating mode | CW |
| Power stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Transverse mode | Multimode |
| Polarization direction | Horizontal+ Vertical |
| Beam divergence, full angle (mrad) | <5 |
| Operating temperature (℃) | 25±3 |
| Power supply (100-240VAC) | PSU-N-FDA/PSU-N-LED |
| Expected lifetime (hours) | >10000 |
| Central wavelength (nm) | 1208±15 |
| Output power (mW) | 1-3500 |
| Beam diameter at the aperture (mm) | ~13×7.0 |
| Warm-up time (minutes) | <5 |
| Beam height from base plate (mm) | 25 |
| Modulation option | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional |
Applications
Uses named on this model’s datasheet.
- Laser projection
- Laser shows
- Biomedical applications
- Holography
- Metrology
